NATIONAL INSTRUMENTS NI9502 DRIVE MODULE

Send Inquiry

Request To Call Back

NATIONAL INSTRUMENTS NI9502 DRIVE MODULE

Get a Price/Quote

MOQ : 1 Piece

NATIONAL INSTRUMENTS NI9502 DRIVE MODULE Specification

Operating Temperature
-40C to +70C

Feature
Integrated feedback, safety features, easy configuration

Mounting Type
Din rail or module slot

IP Rating
IP20

Overheating Protection
YES

Connector Type
Removable terminal connector

Shape
Rectangular

Humidity %
10% to 90% non-condensing

Surface Finish
Matte

Efficiency
High

Insulation Material
Plastic casing

Product Type
Drive Module

Application
Motion control, C Series modules, CompactRIO systems

Protection Level
Overload Protection

Rated Voltage
24 V DC

Energy Consumption
Low

Output Type
Digital/PWM control

Color
Gray

Dimension (L*W*H)
27.9 mm x 122 mm x 88.1 mm

Weight
110 g

Input Voltage
19-30 V DC

Size
Standard C Series module

Phase
Single Phase

Material
Plastic, Metal

Connection Type
Terminal Block

Peak Current
10 A

Supported Motor Types
Brushless DC motors

Feedback Options
Hall sensors, quadrature encoder

Safety
Short-circuit and over-temperature protection

Interface
C Series module (NI CompactRIO, CompactDAQ)

Compliances
RoHS, CE, UL

Maximum Output Current
7.5 A continuous

Altitude
2000 m max

Storage Temperature
-40C to +85C

Firmware Upgradeable
Yes

Isolation Voltage
60 V (from system)

NATIONAL INSTRUMENTS NI9502 DRIVE MODULE About

Experience top-tier performance with the NATIONAL INSTRUMENTS NI9502 DRIVE MODULE, expertly engineered for motion control applications. Personalise your automation solutions using its advanced, integrated feedback for Brushless DC motors. This blue-ribbon C Series module offers extraordinary safety with overload, short-circuit, and over-temperature protection, ensuring reliable operation. Enjoy reduced energy consumption and high efficiency at an unbeatable price, available from leading suppliers and traders across India. Suitable for demanding environments, it is firmware upgradeable, compliant with RoHS, CE, and UL standards, and quick to configure for seamless system integration.

Ideal Applications and Versatile Usage

The NATIONAL INSTRUMENTS NI9502 DRIVE MODULE is suitable for use in industrial automation, robotics, and advanced motion control systems. Its usage type includes precise control in CompactRIO and C Series module platforms, making it perfect for engineers seeking reliable output and safety. Used for managing single-phase, high-efficiency Brushless DC motors, it ensures exceptional feedback and protection features for a wide array of industrial process automation scenarios.

Packaging, Certifications, and Sample Policy

Each NI9502 DRIVE MODULE is packaged to safeguard its integrity during transit, with secure mounting options included. Estimated arrival timelines depend on shipping preferences and location within India. This module meets RoHS, CE, and UL certification requirements, ensuring strict quality standards. Sample evaluation is available upon request, with rates varying according to quantity and destination-simply contact the supplier to initiate the request process and receive a sample for assessment.

FAQ's of NATIONAL INSTRUMENTS NI9502 DRIVE MODULE:

Q: How does the NI9502 drive module ensure safe operation in industrial applications?

A: The NI9502 drive module incorporates multiple safety features such as short-circuit, overload, and over-temperature protection, as well as isolation up to 60V, ensuring safe and reliable operation in various industrial environments.

Q: What types of motors are compatible with the NI9502 DRIVE MODULE?

A: This module is specifically designed to support Brushless DC motors, providing precise control and integrated feedback via hall sensors or quadrature encoders.

Q: When should firmware upgrades be considered for the NI9502 MODULE?

A: Firmware upgrades should be performed whenever National Instruments releases updates to improve functionality or enhance security, ensuring optimal performance and compatibility with other system components.

Q: Where can the NI9502 DRIVE MODULE be installed within an automation system?

A: The NI9502 is designed for seamless integration in NI CompactRIO and CompactDAQ systems, with standard DIN rail or module slot mounting options for easy installation.

Q: What are the benefits of using the NI9502 for motion control?

A: Users benefit from reduced energy consumption, high efficiency, and extraordinary ease of configuration, alongside robust feedback and comprehensive safety features for reliable, top-tier motion control.
