NATIONAL INSTRUMENTS NI9263 OUTPUT MODULE

Get a Price/Quote

MOQ : 1 Piece

NATIONAL INSTRUMENTS NI9263 OUTPUT MODULE Specification

Mounting Type
DIN Rail Mount

Surface Finish
Matte

Feature
Hot-swappable, Screw Terminal

Connector Type
Removable Spring Terminal

Shape
Rectangular

Overheating Protection
Built-in Thermal Shutdown

Operating Temperature
-40 C to 70 C

IP Rating
IP20

Humidity %
10% to 90% non-condensing

Insulation Material
Polyamide housing

Product Type
Analog Output Module

Application
Industrial Automation, Data Acquisition, Control Systems

Protection Level
Short-circuit protection, Over-voltage Protection

Rated Voltage
60 VDC max (Cat II)

Energy Consumption
2.1 W max at 24 VDC

Output Type
Analog Voltage

Color
Gray

Dimension (L*W*H)
120 mm x 28 mm x 69 mm

Weight
135 g

Phase
Single Phase

Size
Compact

Input Voltage
9 VDC to 30 VDC (C Series Power Supply)

Connection Type
Spring Terminal

Material
Plastic, Metal

Output Range
-10 V to +10 V, 16-bit Resolution

Hot-Swappable Capability
Yes

Number of Channels
4 Analog Output Channels

Storage Temperature
-40 C to 85 C

Conversion Time
60 s per channel

Channel-to-Channel Isolation
No, Channels referenced to COM

Synchronization
Hardware-timed synchronization with other C Series modules

Isolation Voltage
Channel-to-Earth Ground 60 VDC Continuous (Cat II)

Maximum Output Current per Channel
1 mA

Compliance Standard
CE, C-Tick, RoHS, UL, CSA

Output Resolution
16 bits (Span of 20 V)

Update Rate
Up to 100 kS/s aggregate

NATIONAL INSTRUMENTS NI9263 OUTPUT MODULE About

Discover the marvelous new release: NATIONAL INSTRUMENTS NI9263 OUTPUT MODULE, now trending for industrial automation and data acquisition needs in India. Access four top-ranking analog output channels, each with a superb 16-bit resolution and a span of -10 V to +10 V. Benefit from hot-swappable capability, rapid update rates up to 100 kS/s, and robust protection features. Its compact, DIN rail-mountable design and CE, UL, and RoHS compliance make it the ideal choice for cutting-edge control systems. Order today for a superior analog output solution.

Versatile Industrial Applications of the NI9263 Output Module

The NATIONAL INSTRUMENTS NI9263 OUTPUT MODULE excels in various industrial automation environments, perfectly suited for process control, data acquisition, and supervisory control systems. Its compact, IP20-rated design, paired with over-voltage and short-circuit protection, ensures reliable performance across manufacturing plants, laboratories, and research facilities. The hot-swappable, screw terminal connection and wide operating temperature range offer exceptional adaptability, making it suitable for both permanent installations and mobile, on-site test setups.

Streamlined Order Processing and Delivery for NI9263 Output Module

Prompt handover and efficient order processing ensure the timely dispatch of the NI9263 OUTPUT MODULE. With goods transport originating from major Indian ports, customers enjoy quick and safe delivery. Flexible payment terms accommodate diverse buyer requirements, while professional support guides you through every step-from placing your order to final handover. Rely on trusted logistics and careful packaging to guarantee your product arrives in pristine condition at your designated location.

FAQ's of NATIONAL INSTRUMENTS NI9263 OUTPUT MODULE:

Q: How does the NI9263 Output Module contribute to data acquisition and control systems?

A: The NI9263 Output Module offers high-resolution analog voltage output, enabling precise signal conversion, device control, and seamless hardware-timed synchronization in advanced data acquisition and control system architectures.

Q: What are the main protection features included in the NI9263 Output Module?

A: The module includes integrated over-voltage and short-circuit protection, as well as built-in thermal shutdown, ensuring reliable operation and safeguarding both the device and connected equipment in demanding industrial environments.

Q: Where can the NI9263 Output Module be applied?

A: It is ideally used in industrial automation, laboratory measurements, process control, and other applications involving data acquisition and analog signal output requirements.

Q: What is the order processing and delivery time for the NI9263 Output Module in India?

A: Order processing and handover are managed efficiently, with goods typically shipped from major Indian FOB ports; delivery time varies by location, but prompt logistics ensure swift transit to your facility.

Q: How does the hot-swappable capability of the NI9263 benefit users?

A: Hot-swappable functionality allows you to replace or add modules without powering down your system, minimizing downtime and simplifying maintenance or system upgrades in dynamic environments.
