ALLEN BRADLY 1769-IR6 INPUT MODULE

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLY 1769-IR6 INPUT MODULE Specification

Rated Operation Voltage
30V DC max

Protection Level
IP20

Base Material
Plastic

Panel Type
Modular DIN Rail Mountable

Thickness
Compact (Standard 1769 Series)

Control System
MicroLogix, CompactLogix

Components
RTD/Resistance Inputs, Status LEDs

Connectivity Type
Removable Terminal Block

Cooling System
Natural Air Cooled

Cover Material
Plastic

Features
Compact, High Accuracy Input Measurement, Removable Terminal Block

Rated Current
N/A (Input Module)

Rated Insulation Voltage
30V

Operating Voltage
30V DC max

Way
6 Channels

Protection Class
Class 1, Div 2 Hazardous Locations

Product Type
Analog RTD/Resistance Input Module

Material
Plastic and Metal Components

Surface Finish
Textured

Standard
IEC 61131-2

Surface Color
Grey

Rated Voltage
30V DC

Maximum Output Current
N/A (Input Module)

Dimension (L*W*H)
118 x 35 x 87 mm

Application
Industrial Automation, PLC System

IP Rating
IP20

Display Type
LED Status Indicators

Relative Humidity
5% to 95% non-condensing

Storage Temperature
-40 to 85C (-40 to 185F)

Input Signal Range
RTD: -200C to +850C, Resistance: 0-4000 Ohm

Input Type
RTD and Resistance Inputs

Module Power Supply Current
125 mA at 5V DC, 80 mA at 24V DC

Number of Channels
6 Differential Inputs

Resolution
16 bits

Operating Temperature
0 to 60C (32 to 140F)

Module Status Indicators
Channel Status and Module Status LEDs

Backplane Current (24V DC)
80 mA max

Backplane Current (5V DC)
125 mA max

Isolation Voltage
Basic Insulation, 30V (continuous), Reinforced to Backplane

Mounting Type
DIN Rail or Panel Mount

About ALLEN BRADLY 1769-IR6 INPUT MODULE

Buy the eminent ALLEN BRADLY 1769-IR6 Input Module, a venerable component trusted by industry leaders for reliable resistance and RTD input measurements. Explore its compact, modular design, perfect for PLC systems such as MicroLogix and CompactLogix. This scarce and highly sought-after module features 6 differential inputs, 16-bit resolution, a robust operating temperature range of 0 to 60C, and status LEDs for at-a-glance monitoring. With basic insulation and IP20 protection, it ensures safety and longevity. Secure your best automation results with this high-accuracy input solution, offered by a trusted supplier and trader in India.

ALLEN BRADLY 1769-IR6 INPUT MODULE: Usage & Applications

The ALLEN BRADLY 1769-IR6 Input Module is widely used in industrial automation, serving as a dependable RTD and resistance input module within PLC systems. Its application spans factory process monitoring, temperature control, and precision measurement in harsh environments. Designed for compatibility with MicroLogix and CompactLogix, it operates efficiently in media such as manufacturing floors, production lines, and testing laboratories, ensuring accurate data collection and process control where reliability is paramount.

Packaging, Export Markets & Payment for ALLEN BRADLY 1769-IR6 INPUT MODULE

Each ALLEN BRADLY 1769-IR6 Input Module is securely packaged to safeguard components during exchange and transportation. Modules are dispatched promptly, ensuring swift order completion for both domestic and international clients. Our main export markets include Asia and the Middle East, with flexible payment terms-including T/T, L/C, or advance payment-for seamless purchasing experiences. Trust our dedicated supplier network in India to deliver quality and efficiency for all your industrial automation needs.

FAQ's of ALLEN BRADLY 1769-IR6 INPUT MODULE:

Q: How does the ALLEN BRADLY 1769-IR6 Input Module benefit industrial automation processes?

A: This module offers high-accuracy RTD and resistance input readings for precise process control in industrial environments, leading to improved operational reliability and energy efficiency.

Q: What systems are compatible with the ALLEN BRADLY 1769-IR6 Input Module?

A: The module is designed for seamless integration with MicroLogix and CompactLogix PLC control systems, supporting efficient automation tasks in various industrial settings.

Q: Where can the 1769-IR6 Input Module be installed and operated safely?

A: It is suitable for installation on DIN rail or panel mounts in controlled environments, with an IP20 protection rating and Class 1, Div 2 hazardous locations compatibility.

Q: What is the process for ordering and receiving the ALLEN BRADLY 1769-IR6 Input Module?

A: Orders are processed quickly, and modules are dispatched in robust packaging to ensure safe delivery. Our streamlined order completion and payment options cater to local and export clients.

Q: How are input signals measured and displayed by the 1769-IR6 module?

A: The module supports 6 differential inputs, providing 16-bit resolution measurement for RTD and resistance signals, with channel and module status indicated by dedicated LEDs.
