SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB52-0XA0

Get a Price/Quote

SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB52-0XA0 Specification

Surface Finish
Matte, Robust Finish

Humidity %
5% to 95% non-condensing

Mounting Type
Panel/Field Mount

Operating Temperature
-25C to +60C

Feature
PG Access port, Integrated terminating resistor switch

Overheating Protection
NO

Efficiency
High Transmission Efficiency

Insulation Material
Plastic

Connector Type
9-pin D-Sub (Male)

Shape
Rectangular

IP Rating
IP20

Product Type
PROFIBUS Connector

Application
Industrial Automation, PROFIBUS Networks

Protection Level
Standard (With integrated strain relief)

Frequency (MHz)
Up to 12 Mbps

Rated Voltage
Max. 5V DC

Energy Consumption
Low

Output Type
Standard PROFIBUS Signal

Color
Grey

Dimension (L*W*H)
Approx. 76 x 35 x 16 mm

Weight
Approx. 40 g

Phase
Single Phase

Size
Standard D-Sub

Input Voltage
5V DC (from PROFIBUS line)

No Of Poles
9

Material
Plastic Body with Metal Housing

Connection Type
Screw / Clamp Terminal

Contact Resistance
5 m

Termination Resistor
Integrated, Switchable

Conductor Cross Section
0.25 mm to 0.5 mm

Cable Entry
Standard, 35 (angled)

Cable Diameter
Max. 8 mm

PG Port
Yes, Diagnostic PG port available

Compatible Systems
SIMATIC S7, All PROFIBUS DP Devices

Signal Transmission Rate
Up to 12 Mbit/s

About SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB52-0XA0

Experience the unparalleled reliability of the SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB52-0XA0, a valiant masterpiece engineered for industrial automation and PROFIBUS networks. This scarce bargain is ideally suited for those seeking high-performance connectivity, featuring an angled 35 cable entry and an integrated, switchable termination resistor. Its robust plastic and metal construction ensures durability, while its advanced diagnostic PG port sets it apart. Buy online today and secure a connector with superb signal integrity, masterful transmission rates up to 12 Mbit/s, and unmatched efficiency for your automation projects.

Innovative Features and Application Surface

The SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB52-0XA0 boasts primary advantages, including a sturdy IP20-rated design, integrated strain relief, and a matte, robust finish. Tailored for SIMATIC S7 systems and all PROFIBUS DP devices, it is engineered to operate efficiently in demanding industrial environments. Its 9-pin D-Sub male connector, panel or field mounting compatibility, and diagnostic PG port make it a top choice for seamless signal transmission across automation surfaces where reliability is critical.

Domestic and Global Market Supply and Delivery

Our supply network ensures that goods are shipped promptly across the main domestic market, satisfying a wide range of industrial automation needs. The connectors reliable supply ability meets both domestic and international demands, streamlining shipment to key export markets. With the growing demand for efficient PROFIBUS connectivity, our robust distribution guarantees timely availability, making us a trusted supplier and trader in various market segments worldwide.

FAQs of SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB52-0XA0:

Q: How does the integrated termination resistor benefit my PROFIBUS network?

A: The integrated, switchable termination resistor in the SIEMENS connector facilitates easy network termination, reducing reflection and data errors, ensuring stable and high-speed signal transmission.

Q: What primary features set the 6ES7 972-0BB52-0XA0 apart from other connectors?

A: Key features include its 35 angled cable entry, robust IP20 protection, a diagnostic PG port for system monitoring, support for up to 12 Mbit/s transmission, and high contact reliability with a low resistance of 5 m.

Q: Where is this connector most commonly used?

A: This connector is ideal for industrial automation and PROFIBUS networks, perfectly compatible with SIMATIC S7 and all PROFIBUS DP devices in control panels, production lines, and critical field installations.

Q: What is the mounting process for the SIEMENS PROFIBUS CONNECTOR?

A: The connector supports both panel and field mounting using its screw/clamp terminal system. This straightforward process ensures secure and efficient installation in a variety of industrial settings.

Q: When can I expect goods to be shipped after placing an order?

A: We pride ourselves on a strong supply chain and prompt service. Shipped goods are typically dispatched quickly both within the domestic market and to our main export regions, based on order availability and demand.
