SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BA10-0XA0

Get a Price/Quote

SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BA10-0XA0 Specification

Mounting Type
Direct mount (panel/field) with screws

Humidity %
max. 75% (non-condensing)

Insulation Material
Plastic

IP Rating
IP20

Surface Finish
Matte

Overheating Protection
NO

Connector Type
D-Sub, 9-pin male

Shape
Rectangular

Operating Temperature
-25C to +60C

Feature
Integrated PG port, Fast connection, Robust design

Efficiency
High

Product Type
PROFIBUS Connector

Application
Industrial Automation, PROFIBUS Networks

Protection Level
Standard

Frequency (MHz)
up to 12 Mbps data rate

Rated Voltage
5 V DC

Energy Consumption
Low

Output Type
Digital

Color
Gray

Dimension (L*W*H)
Approx. 60 x 40 x 17 mm

Weight
approx. 60 g

Input Voltage
5 V DC (from PROFIBUS)

Size
Standard

Phase
Single

Material
Plastic, Metal

No Of Poles
9

Connection Type
D-Sub 9-pin, Screw terminal

About SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BA10-0XA0

Explore the excellence of industrial connectivity with the SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BA10-0XA0. Designed for grand performance, this exclusive connector supports the finest SIMATIC S7 and PROFIBUS DP networks, guaranteeing efficient data transfer up to 12 Mbps. Its robust screw terminal and integrated PG (programming) socket ensure fast setup, while premium shielding provides optimal signal integrity. Enjoy reliable clamp functionality and standard protection in a compact, matte-finished body. The convenient D-Sub 9-pin connection, high compatibility, and CE/UL approvals mark this connector as the choice for exceptional automation solutions.

Essential Features & Versatile Application

The SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BA10-0XA0 offers fast connection with a horizontal cable entry and secure screw terminals. Boasting an integrated PG port and robust matte design, it reliably serves industrial automation and PROFIBUS network applications. Its compact rectangular shape and IP20 protection make it ideal for demanding environments. Efficient at a low energy consumption, this connector supports transmission rates up to 12 Mbps and is suitable for mounting directly in panels or on the field with screws.

Export & Domestic Market Reach

Our SIEMENS PROFIBUS CONNECTOR is widely exported, reaching international destinations via prime FOB ports for efficient freight handling. Orders are fulfilled with reliability, whether you require local drop-off or global shipping upon purchase order confirmation. Serving both main export markets and domestic clients, we focus on seamless logistics and timely delivery to ensure our customers receive the highest quality connectors for their automation systems, fostering trust across diverse regions.

FAQs of SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BA10-0XA0:

Q: How do I install the SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BA10-0XA0?

A: Installation requires direct mounting with screws onto panels or field equipment. Connect the PROFIBUS cable using the screw terminals, ensuring the shield connection for signal integrity. The integrated PG socket streamlines programming access.

Q: What are the primary benefits of using this PROFIBUS Connector in my automation system?

A: This connector delivers excellent reliability with secure screw terminals, robust shielding, and an integrated PG port for fast and easy network access, all while maintaining low energy consumption and supporting high transmission rates.

Q: Where is this connector typically used?

A: The SIEMENS PROFIBUS CONNECTOR is ideal for industrial automation applications and PROFIBUS DP networks, particularly with SIMATIC S7 systems, across various factory and process automation setups.

Q: When should I choose this connector over other models?

A: Opt for this model when your application demands high transmission speeds up to 12 Mbps, integrated PG socket, fast installation, and proven compatibility with PROFIBUS and SIMATIC S7 modules.

Q: What is the usage process for the PG socket feature?

A: The PG socket allows for convenient connection of programming devices, enabling on-site diagnosis and configuration without disconnecting the main PROFIBUS network, thus simplifying maintenance.
