SCHNEIDER ELECTRIC TSXDEY16D2 INPUT MODULE

Send Inquiry

Request To Call Back

SCHNEIDER ELECTRIC TSXDEY16D2 INPUT MODULE

Get a Price/Quote

MOQ : 1 Piece

SCHNEIDER ELECTRIC TSXDEY16D2 INPUT MODULE Specification

Rated Current
5 mA (per input)

Protection Class
Class I

Panel Type
Mountable (Rack/Panel)

Components
Screw Terminal Block, Status LEDs

Operating Voltage
24 V DC

Way
16 Channel

Current Rating
5 mA per channel

Control System
Modicon TSX Series

Thickness
Standard

Cabinet Material
Plastic

Rated Insulation Voltage
500 V AC

Protection Level
IP20

Cover Material
Plastic

Connectivity Type
Screw Terminal

Rated Operation Voltage
24 V DC

Features
Hot Swap Capable, Short Circuit Protection, Status Indication

Base Material
Plastic

Cooling System
Natural Air Cooling

Product Type
Input Module

Material
Plastic / Metal

Surface Finish
Matte

Standard
IEC 61131-2

Surface Color
Grey

Rated Voltage
24 V DC

Frequency (MHz)
50-60 Hz

Dimension (L*W*H)
125 mm x 32 mm x 100 mm

Application
PLC System I/O Expansion

IP Rating
IP20

Display Type
LED Indicator

Relative Humidity
5% to 95% non-condensing

Input Impedance
~4.7 k

Response Time
2 ms (ON/OFF)

Ambient Air Temperature for Storage
-40 to 85C

Operating Temperature
0C to 60C

Mounting
DIN Rail or Panel Mount

Ambient Air Temperature for Operation
0 to 60C

Isolation Voltage
500 V AC between channels and logic

Input Current
5 mA at 24 V DC

Number of Inputs
16

Storage Temperature
-40C to 70C

Input Type
Digital Discrete

Weight
~0.25 kg

About SCHNEIDER ELECTRIC TSXDEY16D2 INPUT MODULE

SCHNEIDER ELECTRIC TSXDEY16D2 INPUT MODULE is an ace solution, pivotal for expanding PLC system I/O with dominant precision. Featuring 16 ephemeral digital discrete inputs, it offers rapid 2 ms response time and favorable reviews from industrial experts. Its robust build and matte finish ensure reliable performance even in challenging environments. Grab this input module to experience premier isolation voltage (500 V AC), hot swap capability, and short circuit protection. Designed for rack or DIN rail mounting, this module integrates seamlessly, becoming the dominant force within Modicon TSX Series control systems.

Versatile Application & Robust Materials

The TSXDEY16D2 input module is tailored for PLC system I/O expansion, fitting seamlessly into commercial automation environments. Its plastic and metal construction, finished in sleek grey matte, ensures longevity and resistance to wear. Designed for mounting on DIN rails or panels, its an ideal choice for industrial setups requiring reliable input management and superior material strength across varying humidity and temperature ranges.

Sample Policy and Export Markets

Our sample policy is designed with transparent outlay, catering to clients looking to assess market value and functionality before bulk purchases. SCHNEIDER ELECTRIC TSXDEY16D2 modules are regularly transported from leading FOB ports across India to global markets, addressing strong demand in Asia, Europe, and the Middle East. This approach streamlines logistics, ensuring timely delivery and maximum commercial reach.

FAQs of SCHNEIDER ELECTRIC TSXDEY16D2 INPUT MODULE:

Q: How do I mount the TSXDEY16D2 input module in a control cabinet?

A: The TSXDEY16D2 module offers versatile mounting options, allowing installation via DIN rail or panel mounting. Ensure proper alignment and secure the screw terminal connections for stable performance within a PLC system.

Q: What are the major benefits of using this input module in industrial automation?

A: Users benefit from rapid 2 ms response time, hot swap capability, short circuit protection, and status indication via LED indicators. These features facilitate efficient control, quick troubleshooting, and enhanced safety in dynamic environments.

Q: Which commercial sectors frequently use the TSXDEY16D2 module?

A: The module is commonly deployed in manufacturing plants, process automation facilities, and utilitiesanywhere reliable discrete input management is a necessity for dominant control system operation.

Q: Where is the main export market for the TSXDEY16D2 input module?

A: Major export markets include Asia, Europe, and the Middle East, with transportation managed via Indias leading FOB ports for favorable global reach.

Q: What protection levels are integrated into the modules design?

A: The module carries an IP20 protection rating, insulation voltage of 500 V AC, and is built to IEC 61131-2 standards, ensuring reliable operation and safety against electrical hazards.
