OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT

Name: OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT
Brand: LOHIYA ELECTRICALS
Price: 1000.0 INR
Availability: InStock

Price 1000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT Specification

Cover Material
Polycarbonate

Connectivity Type
Controller Link Network (coaxial cable, twisted pair, optical fiber supported)

Operating Voltage
5 VDC

Protection Class
Class II

Protection Level
IP20

Control System
CS/CJ-series PLC Platform Communication System

Current Rating
60 mA

Panel Type
DIN-rail / Panel mount

Features
High-speed reliable data link, easy installation, flexible network configuration, supports node number setting switch, status indicators

Rated Current
0.06 A (from CJ1 BUS)

Components
Controller Link Communication Unit, connector terminal, instruction manual

Cooling System
Natural air cooling

Rated Operation Voltage
5 VDC (from controller bus)

Cabinet Material
Not enclosed (for internal installation)

Base Material
Polycarbonate

Thickness
Approx. 65 mm

Way
Multi-node (up to 32 nodes per network)

Rated Insulation Voltage
300 V

Product Type
Controller Link Unit

Material
Plastic and metal components

Surface Finish
Matte

Standard
OMRON Standard, RoHS compliant

Surface Color
Grey

Rated Voltage
5 VDC (supplied from CJ1 BUS)

Frequency (MHz)
4 MHz (network frequency)

Maximum Output Current
Not applicable (bus powered)

Dimension (L*W*H)
Approx. 90 mm 31 mm 65 mm

Application
Industrial automation, communication among OMRON PLCs

IP Rating
IP20

Display Type
LED Indicators

Module Power Consumption
Approx. 0.3 W

Storage Temperature
-20 to 75C

Operating Temperature
0 to 55C

Node Capacity
Up to 32 nodes per network

Allowed Shock Resistance
150 m/s2, 3 times each in X, Y, Z directions

Transmission Distance
Up to 500 m (coaxial cable, maximum 3 cable segments with repeaters)

Humidity
10% to 90% RH (no condensation)

Transmission Media
Coaxial cable, twisted pair, or optical fiber (with converter)

Network Topology
Bus, Star, and Ring

Mounting Method
Direct mounting on CJ1 series base units

Compatible PLC Series
CJ1, CJ2, CS1, NSJ (Ethernet/IP units supported via gateway)

Allowed Vibration Resistance
10-57 Hz, 0.075 mm amplitude

Weight
Approx. 100 g

Model Number
CJ1W-CLK21-V1

OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Telegraphic Transfer (T/T)

Supply Ability
1 Piece Per Day

Delivery Time
3 Days

Sample Available
No

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT

OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT Supplier In Bhavnagar, Gujarat, India

Lohiya electricals Dealing in all types of Industrial Automation Prod

uct and We are dealing in all India.

Model No: CJ1W-CLK21-V1

Products Name: OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT

Brand: OMRON

Condition: Used and Working

OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT available in Stock.

Note:- Custom/Duty and charges will be paid by buyer (if any)

MORE INFORMATION ABOUT THIS PRODUCT :

OMRON

CJ1W-CLK21-V1

CONTROLLER LINK UNIT

Flexible Network Topologies for Industrial Needs

The CJ1W-CLK21-V1 Controller Link Unit enables flexible network configurations including Bus, Star, and Ring topologies. Supporting up to 32 nodes per network, it allows for scalable communication among various Omron PLCs, ensuring adaptability to a wide range of industrial automation setups and layouts.

Robust and Reliable Communication

Designed for high-speed and dependable data transfer, the unit supports multiple transmission media-coaxial cable, twisted pair, and optical fiber with converters. With a transmission range of up to 500 meters (coaxial, with repeaters), it maintains stable communication even in extensive factory environments.

Easy Integration and Installation

Featuring direct mounting on CJ1 series base units, the CJ1W-CLK21-V1 ensures straightforward setup. The unit includes LED status indicators and node number setting switches, aiding in fast commissioning and easy troubleshooting to minimize downtime in industrial systems.

FAQ's of OMRON CJ1W-CLK21-V1 CONTROLLER LINK UNIT:

Q: How do I install the OMRON CJ1W-CLK21-V1 Controller Link Unit on my CJ1 series PLC?

A: The CJ1W-CLK21-V1 is designed for direct mounting on CJ1 series base units. Simply attach the unit to an available slot on your PLC rack, ensuring the connector terminals align securely. DIN-rail or panel mounting options may also be used if specified in your cabinet design.

Q: What types of network topology does this Controller Link Unit support?

A: This unit supports Bus, Star, and Ring topologies, making it suitable for a variety of network architectures in industrial environments. You can configure up to 32 nodes per network to suit both small and large-scale automation systems.

Q: When should I use coaxial cable, twisted pair, or optical fiber for network connections?

A: Choose the transmission medium based on your distance and interference requirements. Coaxial cable is suitable for up to 500 meters with repeaters, twisted pair is convenient for shorter distances with reduced wiring complexity, and optical fiber is ideal when electrical interference is a concern or when integrating with optical network devices (with a converter).

Q: Where can this controller link unit be used within an industrial setting?

A: The CJ1W-CLK21-V1 is suited for internal installation in control panels and enclosures found throughout manufacturing, process automation, and other industrial facilities. Its robust design meets IP20 standards, making it reliable for protected environments.

Q: What is the process for setting the node number and monitoring status?

A: Node numbers are set manually using the provided node number setting switch on the unit. Status can be monitored via the integrated LED indicators, which display communication and error states for straightforward diagnostics and operation.

Q: What are the primary benefits of using the OMRON CJ1W-CLK21-V1 Controller Link Unit?

A: Key benefits include high-speed, reliable networking between Omron PLCs, flexible topology and media options, easy installation, and simple troubleshooting through status indicators. Its compliance with RoHS and robust environmental tolerance make it suited for demanding industrial applications.

Q: Is this unit compatible with other Omron PLC series like CS1 or NSJ?

A: Yes, the CJ1W-CLK21-V1 is compatible with Omron's CJ1, CJ2, CS1, and NSJ PLC series. It also supports Controller Link communication with Ethernet/IP units through appropriate gateways, enhancing inter-series connectivity.
