CARLO GAVAZZI DPC01DM49400HZ PHASE MONITORING RELAY

Send Inquiry

Request To Call Back

CARLO GAVAZZI DPC01DM49400HZ PHASE MONITORING RELAY

Get a Price/Quote

MOQ : 1 Piece

CARLO GAVAZZI DPC01DM49400HZ PHASE MONITORING RELAY Specification

Connector Type
Screw Connector

Overheating Protection
Yes (Relay disconnect)

Efficiency
High (Relay Response time <200 ms)

Feature
Delay Setting, LED Indication, Automatic Reset

IP Rating
IP20

Operating Temperature
-20C to +60C

Mounting Type
DIN Rail

Insulation Material
Polycarbonate

Surface Finish
Matt

Shape
Rectangular

Humidity %
Up to 95% RH, non-condensing

Product Type
Phase Monitoring Relay

Application
Motor, Pump, Compressor Protection

Protection Level
Phase Sequence, Phase Loss, Phase Asymmetry, Undervoltage, Overvoltage

Frequency (MHz)
50-60 Hz

Rated Voltage
208-480 VAC

Energy Consumption
<3 VA

Output Type
Relay, SPDT

Color
White / Grey

Dimension (L*W*H)
90 mm x 22.5 mm x 73 mm

Weight
120 g

Phase
3 Phase

Size
22.5 mm (width) DIN rail

Input Voltage
208-480 VAC

No Of Poles
2

Material
Polycarbonate (housing), Copper (contacts)

Connection Type
Screw Terminal

About CARLO GAVAZZI DPC01DM49400HZ PHASE MONITORING RELAY

Experience immaculate performance with the venerable CARLO GAVAZZI DPC01DM49400HZ Phase Monitoring Relaya must-have for safeguarding motors, pumps, and compressors. For a limited time, enjoy instant savings on this exquisite device, which offers rapid response (<200 ms) and highly adjustable protection thresholds. Benefit from clear LED status indicators (Power, Alarm, Trip) and an automatic reset feature. Its robust polycarbonate construction, high isolation voltage (4 kV), and extensive service life (over 100,000 operations) ensure reliability. Equip your system now for elite protection and efficiency!

Exquisite Features and Robust Build for Demanding Applications

The CARLO GAVAZZI DPC01DM49400HZ Phase Monitoring Relay stands out with its extensive protective functions: phase sequence, phase loss, asymmetry, undervoltage, and overvoltage detection. Designed for critical application surfaces such as motor, pump, and compressor protection, it features a durable polycarbonate housing and copper contacts. Its matt finish, LED indicators, and adjustable thresholds add to its impeccable utility, making it ideal for environments demanding high precision and safety.

Swift Arrival and Export-Oriented Service for Global Markets

Expect your order of the CARLO GAVAZZI DPC01DM49400HZ to arrive promptly, thanks to efficient export market logistics. Available for shipment from major Indian FOB ports, each unit is backed by competitive sale pricing. Samples are available upon request to help you evaluate product excellence before purchase. Rely on a streamlined delivery process designed to meet the needs of international clients and ensure satisfaction on every arrival.

FAQs of CARLO GAVAZZI DPC01DM49400HZ PHASE MONITORING RELAY:

Q: How does the CARLO GAVAZZI DPC01DM49400HZ enhance protection for motors and compressors?

A: The relay provides advanced monitoring of phase sequence, phase loss, asymmetry, undervoltage, and overvoltage, protecting motors and compressors from electrical faults that could otherwise cause severe damage.

Q: What are the key features that make this relay a must-have for industrial applications?

A: Its key features include adjustable asymmetry and voltage thresholds, LED status indicators, delay setting, automatic reset, a fast response time of less than 200 ms, and robust polycarbonate construction for high durability.

Q: When is the best time to purchase the DPC01DM49400HZ Phase Monitoring Relay?

A: Now is the ideal time to purchase, as there are instant savings and limited-time offers available for this high-performance relay model.

Q: Where can I use the CARLO GAVAZZI phase monitoring relay?

A: This relay is perfectly suited for industrial settings, particularly in applications such as motor, pump, and compressor protection, anywhere three-phase voltage protection is critical.

Q: What is the process for installation and setup?

A: Installation is straightforwardmount on a DIN rail, connect using screw terminals, set voltage and asymmetry thresholds via the front dial, then power on to begin monitoring. No advanced programming is required.

Q: How does the relay benefit from features like LED indication and automatic reset?

A: LED indication allows immediate visual status checks, while automatic reset ensures continuous operation after transient faults, minimizing downtime and maintenance effort.
