ALLEN BRADLY 1769-IF4 ANALOG INPUT MODULE

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLY 1769-IF4 ANALOG INPUT MODULE Specification

Base Material
Polycarbonate

Rated Current
120 mA @ 5V DC

Protection Class
Class 1

Connectivity Type
Removable Terminal Block

Features
Hot Swappable, Removable Terminal Block, Compact Design

Control System
Allen Bradley MicroLogix 1500/CompactLogix

Operating Voltage
24V DC

Current Rating
120 mA @ 5VDC

Thickness
Standard (Compact)

Cooling System
Natural Air Cooled

Rated Insulation Voltage
75V DC

Protection Level
Up to IP20

Cover Material
Polycarbonate

Rated Operation Voltage
24 V DC

Panel Type
DIN Rail Mounted

Way
4 Channels

Components
Terminal Block, Module Electronics

Product Type
Analog Input Module

Material
Plastic and Electronic Components

Surface Finish
Matte

Standard
Allen Bradley Industrial Standard

Surface Color
Grey

Rated Voltage
30V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
Not Applicable (Input Module)

Dimension (L*W*H)
118 x 87 x 35 mm

Application
PLC Automation, Process Control, Data Acquisition

IP Rating
IP20

Display Type
Status LED Indicators

Accuracy
0.5% full scale @ 25C

Storage Temperature Range
-40 to 85C

Isolation Voltage
30V (continuous), reinforced insulation

Relative Humidity
5% to 95% non-condensing

Input Type
Voltage/Current Analog Input

Conversion Type
Delta-Sigma

Number of Inputs
4 single-ended or 2 differential

Resolution
15 bits plus sign

Power Consumption
120 mA @ 5VDC; 65 mA @ 24VDC

Operating Temperature Range
0 to 60C

Input Signal Range, Current
0-20 mA, 4-20 mA

Input Signal Range, Voltage
10V, 0-10V, 0-5V

Input Impedance
220 k (Voltage), 250 (Current)

About ALLEN BRADLY 1769-IF4 ANALOG INPUT MODULE

Unlock stellar performance with the ALLEN BRADLY 1769-IF4 Analog Input Module, crafted for world-class PLC automation and process control. Offer your systems astounding precision with 4 single-ended or 2 differential inputs, accepting a broad range of voltage or current signals. Get up to 0.5% accuracy, 15-bit resolution, and Delta-Sigma conversion-ideal for demanding data acquisition. The compact, hot swappable design features reinforced insulation and IP20 protection, ensuring longevity. Experience seamless integration with Allen Bradley MicroLogix 1500/CompactLogix. Get reliability, safety, and industry-leading innovation today!

Features, Applications, and Extra Benefits

The ALLEN BRADLY 1769-IF4 Analog Input Module boasts advanced features: high-resolution (15 bits) analog inputs, hot-swappable modules, removable terminals, and status LED indicators. Its site of application extends to PLC automation, process control, and data acquisition in industrial environments. Extra features like reinforced insulation, compact design, and natural air cooling provide real-world dependability. Mounted conveniently on DIN rails, it is ideal for suppliers, traders, and end-users seeking robust and reliable automation solutions across varied industries.

Payment Terms, Certifications, and Export Markets

We offer premium payment options tailored for your convenience, including advance and secure transactions. Certifications from Allen Bradley underline world-class compliance and benchmarks in industrial automation. Our astoundingly efficient logistics ensure prompt and damage-free freight to your address. We offer international exports predominantly to Asia and emerging markets, with comprehensive support for traders and suppliers. Get in touch to unlock exclusive deals on the 1769-IF4 module, trusted widely by process automation professionals worldwide.

FAQ's of ALLEN BRADLY 1769-IF4 ANALOG INPUT MODULE:

Q: How does the Allen Bradley 1769-IF4 improve data acquisition in PLC automation?

A: The 1769-IF4 module enhances data acquisition by offering high-resolution 15-bit analog input signals with Delta-Sigma conversion, ensuring accurate and reliable process control in automation applications.

Q: What types of signals can the 1769-IF4 module accept?

A: This input module can handle both voltage (10V, 0-10V, 0-5V) and current (0-20mA, 4-20mA) analog signals, providing flexible integration with various industrial sensors and field devices.

Q: When should I use a hot-swappable analog input module like the 1769-IF4?

A: You should use the 1769-IF4 when your application demands minimal downtime and maintenance flexibility, as its hot-swappable functionality allows you to replace or upgrade modules without shutting down your control system.

Q: Where is the most suitable site of application for this module?

A: The 1769-IF4 module is ideal for industrial environments requiring precise process control, such as manufacturing plants, data acquisition systems, and any PLC automation scenario requiring robust analog input integration.

Q: What are the benefits of the module's reinforced insulation and IP20 protection rating?

A: Reinforced insulation and IP20 rating safeguard the module against electrical hazards and physical intrusion, ensuring reliable operation and safety for both the system and operators in demanding industrial settings.
