ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT

Send Inquiry

Request To Call Back

ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT

Get a Price/Quote

ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT Specification

Way
24-way I/O

Rated Insulation Voltage
300V

Control System
Programmable Logic Controller

Rated Current
10A

Components
24V DC input, relay outputs, base unit terminal blocks

Protection Class
Class II

Thickness
Standard industrial panel mount

Base Material
Polycarbonate

Operating Voltage
120/240 VAC

Connectivity Type
Removable terminal blocks, expansion ports

Features
Modular design, quick-disconnect terminals, expandable I/O, diagnostic LEDs

Cover Material
Polycarbonate

Rated Operation Voltage
120/240 VAC

Current Rating
10A

Cooling System
Natural air convection

Protection Level
IP20

Panel Type
PLC control panel

Product Type
Micrologix 1500 Base Unit

Material
High-impact plastic housing

Surface Finish
Matte

Standard
IEC 61131-2, UL, CE

Surface Color
Light gray

Rated Voltage
120/240 VAC

Frequency (MHz)
50/60 Hz

Maximum Output Current
8A (relay) / 0.75A (transistor)

Dimension (L*W*H)
218 x 87 x 59 mm

Application
Industrial automation, Machine control

IP Rating
IP20

Display Type
LED status indicators

Number of Inputs
16 digital inputs

Environmental Protection
RoHS compliant

Isolation Voltage
1500V AC (input to output)

Expansion Capability
Supports additional modules

Operating Temperature
0 to 55°C

Model Number
1764-24AWA

Weight
Approx. 0.45 kg

Response Time
<10 ms

Power Consumption
Max. 35 VA

Number of Outputs
8 relay outputs

Storage Temperature
-40 to 85°C

Input Voltage Range
85-264 VAC

Processor Compatibility
Micrologix 1500 processor

Mounting Type
DIN Rail or panel mount

About ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT

Unlock spectacular performance for your automation projects with the resplendent ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT. Buy online and secure a valorous deal with instant checkout. Engineered in light gray, matte-finished polycarbonate, this base unit delivers reliable control with 16 digital inputs and 8 relay outputs. Supports DIN rail or panel mounting and operates in demanding industrial environments (0 to 55C). RoHS compliant, IEC 61131-2, UL, and CE certified, it offers modular expansion, quick-disconnect terminals, diagnostic LEDs, and superior isolation. Ideal for industrial automation and machine control.

Versatile Usage Across Industrial Applications

The ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT transcends conventional control panels, providing robust solutions for industrial automation, machine control, and process management. With programmable logic versatility, it suits application media ranging from manufacturing plants to energy monitoring and discrete control installations. Its modular design and expandable I/O allow engineers and technicians to customize usage for specific requirements, delivering dependable performance in varied industrial environments.

Streamlined Order, Valuation, and Certification Assurance

Benefit from express shipping when you place a purchase order for the ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT supplied by trusted traders in India. FOB port options are available for efficient logistics. Packaging details ensure secure deliveryunits are boxed with protective inserts. Certified to IEC 61131-2, UL, and CE standards, this product surpasses crucial valuation benchmarks for compliance and reliability, ensuring peace of mind throughout your procurement process.

FAQs of ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT:

Q: How does the ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT enhance industrial automation?

A: Its modular architecture, fast response time (<10 ms), and expandable I/O capability empower engineers to manage complex control tasks efficiently across various automation systems.

Q: What type of applications is this base unit used for?

A: It is primarily utilized in industrial automation, machine control, process monitoring, and PLC-based panel configurations where reliable and programmable logic control is required.

Q: Where can you purchase the ALLEN BRADLEY 1764 24AWA MICROLOGIX 1500 BASE UNIT in India?

A: You can buy online from authorized suppliers or traders, benefiting from express shipping and secure packaging tailored for the Indian industrial market.

Q: What certifications does the product hold for compliance?

A: The unit meets IEC 61131-2, UL, and CE standards, in addition to being RoHS compliant for environmental and safety assurance.

Q: How are expansion and connectivity handled in this base unit?

A: It supports additional modules via expansion ports, and features removable terminal blocks for quick, reliable connectivity within PLC control panels and industrial networks.
