AEC SMD SMD 506-C SERVO STEP DRIVE

Get a Price/Quote

MOQ : 1 Piece

AEC SMD SMD 506-C SERVO STEP DRIVE Specification

Connectivity Type
Screw Terminal, Pluggable Connector

Current Rating
6.0A

Cooling System
Passive Convection, No Fan

Thickness
Approx. 20 mm

Cover Material
Metal Enclosure

Rated Operation Voltage
24-80V DC

Control System
Pulse/Direction Control (Step/Dir)

Protection Level
Over-voltage, Over-current, Short Circuit, Over-temperature

Way
1 Way

Cabinet Material
Aluminum Alloy

Features
Microstep Drive, High Precision, Vibration Suppression, Automatic Current Reduction

Components
Microcontroller Based, Discrete ICs

Rated Current
6.0A max

Protection Class
Class I

Rated Insulation Voltage
500V

Base Material
Rigid PCB

Operating Voltage
24-80V DC

Product Type
Servo Step Drive (Compact) SMD 506-C

Material
Industrial Grade PCB, Electronic Components

Surface Finish
Matte Coated

Standard
Industry Standard Servo Step Drive

Surface Color
Black

Rated Voltage
24-80V DC

Frequency (MHz)
20-200 KHz (Pulse Input)

Maximum Output Current
6.0A

Dimension (L*W*H)
118mm x 75mm x 20mm

Application
Stepper and Servo Motor Control Automation

IP Rating
IP20

Display Type
LED Status Indicator

Input Signal Voltage
5V (TTL Compatible)

Weight
Approx. 350g

Humidity Range
40% - 90% RH (Non-condensing)

EMC Compliance
IEC/EN 61000

Step Resolution
Programmable, Up to 256 Microsteps/Revolution

Storage Temperature
-20C to +85C

Pulse Input Frequency
Up to 200 kHz

Compatible Motors
2-phase Hybrid Stepper, Servo Motors

RoHS Compliance
Yes

Signal Isolation
Optically Isolated Inputs

Efficiency
>90%

Insulation Resistance
>= 100 M (500V DC)

Ambient Temperature Range
0C to +50C

Mounting Type
Panel Mount with Slots

About AEC SMD SMD 506-C SERVO STEP DRIVE

Take advantage of the hot deal on the top-ranking AEC SMD 506-C SERVO STEP DRIVE and boost your automation reliability! Buy this exceptional, valiant drive for outstanding control with compatible 2-phase hybrid stepper and servo motors. With superior insulation, wide temperature tolerance, high efficiency (>90%), and robust protection (over-voltage, short circuit, and more), this industry-standard panel-mount unit is a must for precision tasks. Enjoy seamless installation with its black matte-coated metal enclosure and rigid PCB. The high-frequency input and programmable steps ensure ultimate performance in demanding settings.

Industrial Surface & Commercial Application Highlights

The AEC SMD 506-C SERVO STEP DRIVE is expertly designed for both stepper and servo motor control automation, making it ideal for varied industrial surfaces and commercial automation settings. Crafted from industrial-grade PCB and a sturdy aluminum alloy enclosure, it offers high precision, vibration suppression, and advanced microstep drive capabilities. Its matte black, rigid construction ensures resilience in demanding environments, supporting smooth business operations and extensive material longevity.

Payment Terms & Logistics for Hassle-Free Procurement

Dispatched conveniently from India, this superior drive is prepared for goods transport through reliable channels. Payment terms include flexible options to suit your business expenditure. The drive is securely packed to ensure safe delivery and maintain its integrity during transport. Available on an FOB port basis, customers can expect transparent cost management and clear logistics throughout the purchasing process, ensuring total peace of mind upon ordering this essential automation component.

FAQ's of AEC SMD SMD 506-C SERVO STEP DRIVE:

Q: How is the AEC SMD 506-C SERVO STEP DRIVE installed in automation systems?

A: It is designed for easy panel mounting with slots, making installation straightforward and secure in automation cabinets or control panels.

Q: What motors are compatible with this servo step drive?

A: The AEC SMD 506-C is compatible with 2-phase hybrid stepper motors and servo motors, ensuring flexibility for various industrial automation needs.

Q: Where can this drive be deployed within commercial applications?

A: It is suitable for use in commercial and industrial settings needing high-precision stepper or servo motor control, such as factory automation, robotics, and process machinery.

Q: What benefits does the drive's microstep resolution offer?

A: With programmable microstep resolution up to 256 microsteps per revolution, users achieve exceptional motion accuracy and smoother performance in motor applications.

Q: How does the drive ensure operational safety and equipment protection?

A: It features built-in protections including over-voltage, over-current, short circuit, and over-temperature safeguards, along with optically isolated signal inputs to prevent electrical faults.

Q: What type of material and construction enhances the drive's durability?

A: The use of industrial-grade PCB, a robust aluminum alloy cabinet, and a matte-coated finish provides durability, efficient passive cooling, and resilience in challenging industrial environments.
