VACON PC00350D CM280102 INVERTER BOARD

Get a Price/Quote

VACON PC00350D CM280102 INVERTER BOARD Specification

Panel Type
Control Panel Mounted

Way
Single Way

Components
High-Grade Capacitors, Resistors, ICs, Relays

Rated Insulation Voltage
600 V

Cover Material
None (Open PCB)

Cabinet Material
N/A (PCB only)

Protection Level
Conformal Coated

Rated Current
10 A

Thickness
2.0 mm

Cooling System
Passive

Control System
Microcontroller Based

Current Rating
10 A

Rated Operation Voltage
220-500 V AC

Features
High Reliability, Industrial Grade, OEM Replacement

Base Material
FR4

Protection Class
Class I

Connectivity Type
Screw Terminal/Plug-In Connectors

Operating Voltage
220-500 V

Product Type
Inverter Board

Material
High-grade Fiber Epoxy PCB

Surface Finish
Lead-Free HASL

Standard
OEM Specification

Surface Color
Green

Rated Voltage
500 V

Frequency (MHz)
50/60 Hz Compatible

Maximum Output Current
10 A

Dimension (L*W*H)
350 mm x 120 mm x 25 mm

Application
Vacon Inverter/Drive Replacement

IP Rating
IP00 (Circuit Board)

Display Type
No Display

Storage Temperature
-40°C to +85°C

Mounting Type
Panel or Chassis Mount

Weight
0.35 kg

Operating Temperature Range
-20°C to +70°C

PCB Layer
4 Layer

Repair/Serviceable
Yes

Input Voltage Range
200-500 V AC

Suitable Model
VACON CX, NXC Series Inverters

Manufacturer Part Number
PC00350D CM280102

About VACON PC00350D CM280102 INVERTER BOARD

Unlock commanding control and dominant performance with the VACON PC00350D CM280102 INVERTER BOARDbuilt for VACON CX and NXC Series Inverters. This latest OEM replacement board features a high-grade fiber epoxy PCB with a robust 4-layer design, ensuring eminent reliability in industrial environments. Advance purchase opportunities available for a limited time only! Expertly engineered for panel or chassis mounting, it delivers up to 10A current and supports 220-500V AC. Boasting superior protection and industry-standard lead-free HASL finish, this serviceable board empowers your drives with assured precision.

VACON PC00350D CM280102 INVERTER BOARD: Industrial Applications

Widely used by professionals for VACON inverter and drive replacements, this board is ideal in sectors demanding high reliability and control, such as manufacturing plants and process automation. It incorporates advanced features, including a microcontroller-based control system and high-grade components, ensuring optimal performance in diverse industrial environments. Engineered for ease of mounting on control panels or chassis, this product consistently meets the needs of dominant operational setups requiring sustained precision and power.

Certifications, Supply & Sample Policies for VACON PC00350D CM280102

Manufactured to OEM specification and industrial-grade standards, the VACON PC00350D CM280102 INVERTER BOARD is available with reliable transportation solutions for bulk proposal amounts. We maintain a strong supply ability to ensure timely delivery, supporting project outlays with confidence. Samples may be provided subject to supplier policy, helping clients evaluate before committing substantial investments. Our streamlined distribution process is devised to meet the needs of eminent suppliers and traders seeking quick, dependable fulfillment.

FAQs of VACON PC00350D CM280102 INVERTER BOARD:

Q: How is the VACON PC00350D CM280102 INVERTER BOARD installed?

A: The board can be mounted directly onto a panel or chassis using standard fittings. Screw terminal and plug-in connectors provide straightforward electrical integration into VACON CX and NXC Series inverters.

Q: What area of application does the VACON PC00350D CM280102 suit best?

A: It is ideally suited for industrial environments, including manufacturing and automated process plants, where reliable inverter and drive control is paramount.

Q: When should the VACON PC00350D CM280102 INVERTER BOARD be replaced?

A: Replacement is recommended when existing inverter boards exhibit faults, reduced performance, or at scheduled maintenance intervals to uphold dominant operational reliability.

Q: Where can I source samples for evaluation before full purchase?

A: Samples may be available upon request, depending on supplier policy and proposal amount. Contact your distributor for details on sample provision and transportation options.

Q: What benefits does repair/serviceability offer for this inverter board?

A: Being repairable and serviceable, this board allows users to extend the operational lifespan and reduce overall outlay compared to full replacement, supporting ongoing reliability and cost-efficiency.

Q: How does the board ensure safety and protection during operation?

A: It features conformal coating and meets Class I protection standards, providing insulation and safeguarding against environmental factors within the prescribed IP00 rating for circuit boards.
