SIEMENS SINAMICS 6SL3430-6TE21-6AA0 SMART LINE MODULE

Send Inquiry

Request To Call Back

SIEMENS SINAMICS 6SL3430-6TE21-6AA0 SMART LINE MODULE

Get a Price/Quote

MOQ : 1 Piece

SIEMENS SINAMICS 6SL3430-6TE21-6AA0 SMART LINE MODULE Specification

Connector Type
Terminal Blocks

Power Supply
Three-phase AC, 380 480 V +10%/-10%

Rated Power
16 kW

Working Temperature
0C to +40C (Derating up to +55C)

Noise Level
<60 dB

Phase
3-Phase

Rated Current
32 A

Power Factor
>= 0.95

Features
Compact design, Integrated protection, High reliability, Easy installation, Modular system

Cooling Method
Internal air cooling by built-in fan

Operating Temperature
0C to +40C

Application
Industrial Drives, Automation, Motion Control

Output Type
DC Link Voltage

Current Range
Max 32 A

Output Current
32 A

Product Type
SINAMICS Smart Line Module

Output Power
16 kW

Output Frequency
0 Hz (Line module passes DC link voltage)

Input Voltage
380-480 V AC (3-phase)

Voltage Protection
Integrated Overvoltage and Undervoltage Protection

Efficiency
Up to 98%

Material
Metal Housing

Line Regulation
< 1%

Storage Temperature
-40C to +70C

Weight
8.5 kg

Standards Compliance
CE, UL, cUL, EN 61800-5-1

System Compatibility
S120 multi-axis drives

Insulation Voltage
Basic insulation up to 600 V

Relative Humidity
5% to 95%, non-condensing

Enclosure Protection
IP20

Mounting Type
Panel Mount

Product Code
6SL3430-6TE21-6AA0

Communication Interfaces
Profinet, Profibus via CU modules

Braking Option
External brake chopper can be connected

DC Link Voltage
up to 800 VDC

Maximum Altitude
Up to 1000 m without derating; up to 4000 m with derating

Frequency Range (Input)
47-63 Hz

Series
SINAMICS S120

SIEMENS SINAMICS 6SL3430-6TE21-6AA0 SMART LINE MODULE About

The featured SIEMENS SINAMICS 6SL3430-6TE21-6AA0 SMART LINE MODULE, acclaimed for its first-class performance, delivers unparalleled efficiency and reliability in demanding industrial environments. This customizable panel-mounted solution, part of the majestic SINAMICS S120 series, boasts a compact metal housing with IP20 protection and supports up to 16 kW output power at a remarkable 98% efficiency. Integrated overvoltage and undervoltage protection ensure safe operations, while modular connectivity via Profinet and Profibus makes system integration seamless. Its robust design supports up to 4000 m altitude and adheres to the highest international standards.

Versatile Applications & Superior Features

SIEMENS SINAMICS 6SL3430-6TE21-6AA0 excels in automation, motion control, and industrial drives, making it ideal for diverse manufacturing setups. The external brake chopper option enhances safety, while integrated protection and modularity guarantee flexibility. Crafted from premium metal, its internal fan ensures efficient cooling under rigorous conditions, providing long-term durability and consistent output. This module is engineered for reliability in environments with humidity up to 95% and significant temperature fluctuations.

Competitive Payment Terms & Swift Delivery

Enjoy the lowest price offers for the SIEMENS SINAMICS 6SL3430-6TE21-6AA0 via express shipping throughout the main domestic market in India. Sample policy options are available to help you evaluate the product before commitment. Delivered efficiently with secure payment terms, this acclaimed module reaches your facility quickly and smoothly, enabling fast deployment and uninterrupted productivity in your operations.

FAQs of SIEMENS SINAMICS 6SL3430-6TE21-6AA0 SMART LINE MODULE:

Q: How does the SIEMENS SINAMICS 6SL3430-6TE21-6AA0 benefit industrial automation sectors?

A: This line module enhances industrial automation by delivering reliable DC power, high efficiency, and superb integration through Profinet and Profibus for multi-axis SINAMICS S120 systems.

Q: What extra features set this module apart from other power line solutions?

A: The module offers modular system compatibility, integrated voltage protection, external brake chopper connection, and superior cooling through a built-in fan, distinguishing it as a flexible and safe option.

Q: Where can the module be installed and operated efficiently?

A: It is designed for panel mounting and operates efficiently even at altitudes up to 4000 meters (with derating), in environments with up to 95% humidity and temperatures ranging from -40C to +70C when stored.

Q: What is the process for acquiring sample units of the SIEMENS SINAMICS 6SL3430-6TE21-6AA0?

A: Sample units can be requested through the suppliers sample policy, enabling thorough evaluation before making bulk purchases or full-scale deployment.

Q: How does the payment and delivery process ensure fast and secure transactions?

A: The payment terms guarantee secure transactions while express shipping across India ensures the module is delivered promptly at the lowest possible price.

Q: When should external brake choppers be connected to the module?

A: External brake choppers should be connected when additional safety or controlled braking is required during the operation of multi-axis motion control systems.
