DC SIEMENS SIMATIC S7 300 CPU 6ES7 314-1AG14-0AB0

Get a Price/Quote

DC SIEMENS SIMATIC S7 300 CPU 6ES7 314-1AG14-0AB0 Specification

Feature
Programmable Logic Controller (PLC)

Mounting Type
DIN Rail Mounting

Shape
Rectangular

Surface Finish
Matte

Insulation Material
Plastic

Overheating Protection
YES

Connector Type
Screw Connector

IP Rating
IP20

Operating Temperature
0C to 60C

Product Type
PLC CPU Module

Application
Industrial Automation

Protection Level
Standard

Frequency (MHz)
622 MHz

Rated Voltage
24 VDC

Energy Consumption
Low Power Consumption

Output Type
Digital and Analog

Color
Black

Dimension (L*W*H)
125 x 135 x 130 mm

Weight
Approx. 750 grams

Warranty
1 Year

Size
Medium

Phase
Single Phase

Input Voltage
24 VDC

No Of Poles
Single Pole

Material
Polycarbonate

Connection Type
Terminal Block

About DC SIEMENS SIMATIC S7 300 CPU 6ES7 314-1AG14-0AB0

SIEMENS SIMATIC S7 300 CPU 6ES7 314-1AG14-0AB0

Text-to-speech function is limited to 200 characters

Options : History : Feedback : Donate

Versatile PLC for Industrial Control

The SIMATIC S7 300 CPU is engineered to handle a variety of automation tasks, providing precise control over complex mechanical and electrical processes. Its programmability and diverse input/output types make it suitable for numerous industrial environments, enhancing flexibility and productivity.

Robust Design for Reliable Operation

Constructed from durable polycarbonate with a matte finish, this CPU ensures long-lasting performance. The IP20 protection level guards against dust, and the built-in overheating protection adds an extra layer of safety in high-temperature applications.

Simplified Installation and Integration

Mounted easily on DIN rails, the S7 300 CPU uses screw connectors and terminal blocks, streamlining the setup process. Its moderate dimensions allow for efficient space utilization while maintaining optimal accessibility and connectivity with other control components.

FAQs of DC SIEMENS SIMATIC S7 300 CPU 6ES7 314-1AG14-0AB0:

Q: How do I install the SIMATIC S7 300 CPU 6ES7 314-1AG14-0AB0 in an industrial setting?

A: The CPU can be mounted on a standard DIN rail using the included bracket. For connections, use the terminal block with screw connectors to link input and output wires securely. Ensure the operating environment is within the recommended temperature range of 0C to 60C.

Q: What are the main benefits of using this PLC in industrial automation?

A: This programmable logic controller offers high-speed processing, energy-efficient operation, and flexible digital and analog outputs. Its robust insulation and overheating protection ensure dependability, making it ideal for complex automation tasks.

Q: When should I consider replacing or upgrading the CPU unit?

A: Consider replacement if you witness recurring faults, system lag, or if your automation needs have outgrown the CPUs processing or I/O capabilities. The included 1-year warranty supports timely troubleshooting and part replacement if necessary.

Q: Where can this PLC be effectively utilized?

A: The SIMATIC S7 300 CPU is suitable for factories, process plants, and industrial environments requiring precise automation and control. Its single-phase operation and medium size make it adaptable to various installation scenarios.

Q: What is the process for programming and configuring this PLC?

A: Programming is typically accomplished using Siemens automation software, which allows you to create, modify, and upload control logic to the CPU. The integrated digital and analog outputs can be assigned specific functions during setup, tailored to your application needs.

Q: How does the overheating protection feature function in this CPU?

A: The built-in overheating protection continuously monitors the devices internal temperature and automatically initiates preventive measures if high temperatures are detected, safeguarding the CPU from thermal damage and ensuring consistent operation.
