SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0

Send Inquiry

Request To Call Back

SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0

Get a Price/Quote

SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 Specification

IP Rating
IP20

Efficiency
High

Surface Finish
Matte

Insulation Material
Plastic

Operating Temperature
0 to 55C

Overheating Protection
YES

Shape
Rectangular

Humidity %
5-95% (non-condensing)

Mounting Type
DIN Rail

Feature
High Interference Immunity, Hot Swappable, Expandable

Connector Type
Terminal

Product Type
Digital Input/Output Module

Application
PLC Automation System, Industrial Automation

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
24 V DC

Energy Consumption
Max. 10 W

Output Type
Relay

Color
Grey

Dimension (L*W*H)
100 x 70 x 75 mm

Weight
170 g

Phase
Single Phase

Input Voltage
24 V DC

Size
Standard

Connection Type
Screw Terminal

Material
Plastic, Metal

Shock Resistance
Complies with EN 60068-2-27

Response Time
Input: < 1 ms; Output: < 1 ms

Isolation Voltage
500 V (channel to backplane)

Compatible CPU
SIMATIC S7-1200 Series

Vibration
Complies with EN 60068-2-6

Module Type
SM 1223 DC/RLY

Switching Capacity of Relay Output
2A at 30V DC / 250V AC

Standards
IEC 61131-2

Number of Digital Outputs
8 (Relay)

Number of Digital Inputs
8

Channel Status LED
Yes

About SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0

Redeem extraordinary value with the SIEMENS S7 SM 1223 DC/RLY (6ES7 223-1PH30-0XB0), engineered for potent performance in PLC and industrial automation. Featuring 8 superb digital inputs and 8 relay outputs, this module capitalises on high switching capacity2A at 30V DC or 250V ACto drive demanding operations. Benefit from rapid response times (<1 ms), robust IEC 61131-2 and EN 60068 compliance, and a high standard of protection (IP20). Its hot-swappable, expandable design ensures operational continuity, making it a valuable asset for your automation setup.

Versatile Automation for High-Demand Applications

The SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 is used across PLC automation and industrial automation applications, delivering exceptional reliability and control. Its robust rectangular build, high interference immunity, and relay outputs are tailored for usage in critical processes. This potent expansion module is compatible with SIMATIC S7-1200 CPUs, ideal for those who require flexibility, hot-swappable capability, and easy DIN-rail mounting for streamlined installations in dynamic industrial settings.

Sample Policy and International Trade Details

Ask for our competitive list price and sample policy to evaluate the SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 before purchase. We facilitate FOB Port options for smooth international shipments. Our main export markets include Asia, the Middle East, and Africa. The asking price reflects the modules sophisticated features and compliance with international standards, ensuring top-tier value for global buyers seeking reliability in automation modules.

FAQs of SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0:

Q: How can I benefit from using the SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 in automation?

A: You can capitalise on superb relay switching, rapid response times, and reliable performance, significantly enhancing efficiency and system flexibility in your industrial or PLC automation projects.

Q: What type of outputs does this module support and at what capacity?

A: The module provides 8 relay outputs, each offering a switching capacity of 2A at 30V DC or 250V AC, ensuring robust output control for demanding industrial loads.

Q: Where can the SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 be utilised?

A: It is expertly designed for industrial automation and PLC automation systems where reliable input/output management and compliance with international standards are required.

Q: What are the key features that distinguish this expansion module?

A: Notable features include high interference immunity, hot-swappable and expandable design, channel status LEDs, quick response times, and compliance with IEC and EN standards for safety and performance.

Q: How does the sample procurement process work for international buyers?

A: Interested buyers can inquire about our sample policy and list price. The process includes requesting samples, finalising the FOB port for shipment, and confirming the asking price before purchasing larger quantities.
