SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0

Send Inquiry

Request To Call Back

SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0

Get a Price/Quote

SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 Specification

Overheating Protection
YES

Connector Type
Terminal Block

Feature
LED Status Indicator, Removable Terminal Blocks

Operating Temperature
-20 to +60 C

Humidity %
5 to 95% (non-condensing)

Insulation Material
Polyamide

Surface Finish
Matte

IP Rating
IP20

Shape
Rectangular Module

Efficiency
High (Industrial Grade)

Mounting Type
DIN Rail Mounting

Product Type
Digital Input/Output Expansion Module

Application
PLC Automation Systems, SIMATIC S7-1200

Protection Level
Basic Protection, Short-circuit & Overload Protection

Frequency (MHz)
50-60 Hz

Rated Voltage
24 V DC

Energy Consumption
Approx. 2 W

Output Type
Relay Outputs

Color
Gray

Dimension (L*W*H)
100 x 45 x 81 mm

Weight
0.23 kg

Phase
Single Phase

Input Voltage
24 V DC

Size
Compact

Material
Plastic Housing

Connection Type
Screw Terminal

No Of Poles
None (Not Applicable)

Product Code
6ES7 223-1PH30-0XB0

Digital Outputs
6 Relay Channels (5-30V DC/5-250V AC, 2A Max)

Digital Inputs
8 Channels (24 V DC)

Response Time Inputs
Input delay 4.5 ms typ.

Response Time Outputs
Relay switching time 10 ms typ.

Storage Temperature
-40 to +70 C

Relative Air Pressure
79.5 to 1080 hPa

Standards Compliance
IEC 61131

Environmental Resistance
Vibration and Shock Proof

Maximum Wire Size
2.5 mm2 (Terminal Block)

Approval/Certification
CE, cULus, KC

Compatible Controller Series
SIMATIC S7-1200

Sealability
Finger-safe

Lifecycle Status
Active

About SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0

Explore the top-rated SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0a dazzling addition to any PLC automation system. With 8 brilliant digital input channels and 6 sought-after relay outputs, this compact module ensures robust performance at the best price. Its sturdy build, vibrant LED status indicator, and advanced protection features make it a reliable choice for demanding industrial environments. Certified to international standards, this active, vibration-proof, and energy-efficient module is your gateway to seamless SIMATIC S7-1200 compatibility and operational excellence.

Versatile Applications and Usage

The SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 is ideal for modern PLC automation systems, particularly those utilizing the SIMATIC S7-1200 controller series. Its brilliant input and output capabilities make it suitable for assembly lines, manufacturing plants, and process control applications. Designed for rugged industrial environments, its compact design and reliable relay outputs ensure seamless integration, superior efficiency, and steadfast performance across a wide range of industrial scenarios.

Sample Availability and Market Reach

Sample units of the SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 can be dispatched promptly to interested buyers. We provide competitive quotations and flexible logistics for clients across India and key international markets. With a focus on efficiency, our seamless supply chain caters to both the main export and domestic sectors, ensuring smooth delivery and reliable support to our valued customers.

FAQs of SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0:

Q: How does the SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 enhance PLC automation systems?

A: This module expands the input and output capabilities of SIMATIC S7-1200 PLCs, enabling efficient control and monitoring with reliable performance, energy efficiency, and advanced protection features such as short-circuit and overload protection.

Q: What applications is this module best suited for?

A: It is well-suited for industrial automation, assembly lines, process control, and similar environments where robust digital inputs and relay outputs are needed for seamless and reliable operation.

Q: When can sample units be dispatched to customers?

A: Sample units are available for prompt dispatch upon request, subject to availability and confirmation through our sales or support team.

Q: Where can the SIEMENS S7 SM 1223 DC/RLY 6ES7 223-1PH30-0XB0 be installed?

A: This rectangular module is designed for DIN rail mounting in electrical panels, ensuring easy installation in industrial control cabinets and automation setups.

Q: What is the typical process for obtaining quotations and arranging delivery?

A: Customers can request a quotation through our sales channels. After receiving the quotation, we coordinate tailored logistics for swift delivery to both domestic and international buyers.

Q: How does the module ensure long-term reliability?

A: Built with a vibration- and shock-resistant design, industrial-grade materials, and compliance with global standards, the module offers stability and durability in demanding operational environments.
