SIEMENS S7 1231 TC MODULE 6ES7 231-50D32-0XB0

Send Inquiry

Request To Call Back

SIEMENS S7 1231 TC MODULE 6ES7 231-50D32-0XB0

Get a Price/Quote

SIEMENS S7 1231 TC MODULE 6ES7 231-50D32-0XB0 Specification

Surface Finish
Matte

Insulation Material
High Grade Plastic

Efficiency
High precision signal acquisition

Humidity %
5% to 95% (non-condensing)

IP Rating
IP20

Shape
Rectangular

Mounting Type
DIN rail

Operating Temperature
-20C to +60C

Overheating Protection
Yes, integrated diagnostics

Feature
8 differential thermocouple input channels, extensive diagnostics

Connector Type
Screw terminal

Product Type
Thermocouple Input Module

Application
Temperature Measurement & Process Automation

Protection Level
Class 1 (as per IEC 61131-2)

Frequency (MHz)
50/60 Hz

Rated Voltage
24 V DC

Energy Consumption
Max. 1.5 W

Output Type
N/A (Input Module)

Color
Grey

Dimension (L*W*H)
100 x 40 x 75 mm

Weight
120 g

Input Voltage
24 V DC

Size
Compact

Phase
Single Phase

Material
Plastic & Metal

Connection Type
Screw terminal

Input Channels
4 (independent, differential)

Isolation
Yes, between channels and logic

Compatibility
SIMATIC S7-1200 Series PLCs

Conversion Time
< 400 ms per channel

Wire Gauge
0.2-2.5 mm2 solid/stranded

Supported Thermocouple Types
J, K, T, E, N, S, R, B

Storage Temperature
-40 to +70 C

Part Number
6ES7 231-50D32-0XB0

Status Indicators
LED for channel and module status

Module Type
TC (Thermocouple) Module

Product Series
S7-1200

Resolution
16 Bit

About SIEMENS S7 1231 TC MODULE 6ES7 231-50D32-0XB0

Add to Cart the pristine SIEMENS S7 1231 TC MODULE 6ES7 231-50D32-0XB0 for top-notch temperature measurement in your process automation projects. This majestic S7-1200 series TC Module features four independent, differential channels accommodating a broad range of thermocouple types for exceptional versatility and accuracy. Advanced purchase ensures you benefit from swift, integrated diagnostics, Class 1 protection, and high-precision 16-bit resolution. Its compact design, robust IP20-rated construction, and compact dimensions make it a perfect fit for modern control panels. Pick yours now!

Unmatched Precision and Versatility for Temperature Control

The SIEMENS S7 1231 TC MODULE delivers remarkable competitive advantages, including reliable isolation between channels and logic, rapid signal conversion, and extensive diagnostics. Ideal for process automation, industrial ovens, and HVAC systems, it is predominantly used as a temperature input module for the SIMATIC S7-1200 Series PLCs. Its 8-channel input capability and support for a wide spectrum of thermocouple types provide unparalleled flexibility in demanding applications.

Global Reach, Prompt Delivery & Sample Availability

This SIEMENS S7 1231 TC MODULE is delivered promptly to main export markets such as Europe, Asia, and the Middle East. Drop-off is available within a short time after confirming the asking price. Samples can be provided on advance request, ensuring you experience quality before full-scale procurement. Secure your modules with reliable logistics management for safe, on-time delivery, enhancing your operations with Siemens excellence.

FAQs of SIEMENS S7 1231 TC MODULE 6ES7 231-50D32-0XB0:

Q: How does the SIEMENS S7 1231 TC MODULE ensure high-precision temperature measurement?

A: The module features 16-bit resolution, rapid conversion time of less than 400 ms per channel, and extensive diagnostics, allowing for precise temperature readings and quick fault identification.

Q: What is the compatibility of the 6ES7 231-50D32-0XB0 module?

A: This TC module is compatible with the SIMATIC S7-1200 Series PLCs, seamlessly integrating into your process automation systems for flexible and reliable temperature measurement.

Q: Where can the SIEMENS S7 1231 TC MODULE be applied?

A: It is ideal for process automation, temperature measurement in industrial equipment, ovens, HVAC systems, and any setup requiring accurate thermocouple signal handling.

Q: What thermocouple types does the module support?

A: It accommodates J, K, T, E, N, S, R, and B thermocouple types, making it suitable for a broad spectrum of industrial applications.

Q: What are the benefits of using this module in automation systems?

A: Users gain reliable isolation, compact size, powerful diagnostics, and robust protection, ensuring safe, efficient, and sustained performance in harsh environments.

Q: How can a sample of the SIEMENS S7 1231 TC MODULE be obtained?

A: A sample can be requested during your initial inquiry. Once the asking price is discussed and advance terms are met, delivery will be arranged promptly.
