SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB20-0XA0

Send Inquiry

Request To Call Back

SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB20-0XA0

Get a Price/Quote

SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB20-0XA0 Specification

Connector Type
D-Sub 9 Pin Female

Operating Temperature
-25C to +60C

Surface Finish
Metallic

Mounting Type
Direct Plug-on (D-Sub 9-Pin) with locking screws

Feature
Integrated termination resistor, diagnostic LEDs

IP Rating
No IP rating (Indoor use)

Shape
Rectangular

Insulation Material
Polyamide / Plastic

Overheating Protection
NO

Humidity %
Up to 75% RH (non-condensing)

Efficiency
Passive (not rated)

Product Type
PROFIBUS Connector

Application
Industrial Automation, PROFIBUS DP Networks

Protection Level
Standard; no IP classification

Frequency (MHz)
Up to 12 Mbps

Rated Voltage
5V DC

Energy Consumption
Passive (no energy consumption)

Output Type
BUS Signal

Color
Silver/Grey

Dimension (L*W*H)
59 x 35 x 17 mm (approx.)

Weight
Approx. 50g

Input Voltage
Not required (passive device)

Size
Standard PROFIBUS Size

No Of Poles
9 (for D-Sub female) / 2 (for terminating resistor)

Material
Metal housing with plastic internal components

Connection Type
Screw Terminal Connection

Termination
Switchable integrated terminating resistor (on/off)

Bus Connection
1 x 9-pin Sub-D socket, screw connection terminals for bus cable

Strain Relief
Yes, integrated

Service Port
No (non-service version)

RoHS Compliance
Yes

Minimum Bending Radius
Approx. 30 mm (depending on cable)

Maximum Data Rate
12 Mbps (PROFIBUS DP Standard)

Status Display
LED (indicates bus communication and errors)

Compatibility
All standard PROFIBUS DP devices

Contact Resistance
5 m

Approvals/Certifications
CE, UL recognized

Maintenance
Tool-free opening for easy access

Shielding
Full metal enclosure for optimal shielding

Cable Entry
Horizontal (90 to connector)

Diagnostic
Integrated bus diagnostic LEDs for status display

Wire Cross-Section
0.250.5 mm (AWG 2420)

About SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB20-0XA0

New release! Discover the commanding SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB20-0XA0your last chance to advance purchase this polished component for seamless PROFIBUS DP integration. Designed with a grandiose metallic finish and a horizontal cable entry, it features a switchable termination resistor for flexible network configuration. Diagnostic LEDs provide intuitive status monitoring. Benefit from tool-free access, robust strain relief, and full metal shielding for reliable connectivity. Compatible with all standard PROFIBUS DP devices, this connector is precision-engineered to handle fast-paced, industrial automation environments. RoHS, CE, and UL approved.

Competitive Advantages & Applications

The SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB20-0XA0 excels with its grandiose durability and commanding performance, ensuring robust and polished connectivity in automation projects. Integrated diagnostic LEDs and tool-free access provide clear operational status and simplified maintenance. Its ideal for industrial automation and high-demand PROFIBUS DP networks across manufacturing, logistics, and process industries, supporting superior communication between devices while maintaining minimal contact resistance for consistent signal quality.

Sample Policy & Export/Domestic Markets

SIEMENS offers sample units of the PROFIBUS CONNECTOR at minimal charge, ensuring prompt arrival and hands-on evaluation for buyers seeking the lowest price advantage. Serving both leading export markets and domestic industrial sectors, this connector is readily available for quick deployment. Buyers benefit from competitive rates and global shipping, making it a preferred choice among traders and suppliers aiming to deliver quality and value in automation solutions.

FAQs of SIEMENS PROFIBUS CONNECTOR 6ES7 972-0BB20-0XA0:

Q: How does the integrated diagnostic LED enhance connector usage?

A: The integrated diagnostic LEDs provide real-time status updates, allowing users to quickly identify bus communication and error conditions for efficient troubleshooting and maintenance.

Q: What process is involved in installing the SIEMENS PROFIBUS CONNECTOR?

A: Installation is straightforward: simply direct plug onto the D-Sub 9-pin interface, use the locking screws for secure mounting, and connect bus cables with the screw terminals. Tool-free opening ensures easy and quick access.

Q: Where can the SIEMENS PROFIBUS CONNECTOR be used?

A: This connector is optimized for use in industrial automation, manufacturing, and process control environments, ensuring reliable communication in PROFIBUS DP networks.

Q: When is the termination resistor switched on or off?

A: The switchable integrated termination resistor can be set to on when the connector is at the end of a network segment for proper signal termination, and off when located in the middle of a segment.

Q: What are the benefits of the metal housing and full shielding?

A: The full metal enclosure ensures optimal signal shielding against electromagnetic interference, providing robust protection and maintaining a polished connectivity standard ideal for demanding applications.

Tell us about your requirement
