SIEMENS ENCODER EQI 1325.005-32

Get a Price/Quote

SIEMENS ENCODER EQI 1325.005-32 Specification

Rated Operation Voltage
5 V DC

Way
Single Turn / Multi Turn

Features
High Precision, Compact Design, Magnetically shielded, Long Lifespan

Cover Material
Aluminum / Plastic

Thickness
86 mm

Connectivity Type
Circular Connector, 15 Pin

Rated Current
100 mA

Base Material
Aluminum Alloy

Current Rating
100 mA

Rated Insulation Voltage
500 V

Operating Voltage
5 V DC

Control System
Closed Loop Feedback System

Components
Encoder Body, Flange, Coupling, Connector, Cable

Protection Class
Class I

Cabinet Material
Aluminum

Cooling System
Passive (No Fan)

Protection Level
IP67

Product Type
Rotary Absolute Encoder

Material
Aluminum Alloy & High Grade Electronics

Surface Finish
Anodized Finish

Standard
Siemens Standard

Surface Color
Silver & Black

Rated Voltage
5 V DC

Frequency (MHz)
12 MHz

Maximum Output Current
100 mA

Dimension (L*W*H)
132 mm Diameter x 86 mm Length

Application
Industrial Automation, Siemens CNC & Servo Systems

IP Rating
IP67

Measuring Length
8192 Turns (Multi-Turn)

Weight
Approx. 850 g

Power Consumption
< 2 W

Storage Temperature
-40°C to +85°C

Resolution
25 Bit (Multi-Turn) / 13 Bit (Single Turn)

Relative Humidity
Max 95% Non-Condensing

Ambient Temperature
-20°C to +85°C

Mounting
Clamping Flange

Output Signal
Serial Data (EnDat, SSI)

Shock Resistance
2000 m/s² (6 ms)

Shaft Diameter
12 mm

Vibration Resistance
Up to 100 m/s² (10...2000 Hz)

About SIEMENS ENCODER EQI 1325.005-32

Discover the new release: SIEMENS ENCODER EQI 1325.005-32, a prodigious solution tailored for top-tier industrial automation. Take advantage of competitive pricing on this phenomenal encoder, featuring a 25-bit multi-turn and 13-bit single-turn resolution with a measuring length of 8192 turns. Its robust aluminum alloy construction, IP67 protection level, and high vibration/shock resistance guarantee durability, while its advanced connectivity (EnDat, SSI Serial Data) ensures seamless performance. Designed for Siemens CNC & Servo Systems, it delivers reliable closed-loop feedback and long-lasting precisionyour ideal choice for demanding environments.

Versatile Industrial Application

The SIEMENS ENCODER EQI 1325.005-32 is specifically engineered for both general and commercial use. Ideal for deployment in industrial automation, it excels in Siemens CNC and servo systems, offering precise position feedback in closed-loop systems. Its compatibility spans various applications, including manufacturing, robotics, and process control, making it suitable for type-of-usage scenarios from routine operation to complex and high-demand environments where accuracy and dependability are non-negotiable.

Professional Packaging & Supply Details

This premium encoder arrives in secure packaging designed to safeguard its integrity during transit. With substantial supply ability to meet large-scale requirements, customers can take advantage of sale price offers for bulk purchases. The product is distributed across main domestic markets, optimizing expenditure while maintaining exceptional quality. Whether you need single units or significant volume orders, professional handling and reliable logistics guarantee timely delivery and satisfaction in every transaction.

FAQs of SIEMENS ENCODER EQI 1325.005-32:

Q: How does the SIEMENS ENCODER EQI 1325.005-32 benefit industrial automation processes?

A: It delivers prodigious precision and stability in position feedback, enabling more accurate and efficient control in CNC and servo systems essential for automation.

Q: What are the main commercial uses of this encoder?

A: It is primarily used in manufacturing equipment, robotics, and process control systems where high-resolution feedback ensures smooth operation and enhanced productivity.

Q: Where is the encoder best installed for optimal performance?

A: The encoder should be mounted in environments that require closed-loop feedback, such as on motor shafts in Siemens CNC machinery, ensuring reliable signal transmission and protection from dust and moisture, thanks to its IP67 rating.

Q: What is the process for connecting this encoder to a control system?

A: Connection involves using the circular 15-pin connector for output signal transmission (EnDat or SSI), integrated into the control cabinet using standard Siemens procedures for closed-loop feedback applications.

Q: When should buyers consider bulk purchasing this product?

A: Bulk purchasing is recommended when outfitting multiple machines or upgrading existing systems to take advantage of sale pricing and lower overall expenditure per unit.

Q: How does the aluminum alloy and anodized finish contribute to its lifespan?

A: The high-grade aluminum alloy and anodized surface enhance durability by resisting corrosion and physical wear, ensuring long-term reliability even in harsh industrial conditions.
