SIEMENS CIRCUIT BOARD CP5621

Get a Price/Quote

SIEMENS CIRCUIT BOARD CP5621 Specification

Humidity %
Up to 95% non-condensing

Efficiency
High signal transmission efficiency

Feature
Supports MPI/PROFIBUS communication, Plug & Play

Surface Finish
Soldermask Coated

Mounting Type
PCI Slot Mounted

Connector Type
DB9 Female for Profibus/MPI

Shape
Rectangular

Operating Temperature
0C to 60C

IP Rating
N/A (for internal use)

Insulation Material
Epoxy Resin (standard PCB insulating layer)

Overheating Protection
Yes (internal thermal management by PC)

Product Type
Communication Processor Module

Application
Industrial Automation & Communication (MPI/Profibus Interface)

Protection Level
Standard PCB Protection

Frequency (MHz)
9-12 MHz typ.

Rated Voltage
5V DC (supplied by host PC)

Energy Consumption
Low

Output Type
Digital Data Output

Color
Green

Dimension (L*W*H)
approx. 100 x 90 x 22 mm

Weight
Approx. 150 g

Size
Standard PCI Card Size

Input Voltage
5V DC

Connection Type
PCI Interface

No Of Poles
N/A (Electronic Circuit Board)

Material
High-Quality PCB Material

About SIEMENS CIRCUIT BOARD CP5621

Experience the elite performance of the SIEMENS CIRCUIT BOARD CP5621, model 6GK1561-1AA01, a noble solution designed for lofty industrial automation and communication demands. This exclusive PCI interface board supports powerful MPI and PROFIBUS DP bus systems, delivering a towering data transfer rate of up to 12 Mbps. Featuring integrated ESD protection and a robust operating temperature range, it ensures unwavering reliability. The board is firmware-upgradeable and features plug & play convenience, so you receive the ultimate in efficiency with elite standardsan exceptional choice for discerning professionals.

Advanced Features & Optimum Applications

The SIEMENS CIRCUIT BOARD CP5621 is equipped with advanced features such as high signal transmission efficiency, internal overheating protection, and robust ESD shielding. It supports seamless integration with SIEMENS SIMATIC S7, WinCC, and PCS7 systems, making it ideal for demanding industrial automation and communication tasks. Plug & play capability and sturdy PCB construction ensure straightforward use and durability, while compatibility with Windows 32-bit and 64-bit platforms broadens its application, fitting both new and existing installations.

Domestic Market Focus & Service Details

Serving the main domestic market with efficiency, the SIEMENS CIRCUIT BOARD CP5621 is offered with reliable packing & dispatch standards. Our sample policy enables prospective clients to assess the boards performance firsthand. Scheduled drop-offs guarantee timely delivery, ensuring the board reaches your site in pristine condition. With a list price reflecting elite value, we provide flexibility for traders and suppliers. Expect swift lead times, careful handling, and assured product integrity throughout the distribution cycle.

FAQs of SIEMENS CIRCUIT BOARD CP5621:

Q: How does the SIEMENS CP5621 Circuit Board enhance industrial automation systems?

A: The CP5621 enables high-speed, reliable digital data communication between industrial control systems, leveraging MPI and PROFIBUS protocols for seamless SIMATIC S7, WinCC, and PCS7 integration.

Q: What are the suitable operating conditions for the SIEMENS CP5621?

A: The CP5621 operates optimally in temperatures from 0C to 60C, with storage capability down to -40C and up to 70C, and relative humidity up to 95% non-condensing, making it ideal for various industrial environments.

Q: Where can the CP5621 be installed within a system?

A: The board mounts internally via a standard PCI slot in compatible control PCs, ensuring easy deployment within industrial automation hardware setups.

Q: What is the process for firmware upgrading on the SIEMENS CP5621?

A: Firmware can be upgraded using the manufacturer-provided utility, allowing the board to maintain compatibility and improve performance with evolving system requirements.

Q: What benefits does the integrated ESD protection provide?

A: Integrated ESD protection helps shield sensitive electronic components from electrostatic discharges, increasing the boards durability and operational reliability in industrial settings.

Q: When can I expect delivery of the SIEMENS CP5621 after ordering?

A: Delivery is typically arranged swiftly after order confirmation, with secure packing & dispatch and scheduled drop-off to maintain product integrity and minimize lead time.
