SIEMENS A5E02484572-003 PCB Card

Get a Price/Quote

SIEMENS A5E02484572-003 PCB Card Specification

Rated Current
2A

Connectivity Type
Pin Header Connector

Components
SMT / Through Hole

Thickness
1.6mm

Operating Voltage
24V DC

Base Material
Glass Epoxy

Panel Type
PCBA

Current Rating
2A

Features
High Reliability, Compact Design, Easy Replacement

Rated Insulation Voltage
500V AC

Protection Class
Class II

Protection Level
IP20

Way
Multilayer

Cooling System
Natural Air Cooling

Control System
Siemens Automation System

Rated Operation Voltage
24V DC

Product Type
Industrial PCB Card

Material
FR4 Glass Epoxy

Surface Finish
HASL (Hot Air Solder Leveling)

Standard
IEC/EN 61131-2

Surface Color
Green

Rated Voltage
24V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
2A

Dimension (L*W*H)
125mm x 80mm x 18mm

Application
Automation, PLC, Machine Control

IP Rating
IP20

Compatible Devices
SIMATIC S7, ET200, other SIEMENS modules

Storage Temperature Range
-20C to +85C

Weight
Approx. 62g

Service Life
>10 Years

RoHS Compliance
Yes

PCB Conformal Coating
Available (on request)

Output Type
Digital Output (Configurable Ports

Withstand Voltage
AC 1000V, 1 minute

PCB Layers
4 Layer

Model Number
A5E02484572-003

Input Type
Digital / Analog (depending on configuration)

Insulation Resistance
>100M

Operating Temperature Range
0C to +60C

Mounting Type
Panel Mount / DIN Rail (with optional housing)

SIEMENS A5E02484572-003 PCB Card About

Experience transcendent reliability with the SIEMENS A5E02484572-003 PCB Card, expertly engineered for a variety of automation and control applications. This first-string PCB card delivers the ultimate in reduced downtime, blending top-tier insulation resistance (>100M), four multilayer PCB design, and RoHS compliance. Its fresh, compact design (125x80x18mm, 62g) supports both panel and DIN rail mounting with optional housing. Compatible with SIMATIC S7, ET200, and other SIEMENS modules, it offers configurable digital or analog inputs, ultimate service life over 10 years, and conformal coating on request for maximized protection.

Versatile Automation for Demanding Applications

The SIEMENS A5E02484572-003 PCB Card stands out in advanced automation, machine control, and PLC environments. Crafted from durable FR4 glass epoxy, this solution features a multilayer design for enhanced performance and reduced EMI. Commercial users benefit from its robust structure, IP20 protection, and compatibility with leading Siemens control systems, ensuring longevity and reliability in both industrial and commercial contexts.

Sale Price Flexibility and Global Export Services

SIEMENS A5E02484572-003 PCB Cards are available at competitive sale prices with safe, secure packaging tailored to international shipping standards. Transport services are chosen for reliability and efficiency, supporting major export markets across Asia, Europe, and the Middle East. Detailed invoicing, clear payment terms, and responsive support streamline procurement, guaranteeing smooth cross-border transactions for suppliers and traders in India and beyond.

FAQs of SIEMENS A5E02484572-003 PCB Card:

Q: How does the SIEMENS A5E02484572-003 PCB Card ensure high reliability in automation systems?

A: The card features a durable four-layer PCB, high insulation resistance (>100M), and a robust material composition (FR4 glass epoxy). Its configurable digital/analog inputs and outputs, as well as compatibility with Siemens automation modules, help maintain optimal performance and reduced wear over its long service life.

Q: What are the application areas for this SIEMENS PCB Card?

A: It is designed for advanced automation, industrial machine control, PLC systems, and other applications where reliable control and communication with Siemens modules such as SIMATIC S7 and ET200 are essential.

Q: When should conformal coating be requested for this PCB Card?

A: Conformal coating is recommended when the PCB will operate in environments susceptible to moisture, dust, or corrosive agents, as it provides an additional protective barrier, further enhancing longevity and reliability.

Q: Where can the SIEMENS A5E02484572-003 be installed?

A: Its versatile design allows for panel or DIN rail mounting, making it suitable for integration in control cabinets or automation panels within various industrial settings.

Q: What are the benefits of its RoHS compliance and IP20 protection level?

A: RoHS compliance ensures the product is free from hazardous substances, promoting environmental safety. IP20 protection provides basic defense against solid objects, which is suitable for controlled industrial environments.
