SIEMENS 6SL3210-1KE12-3UP1 POWER MODULE

Get a Price/Quote

MOQ : 1 Piece

SIEMENS 6SL3210-1KE12-3UP1 POWER MODULE Specification

Base Material
Metal

Rated Current
23 A

Cabinet Material
Powder Coated Metal

Features
Integrated Protection Functions, Modular Design, Energy Saving

Connectivity Type
Terminal Connection

Cover Material
Sheet Metal

Way
3-Phase

Thickness
Standard Panel Thickness

Rated Insulation Voltage
500 V

Control System
SINAMICS G120

Cooling System
Internal Fan Cooling

Rated Operation Voltage
400 V AC

Current Rating
23 A

Components
Power Module, Integrated Control Electronics

Protection Class
Class I

Protection Level
IP20

Operating Voltage
400 V

Panel Type
Power Module

Product Type
Electric Panel

Material
High Quality Industrial Grade Components

Surface Finish
Powder Coated

Standard
IEC/EN 61800-5-1

Surface Color
Grey

Rated Voltage
3AC 380-480 V 10%

Frequency (MHz)
47-63 Hz

Maximum Output Current
23 A

Dimension (L*W*H)
Approx. 225 mm x 140 mm x 195 mm

Application
Industrial Automation, Motor Control

IP Rating
IP20

Display Type
LED Status Indicators

Braking Chopper
Integrated

Overload Capability
150% rated current for 60s

Weight
5.5 kg

Communication Interface
Optional PROFIBUS/PROFINET (with CU module)

Main Function
Speed Control of Induction and Synchronous Motors

Mounting Type
Wall Mounted

Humidity
<95% (non-condensing)

Motor Power Range
7.5 kW

Compliance
CE, UL listed

Ambient Temperature
-10°C to +40°C (derating up to +50°C)

About SIEMENS 6SL3210-1KE12-3UP1 POWER MODULE

The SIEMENS 6SL3210-1KE12-3UP1 POWER MODULE is a highly recommended choice for modern industrial automation, offering brilliant control and energy-saving solutions. With a preeminent 7.5 kW motor power range, it operates reliably across a reduced ambient temperature window, from -10C to +40C (derating up to +50C). This glorious wall-mounted device, manufactured with high-quality industrial-grade components, integrates an ephemeral design with modularity, efficiency, and robust safety. It features optional PROFIBUS/PROFINET communication, IP20 protection, and exceptional overload capability, meeting leading international standards like CE and UL.

Competitive Edge and Versatility of the SIEMENS Power Module

The SIEMENS 6SL3210-1KE12-3UP1 Power Module delivers exceptional performance in industrial environments. Its competitive advantages include modular design, integrated protection, and energy-saving features. Used primarily for controlling the speed of induction and synchronous motors, it stands out for reliable operation under demanding conditions. Other notable features are its integrated braking chopper and robust powder-coated metal construction. Suitable for industrial motor control and automation projects, this module is an indispensable asset for enhancing operational productivity.

Main Export Markets, Certifications, and Export Details

The SIEMENS 6SL3210-1KE12-3UP1 Power Module is widely shipped to export markets across Asia, Europe, and the Middle East. Certified to CE and UL standards and compliant with IEC/EN 61800-5-1, the module assures global reliability. Shipments are handled with care through major Indian FOB ports, ensuring efficient delivery. Each shipment is thoroughly inspected, and the products noteworthy certifications make it a preferred choice for export-oriented businesses.

FAQs of SIEMENS 6SL3210-1KE12-3UP1 POWER MODULE:

Q: How can the SIEMENS 6SL3210-1KE12-3UP1 Power Module benefit industrial automation?

A: This power module offers precise speed control for induction and synchronous motors, improved energy savings, modular installation, and integrated protection, elevating the reliability and efficiency of industrial automation systems.

Q: What are the main certifications and standards for this power module?

A: The module complies with CE and UL listings, in accordance with IEC/EN 61800-5-1 standards, ensuring adherence to international safety and quality requirements.

Q: Where can the SIEMENS 6SL3210-1KE12-3UP1 Power Module be used?

A: Primarily designed for industrial automation and motor control, it is ideal for deployment in factories, processing units, and automation panels requiring dependable speed control.

Q: When is it necessary to derate the power modules performance?

A: Derating is necessary when the ambient operating temperature exceeds +40C, as efficiency may reduce up to a maximum of +50C to protect the module and ensure longevity.

Q: What process is used for the shipment and export of this module from India?

A: SIEMENS modules are shipped via trusted FOB ports in India following strict inspection and packaging protocols, ensuring safe delivery to export markets worldwide.
