SIEMENS 6SE7021-8TB84-6HF3 PCB CARD

Get a Price/Quote

MOQ : 1 Piece

SIEMENS 6SE7021-8TB84-6HF3 PCB CARD Specification

Panel Type
Plug-in Control PCB

Protection Level
Conformal Coated

Cover Material
None (Exposed PCB)

Cooling System
Air Cooled

Way
4-Layer PCB

Rated Insulation Voltage
690V AC

Operating Voltage
24V DC

Thickness
1.6 mm

Base Material
FR4 Epoxy Resin

Cabinet Material
Not Applicable (Mounted in Drive Enclosure)

Connectivity Type
Edge Connector, Terminal Block

Rated Operation Voltage
600V AC

Components
ICs, Resistors, Capacitors, Connectors

Control System
Used in closed-loop drive control

Rated Current
4 A

Protection Class
Class I

Features
Original Siemens part, high reliability, auto-detection, quick plug-in replacement

Current Rating
4 A

Product Type
Electronic Module

Material
PCB (Printed Circuit Board), Electronic Components

Surface Finish
HASL (Hot Air Solder Leveling)

Standard
Siemens Industrial Standard

Surface Color
Green

Rated Voltage
24V DC (Control), 600V AC (Power)

Frequency (MHz)
50/60 Hz

Maximum Output Current
4 A

Dimension (L*W*H)
230 mm x 110 mm x 22 mm

Application
Siemens SINAMICS / SIMOREG Drive Inverter Control

IP Rating
IP00 (No direct enclosure)

Repairability
Field Replaceable

PCB Type
Double-Sided, Multilayer

Compatible Series
SINAMICS, SIMOREG Inverter Drives

Replacement Part Number
6SE7021-8TB84-6HF3

Weight
Approx. 250 g

RoHS Compliance
Yes

Mounting Type
Plug-in/Socket Mounting

Typical Lifespan
>10 Years in Rated Conditions

Input Type
Digital/Analog via Connector

Operating Temperature Range
0°C to +60°C

Model Number
6SE7021-8TB84-6HF3

Programming
Factory Pre-programmed

Output Type
Digital/Relay (Control Signals)

Storage Temperature Range
-40°C to +85°C

ESD Protection
Onboard ESD Suppressors

About SIEMENS 6SE7021-8TB84-6HF3 PCB CARD

Redeem the full potential of your drive systems with the SIEMENS 6SE7021-8TB84-6HF3 PCB CARDan elite, hot-selling solution revered for its redoubtable reliability and supreme performance. Engineered for plug-in/socket mounting, this original Siemens part is RoHS compliant and field-replaceable, ensuring ease of maintenance. Unbeatable ESD protection and a robust 4-layer, double-sided multilayer design promote a typical lifespan of over 10 years. Compatible with SINAMICS and SIMOREG Inverter Drives, it supports both digital and analog input, delivering efficient, closed-loop control for industrial applications. Secure your operations with this conformal-coated, factory pre-programmed control PCB.

Direction of Use, Commercial Purpose, and Application Type

The SIEMENS 6SE7021-8TB84-6HF3 PCB CARD is designed for seamless plug-in replacement within Siemens SINAMICS or SIMOREG drive inverters. Its usage type is commercial, best suited for industrial automation and drive control environments. Quick installation and auto-detection features empower operators to reduce downtime, while robust construction supports continuous operation. With its double-sided multilayer build, it meets the vigorous demands of motion control, making it a redoubtable component for warehouses, production lines, and automated process plants.

Delivery Time, Export Destinations & Certifications

Boasting agile logistics, the SIEMENS 6SE7021-8TB84-6HF3 PCB CARD is typically delivered within 37 business days at competitive sale prices. Our streamlined export processes facilitate quick dispatch across main export markets including Asia, Europe, and the Middle East. This supreme-grade product adheres strictly to Siemens Industrial Standards and is fully RoHS compliant, assuring regulatory confidence and quality assurance for global customers. Benefit from unmatched reliability and efficiency shipped directly to your commercial doorstep.

FAQs of SIEMENS 6SE7021-8TB84-6HF3 PCB CARD:

Q: How do I install the SIEMENS 6SE7021-8TB84-6HF3 PCB CARD in my inverter system?

A: The PCB card is designed for plug-in/socket mounting, allowing for swift and easy installation. Simply power down your drive, remove the old card, and securely insert the new one into the corresponding socket. Factory pre-programming and auto-detection simplify the process further.

Q: What are the primary commercial uses of this PCB card?

A: This card is primarily used for closed-loop drive control in industrial automation, particularly within Siemens SINAMICS and SIMOREG inverter drives. It is ideal for assembly lines, production plants, and other environments requiring precise and reliable motor control.

Q: When should I consider replacing my current PCB card with the 6SE7021-8TB84-6HF3 model?

A: Replacement is advisable when your existing control card shows malfunction, intermittent failures, or after reaching its typical lifespan of over 10 years under rated conditions. The field-replaceable, robust build ensures minimal downtime during substitution.

Q: Where is the SIEMENS 6SE7021-8TB84-6HF3 PCB CARD typically exported?

A: This product is widely exported across Asia, Europe, and the Middle East, serving various industries that require reliable drive inverter control solutions.

Q: What makes this PCB card supreme for drive control applications?

A: The card features onboard ESD suppressors, conformal coating for protection, a 4-layer PCB structure, and compatibility with a wide range of Siemens drives. These attributes, along with its high reliability and long lifespan, make it an unbeatable choice for demanding operational settings.

Q: How does the pre-programming and control system enhance usage efficiency?

A: Factory pre-programming allows instant deployment without configuration hassles, while its closed-loop control system ensures precise, stable operation of inverter drives, enhancing overall process efficiency.
