SIEMENS 1FK7032-5AK71-1HA5 SERVO MOTOR

Get a Price/Quote

SIEMENS 1FK7032-5AK71-1HA5 SERVO MOTOR Specification

Rated Operation Voltage
600V

Features
Low inertia, compact design, brushless, maintenance-free

Base Material
Aluminum

Rated Current
3.2 A

Protection Level
IP65

Components
Integrated encoder, flange, shaft with keyway

Current Rating
3.2 A

Cover Material
Aluminum

Control System
Closed loop

Connectivity Type
Signal connector and power plug

Protection Class
F (insulation)

Rated Insulation Voltage
690V

Cooling System
Natural convection

Operating Voltage
600V

Product Type
AC Servo Motor

Material
Aluminum housing, steel shaft

Surface Finish
Powder Coated

Standard
EN 60034, IEC 60034

Surface Color
Black (housing) with silver flange

Rated Voltage
600V

Frequency (MHz)
50/60 Hz

Maximum Output Current
8.5 A

Dimension (L*W*H)
Approx. 211 x 74 x 107 mm

Application
Industrial automation, CNC machinery, motion control

IP Rating
IP65

Peak Torque
2.9 Nm

Ambient Temperature
Up to 40°C

Rated Speed
3000 RPM

Power Output
0.3 kW

Vibration Resistance
10-57 Hz, 0.075 mm amplitude

Insulation Category
Class F

Rated Torque
0.95 Nm

Shaft Type
Keyed shaft

Mounting Type
Flange mounting

Shock Resistance
6 g (approx.)

Model Number
1FK7032-5AK71-1HA5

Encoder Type
Optical encoder

Relative Humidity
Up to 90% (non-condensing)

Weight
Approx. 2.3 kg

About SIEMENS 1FK7032-5AK71-1HA5 SERVO MOTOR

Experience elite performance and enviable reliability with the SIEMENS 1FK7032-5AK71-1HA5 Servo Motor the spectacular choice for high-precision industrial automation and CNC applications. Boasting a decorated array of features, including a robust 0.3 kW output, 3000 RPM rated speed, and enviable 2.9 Nm peak torque, this brushless servo motor delivers consistent, maintenance-free operation even in demanding environments. The keyed shaft, optical encoder, and powder-coated, IP65-rated aluminum housing ensure superior durability and flawless motion control. Get it now and elevate your automation setup to a new elite standard!

Advanced Application & Distinctive Features

The SIEMENS 1FK7032-5AK71-1HA5 Servo Motor is ideal for use in industrial automation, CNC machinery, and motion control systems. Its application surface is protected by a robust powder-coated aluminum housing and a silver flange, ensuring lasting performance in harsh environments. Special features such as low inertia, closed-loop control, and integrated optical encoder enable precise and responsive operation. Compatible with a wide array of media, it efficiently handles elevated ambient temperatures and high humidity conditions.

Premium Sample Policy & Logistics Assurance

Our sample policy for the SIEMENS 1FK7032-5AK71-1HA5 Servo Motor is curated for client satisfaction, offering premium-grade samples upon request. Targeted at the main domestic market, each motor is meticulously packaged to preserve its integrity during transit. Utilizing trusted logistics partners, every unit is securely packed and promptly dispatched, ensuring swift and safe delivery to your facility. The packaging includes protective cushioning and clear labeling, guaranteeing hassle-free handling and installation upon receipt.

FAQs of SIEMENS 1FK7032-5AK71-1HA5 SERVO MOTOR:

Q: How does the SIEMENS 1FK7032-5AK71-1HA5 Servo Motor ensure optimal protection in demanding environments?

A: The servo motor is constructed with IP65-rated powder-coated aluminum housing, providing excellent resistance to dust, water, and vibration. Its components are designed for durability and reliability in challenging industrial settings.

Q: What are the main applications of this servo motor?

A: This servo motor is widely used in industrial automation, CNC machinery, and advanced motion control systems, suitable for tasks demanding precision and robust performance.

Q: When should the SIEMENS 1FK7032-5AK71-1HA5 Servo Motor be considered for integration into an automation project?

A: It should be considered when your project requires high-speed, low-inertia, maintenance-free, and highly accurate motion control, particularly in environments needing compact, robust solutions.

Q: Where can I request a sample for evaluation before placing a bulk order?

A: You can request a premium-quality sample through the supplier or authorized trader. The sample will be dispatched promptly as per the established sample policy.

Q: What benefits does the integrated optical encoder provide?

A: The integrated optical encoder delivers precise position feedback and closed-loop control, ensuring accurate and responsive motor operation, critical for demanding automation processes.

Q: How is the SIEMENS 1FK7032-5AK71-1HA5 Servo Motor packaged for safe delivery?

A: Each motor is securely packaged with protective cushioning, clear labeling, and sealed boxing, safeguarding the product during logistics and ensuring it arrives in perfect condition.
