SEMIKRON SKKR300/0.2-BVR IGBT

Get a Price/Quote

SEMIKRON SKKR300/0.2-BVR IGBT Specification

Pole Type
Dual/Parallel Arm

Output
Semiconductor Switching

Features
Rugged Construction, High Power Switching, Fast Switching Speed

Frequency
DC/AC up to 1kHz

IP Rating
Not Rated (Dependent on Enclosure)

Mounting Type
Chassis Mount

Usage & Applications
Power Control, Rectifiers, UPS Systems

Protection Level
Built-in Diode & Overvoltage Protection

Installation Type
Panel Mount

Switch Type
IGBT Transistor

Current
300A

Phase
Suitable for Single & Three Phase Applications

Connectivity Type
Busbar/Terminal Connection

Product Type
Semiconductor Power Module (IGBT)

Operating Temperature
-40C to +125C

Working Temperature
-40C to +125C

Input
Voltage Controlled

Application
Industrial Inverters, Motor Drives, Power Equipment, Welders

Supply Voltage
Up to 1800V

Dimension (L*W*H)
190 mm x 125 mm x 55 mm (approx.)

Weight
~2.1 kg

Collector-Emitter Voltage (Vces)
1800V

Isolation Voltage
4000V AC (RMS) 1 minute

Case Style
SEMIKRON Rectangular Module

RoHS Compliance
Yes

Cooling Method
Forced Air / Heat Sink

Pulse Current
600A (max. pulse)

Configuration
Dual Arm (Parallel)

Part Number
SKKR300/0.2-BVR

Baseplate Material
Copper

About SEMIKRON SKKR300/0.2-BVR IGBT

The SEMIKRON SKKR300/0.2-BVR IGBT is in demand for its opulent, valiant performance and enviable reliability. Favorable reviews highlight its impressive 1800V collector-emitter voltage and robust 300A current handling, catering to high-power industrial demands with significant savings in energy costs. Its copper baseplate ensures efficient thermal management, while the dual arm parallel configuration maximizes switching speed. Integrated overvoltage protection and diode features offer rugged durability, making this module ideal for applications in industrial inverters, motor drives, and welding equipment.

Versatile Application Surface for Industrial Needs

SEMIKRON SKKR300/0.2-BVR IGBT finds enviable use in diverse industrial scenarios such as power control, rectifiers, and UPS systems. It is suitable for both single and three-phase applications, ensuring broad area of operation. Its direction of use includes installation on chassis mount panels, connecting easily with busbars or terminal connections. This flexibility makes it a valiant choice for motor drives, welders, and power equipment, supporting high current and voltage requirements in demanding environments.

Domestic Market Delivery and Packaging Solutions

This IGBT module is supplied across the main domestic market, dispatched promptly upon order confirmation. Express shipping options guarantee quick delivery and reliable service. Each unit is packed securely to prevent transit damage, maintaining opulent product integrity. Supply ability meets large-scale project needs, and favorable sale price enables buyers to enjoy significant savings on bulk purchases. With robust logistics, buyers can count on timely arrival and meticulous packaging to ensure product safety.

FAQs of SEMIKRON SKKR300/0.2-BVR IGBT:

Q: How can the SEMIKRON SKKR300/0.2-BVR IGBT be installed in industrial equipment?

A: The module can be installed using its chassis mount feature, connecting via busbar or terminal connections. This ensures compatibility with various industrial setups requiring panel mounts.

Q: What protection features does the SKKR300/0.2-BVR IGBT offer during operation?

A: It includes built-in diode and overvoltage protection, safeguarding the module and equipment from electrical surges and premature failure, ideal for rugged operating conditions.

Q: Where is the ideal area of application for this IGBT module?

A: The SKKR300/0.2-BVR IGBT excels in industrial inverters, motor drives, UPS systems, welding setups, and power control operations that require high current and voltage reliability.

Q: When is express shipping available for this IGBT module?

A: Express shipping is available for domestic orders upon confirmation, ensuring rapid dispatched deliveries tailored to urgent project timelines.

Q: What are the main benefits of using this SEMIKRON IGBT in power equipment?

A: Users benefit from fast switching speeds, high power handling, robust thermal management, and substantial energy savings, contributing to prolonged equipment life and reduced maintenance.
