SEMIKRON SKIIP 32NAB12T1 IGBT

Get a Price/Quote

SEMIKRON SKIIP 32NAB12T1 IGBT Specification

Mounting Type
Chassis Mount

Phase
Three Phase

Protection Level
Insulated Case

Features
Integrated Driver, Reliable Performance, Compact Design

Usage & Applications
Industrial Automation, AC Motor Control, Renewable Energy

Connectivity Type
Through Hole

Current
32A

Installation Type
Screw Mount

Product Type
IGBT Module

Operating Temperature
-40C to +150C

Working Temperature
-40C to +150C

Application
Industrial Motor Drives, Inverters, Power Supplies

Supply Voltage
1200V

Dimension (L*W*H)
110 mm x 62 mm x 17 mm (approx.)

Weight
Approx. 270g

Cooling Method
Forced Air or Conduction

Gate Emitter Voltage (Vge)
±15V max

Technology
Trench IGBT with fast recovery diode

Package Type
SKIIP

Collector Power Dissipation (Pc)
180W (per module)

Isolation Voltage
3.6kV (RMS)

Collector-Emitter Voltage (Vces)
1200V

Storage Temperature
-40°C to +125°C

Integration
SKIIP - Intelligent Power Module with Driver Electronics

Topology
Half-Bridge

About SEMIKRON SKIIP 32NAB12T1 IGBT

Grab the opportunity to elevate your industrial systems with the SEMIKRON SKIIP 32NAB12T1 IGBT, a pivotal component engineered for sublime efficiency and reliability. Its brilliant half-bridge topology, customizable via advanced trench IGBT technology, offers fast recovery and integrated driver electronics. Rated at 1200V, 32A, and 180W per module, this module excels in harsh environmentsthanks to a wide operating and storage temperature range (up to +150C). Secure yours now; this high-performance, insulated, intelligent power module is ending soon! Ideal for industrial automation, inverters, and renewable energy.

Applications and Usage of SEMIKRON SKIIP 32NAB12T1 IGBT

The SEMIKRON SKIIP 32NAB12T1 IGBT finds its site of application in cutting-edge industrial environments such as AC motor control, industrial automation, and renewable energy systems. Used as a fundamental building block in inverters and power supplies, this module ensures optimal efficiency and robust performance. Application places include industrial motor drives, demanding production lines, and renewable energy plants where stability and precision are crucial, providing essential power conversion in three-phase systems.

FOB Port, Payment Terms, and Sales Details SEMIKRON SKIIP 32NAB12T1 IGBT

The SEMIKRON SKIIP 32NAB12T1 IGBT is available at a competitive sale price with flexible FOB port options for international buyers. Payment terms are designed to facilitate secure and swift transactions, ensuring a smooth procurement process. Packaging is tailored for safe transit, absorbing any charge concerns to safeguard the product. Serving the main domestic market efficiently, this module is promptly dispatched, with each order packaged meticulously to ensure timely and intact delivery.

FAQs of SEMIKRON SKIIP 32NAB12T1 IGBT:

Q: How can the SEMIKRON SKIIP 32NAB12T1 IGBT module be installed?

A: The SEMIKRON SKIIP 32NAB12T1 IGBT is designed for easy screw and chassis mounting with through-hole connectivity, allowing flexible and secure integration into your industrial setups.

Q: What are the main benefits of using this IGBT in industrial systems?

A: By integrating a reliable driver, robust protection, and superior power handling, this module guarantees streamlined energy conversion, reduced downtime, and increased lifespan in complex applications like inverters and automation.

Q: Where is the SEMIKRON SKIIP 32NAB12T1 IGBT predominantly used?

A: It is widely used in industrial motor drives, AC motor control, power supplies, and renewable energy plants requiring insulated, high-efficiency power modules.

Q: What type of cooling method is optimal for this module?

A: The SEMIKRON SKIIP 32NAB12T1 IGBT supports both forced air and conduction cooling methods to maintain optimal operating temperatures and ensure consistent performance.

Q: How does the module ensure safety and reliability during operation?

A: With an insulated case, integrated driver electronics, and a wide operating temperature range, this IGBT module offers enhanced safety and trustworthy performance in demanding industrial environments.
