SEMIKRON SKIIP 23AC12T4V1 IGBT

Get a Price/Quote

SEMIKRON SKIIP 23AC12T4V1 IGBT Specification

Features
SKiiP CoolSiC Hybrid Technology, High Efficiency, Robust Design

Installation Type
Screw Mounting

Switch Type
IGBT Switch

Mounting Type
Chassis Mount

Protection Level
Integrated Protection Features

Current
120A

Phase
Three Phase

Frequency
50/60 Hz

Output
1200V

Connectivity Type
Module Pins / Press-fit

IP Rating
IP00

Usage & Applications
Inverters, UPS Systems, Industrial Automation

Product Type
IGBT Module

Operating Temperature
-40C to +150C

Working Temperature
-40C to +150C

Input
DC

Application
Industrial Motor Drives, Power Supplies, Renewable Energy

Supply Voltage
1200V

Dimension (L*W*H)
163mm x 62mm x 30mm

Weight
950g

Collector-Emitter Voltage (Vce)
1200V

Power Dissipation
675W

Isolation Voltage
2500V rms

Package Type
SKIIP (Integrated Circuit Package)

Gate Drive Voltage
15V

Control Interface
Press-fit Contacts

Short Circuit Withstand Time
10µs

Module Series
SKIIP 23AC Series

Cooling Method
Baseplate, Forced Air or Liquid Cooling

Continuous Collector Current (Ic)
120A

RoHS Compliance
Yes

Module Configuration
3-Phase Bridge

Model Number
SKIIP 23AC12T4V1

About SEMIKRON SKIIP 23AC12T4V1 IGBT

Buy the elite SEMIKRON SKIIP 23AC12T4V1 IGBT module at the lowest price for sterling performance and sought-after reliability. This best-in-class SKIIP 23AC Series features a robust 3-phase bridge configuration, 120A current capability, 1200V collector-emitter voltage, and integrated protection features. Experience advanced SKiiP CoolSiC Hybrid Technology, enhancing efficiency and durability. With IP00 rating, press-fit connectivity, forced air or liquid cooling, and RoHS compliance, this module is an ideal choice for supplier and trader needs in industrial motor drives, power supplies, and renewable energy applications. Secure your module today!

Versatile Applications and User Groups

The SEMIKRON SKIIP 23AC12T4V1 IGBT module is specifically engineered for use in inverters, UPS systems, and automation machinery. It provides stable power control for industrial motor drives and renewable energy systems, serving manufacturers, automation technicians, and electrical engineers. Its general-purpose design allows for seamless integration in both specialized setups and general industrial infrastructure.

Domestic and Export Market Solutions

We offer express shipping, careful packing & dispatch, and reliable goods transport for the SEMIKRON SKIIP 23AC12T4V1 IGBT. Samples are available for quality verification across our main domestic markets. With a strong main export market presence, international clients benefit from efficient supply chains and prompt delivery, ensuring products reach you securely and in pristine condition.

FAQs of SEMIKRON SKIIP 23AC12T4V1 IGBT:

Q: How is the SEMIKRON SKIIP 23AC12T4V1 IGBT module typically used?

A: This module is commonly implemented in industrial motor drives, power supplies, UPS systems, and renewable energy installations, ensuring robust and efficient power switching in three-phase applications.

Q: What are the benefits of SKiiP CoolSiC Hybrid Technology in this IGBT module?

A: The SKiiP CoolSiC Hybrid Technology boosts efficiency, ensures lower energy losses, and provides a robust design that supports higher operating temperatures and extended reliability, making it highly sought-after in demanding environments.

Q: Where can I install the SKIIP 23AC12T4V1 module and what is its mounting type?

A: The module is designed for chassis mounting using screw installation, making it easy to integrate into various industrial setups requiring three-phase bridge configurations.

Q: What protection features are provided with the SEMIKRON SKIIP 23AC12T4V1?

A: Integrated protection features include short circuit withstand capability, IP00 rating, and robust insulation, ensuring equipment safety and module longevity under rigorous operating conditions.

Q: How can a trader or supplier acquire sample units for quality verification?

A: Sample units are available upon request. Suppliers and traders can contact our sales team to arrange express shipping and secure packaging for prompt sample delivery.

Q: When should forced air or liquid cooling be used with this IGBT module?

A: Forced air or liquid cooling should be employed in high-power applications where optimal heat dissipation is necessary to maintain reliability and maximize efficiency during continuous operation.
