SEMIKRON SKIIP 23AC126V1 IGBT

Get a Price/Quote

SEMIKRON SKIIP 23AC126V1 IGBT Specification

Mounting Type
Chassis Mount

Output
Inverter Output, AC

Frequency
Up to 20kHz (switching frequency)

Installation Type
Screw Mount / Module Mount

Phase
Three Phase

Switch Type
IGBT Module

Connectivity Type
Screw Terminal

Usage & Applications
Frequency Converters, UPS, Power Control Units

Current
126A

Features
PressPack Module, fast switching, high reliability

Protection Level
Integrated Protection (Short circuit, Over-temperature)

Product Type
IGBT Power Module

Operating Temperature
-40C to +150C

Working Temperature
-40C to +150C

Input
DC

Application
Industrial Drives, Inverters, Motor Control

Supply Voltage
1200V

Dimension (L*W*H)
132 mm x 62 mm x 30 mm (approx.)

Weight
Approx. 400g

RoHS Compliant
Yes

Thermal Resistance
0.065 K/W (junction-case)

Technology
SKIIP 23 series, SEMITRANS Classic

Package Type
SKIIP23AC126V1, Module

Control Interface
Digital

Collector-Emitter Voltage (Vces)
1200V

Isolation Voltage
2500 V RMS (input to output)

Gate Charge
Low gate charge for efficient switching

Integrated Driver
Yes, built-in gate driver

About SEMIKRON SKIIP 23AC126V1 IGBT

Last Chance to grab your must-have SEMIKRON SKIIP 23AC126V1 IGBT Modulea top-drawer solution for industrial power conversion. This world-class SKIIP 23 series SEMITRANS Classic device offers superlative performance with a 1200V collector-emitter voltage and a current rating of 126A. The integrated driver and advanced protection features make installation and operation seamless. RoHS compliant, with superb thermal resistance and low gate charge for fast, efficient switching. Perfect for frequency converters, UPS, and industrial motor controlthis superior IGBT is built for reliability and exceptional results.

Versatile Applications & Usage Options

The SEMIKRON SKIIP 23AC126V1 IGBT stands out for its broad application surface in industrial drives, inverters, and motor controls. Designed for frequency converters, power control units, and UPS systems, its integrated protection ensures high reliability. Ideal for both factory automation and power electronics, this module offers flexible usage typeswhether for continuous operation, demanding switching environments, or robust control solutionsdelivering consistent performance in challenging conditions.

Supply Ability & Order Processing Details

Our supply ability ensures rapid order processing for the SEMIKRON SKIIP 23AC126V1 IGBT module. Orders ship from prominent FOB ports with attractive rate options tailored to your location. Freight charges are competitive, and payment terms are flexible to suit various procurement needs. Rest assured that your request will be handled efficiently, ensuring prompt delivery and reliable support for bulk and repeat orders. Connect with us today to secure your module.

FAQs of SEMIKRON SKIIP 23AC126V1 IGBT:

Q: How does the SEMIKRON SKIIP 23AC126V1 benefit industrial applications?

A: The module provides reliable switching, advanced protection, and integrated driver functionality, making it ideal for industrial drives, inverters, and motor control, ensuring efficient energy conversion and operational safety.

Q: What is the process for installing the SEMIKRON SKIIP 23AC126V1 IGBT?

A: Installation is straightforwardutilizing screw or module mount options and screw terminal connectivity. The integrated protection and driver simplify configuration and commissioning in your system.

Q: Where can the SEMIKRON SKIIP 23AC126V1 IGBT be used?

A: This module is suitable for applications such as frequency converters, UPS systems, motor controls, and power control units across various industrial environments.

Q: When is it recommended to use the SKIIP 23AC126V1 for switching applications?

A: It is recommended for operations requiring fast, efficient switching at up to 20kHz, high current handling up to 126A, and robust protection against short circuits and over-temperature risks.

Q: What payment and shipping terms are available for this module?

A: Flexible payment terms are offered, including options for competitive rates. Orders are shipped via prominent FOB ports with calculated freight charges to ensure cost-effective delivery.

Q: How can buyers ensure optimal performance of the SEMIKRON SKIIP 23AC126V1?

A: By following recommended installation guidelines, maintaining appropriate ambient conditions, and utilizing its built-in protections, buyers can maximize operational reliability and performance.
