SEMIKRON SKIIP 04NAD12V1 IGBT

Get a Price/Quote

SEMIKRON SKIIP 04NAD12V1 IGBT Specification

Features
Integrated driver, compact design, high efficiency

Output
Dual IGBT with integrated drivers

IP Rating
IP00

Connectivity Type
PCB/Screw Terminals

Usage & Applications
AC Motor Drives, UPS, Renewable Energy Systems

Switch Type
IGBT Switch

Mounting Type
Baseplate Mount

Current
20A

Installation Type
Screw Mount

Frequency
50/60 Hz

Phase
Three-Phase Applications

Protection Level
Built-in protection features

Product Type
IGBT Power Module

Operating Temperature
-40C to +125C

Working Temperature
-40C to +125C

Input
VGE (Gate-Emitter Voltage): +/-20V max

Application
Industrial Inverter, Motor Drives, Power Supplies

Supply Voltage
1200V (Vces) max

Dimension (L*W*H)
73 mm x 55 mm x 20 mm (approx.)

Weight
Approx. 160 g

About SEMIKRON SKIIP 04NAD12V1 IGBT

Buy the SEMIKRON SKIIP 04NAD12V1 IGBT Module and access laureate-level performance for demanding industrial applications. This first-class dual IGBT, with integrated isolated drivers, offers sterling efficiency at a collector-emitter voltage of 1200V and collector current of 20A. Designed for robust protection and high thermal stability, its compact SKIIP module supports easy screw or PCB mounting. This module is ideal for three-phase inverters, renewable energy, UPS, and motor drives. Secure this advanced, high-reliability IGBT for uncompromised, efficient power delivery in modern industrial contexts.

Exemplary Usage and Competitive Advantages

The SEMIKRON SKIIP 04NAD12V1 IGBT suits critical roles in industrial inverters, AC motor drives, UPS, and renewable energy systems. Its primary competitive edge is the sterling dual IGBT configuration paired with an integrated isolated driver, enabling compact design and exceptional efficiency. Laureate by design, it delivers thermal resilience and built-in protection, ensuring longevity and reliability in demanding environments. This module is tailored for applications requiring consistent performance and robust protection under diverse temperature and voltage conditions.

Export Markets, Sample Policy, and Order Security

We offer the SEMIKRON SKIIP 04NAD12V1 IGBT to a broad range of international markets. Customers can access sample units upon request, making it easier to evaluate quality before a bulk order. Secure shipping and transparent payment terms provide assurance throughout the order completion process. Our team ensures each transaction is managed smoothly, supporting clients from inquiry to delivery for a seamless buying experience in both domestic and export markets.

FAQs of SEMIKRON SKIIP 04NAD12V1 IGBT:

Q: How can the SEMIKRON SKIIP 04NAD12V1 IGBT enhance my industrial application?

A: The integrated driver and sterling efficiency of the SKIIP 04NAD12V1 IGBT provide robust, reliable power delivery for applications such as industrial inverters, AC motor drives, and renewable energy systems, ensuring longevity and high performance.

Q: What competitive advantages does this IGBT module offer?

A: This IGBT module combines first-class dual configuration, integrated isolation driver, high thermal resilience, and built-in protection features, making it ideal for demanding environments where both efficiency and safety are crucial.

Q: When should I use the SKIIP 04NAD12V1 IGBT in my design?

A: Choose this module when your application requires high voltage (up to 1200V), consistent 20A current, compact size, secure mounting, and integrated driver circuitry for efficiency and ease of installation.

Q: Where is the SEMIKRON SKIIP 04NAD12V1 IGBT most effectively deployed?

A: It is most effectively used in three-phase industrial systems such as AC motor drives, UPS solutions, power supplies, and renewable energy installations where reliable, high-efficiency switching is essential.

Q: What are the main export markets and how is order completion managed?

A: We offer this IGBT module globally, providing secure shipping and various payment terms to ensure a safe, smooth order completion process in both domestic and international transactions.
