SCHNEIDER ELECTRIC TSXDEY32D2K DISCRETE INPUT MODULE

Send Inquiry

Request To Call Back

SCHNEIDER ELECTRIC TSXDEY32D2K DISCRETE INPUT MODULE

Get a Price/Quote

MOQ : 100 Pieces

SCHNEIDER ELECTRIC TSXDEY32D2K DISCRETE INPUT MODULE Specification

Way
32 channels

Control System
Compatible with TSX Premium PLC

Features
Direct mounting, LED indicators, fast response time

Cooling System
Natural air cooling

Base Material
Plastic

Protection Class
Class II

Cover Material
Plastic

Rated Current
Nominal 5 mA per channel

Connectivity Type
Removable connectors

Rated Insulation Voltage
500 V AC

Components
Module with removable spring-type terminal block

Rated Operation Voltage
24 V DC

Thickness
Standard module profile

Operating Voltage
24 V DC

Protection Level
IP20

Current Rating
5 mA per channel

Panel Type
DIN rail mount

Product Type
Discrete Input Module

Material
Industrial-grade plastic housing

Surface Finish
Matte

Standard
IEC 61131-2

Surface Color
Grey

Rated Voltage
24 V DC

Maximum Output Current
N/A (Input module)

Dimension (L*W*H)
125 x 32 x 120 mm

Application
Industrial automation, PLC systems

IP Rating
IP20

Display Type
Status LED for each input

Operating Temperature
0 to 60°C

Vibration Resistance
1.5 mm peak to peak, 10 to 57 Hz; 2 gn, 57 to 150 Hz

Standards Compliance
CE, UL, CSA

Power Consumption
2.7 W

Model Number
TSXDEY32D2K

Wiring Type
Removable terminal block

Storage Temperature
-25 to 70°C

Response Time
< 5 ms

Weight
Approx. 0.3 kg

Number of Inputs
32

Module Format
Standard

Mounting Type
DIN rail

Input Voltage Range
19.2 to 30 V DC

Relative Humidity
5% to 95% (non-condensing)

Input Type
Sink/Source (positive or negative logic)

About SCHNEIDER ELECTRIC TSXDEY32D2K DISCRETE INPUT MODULE

Redeem unparalleled value with the SCHNEIDER ELECTRIC TSXDEY32D2K Discrete Input Module, engineered for pivotal industrial automation needs. With masterful integration, this module offers 32 channels, handling both sink/source logic, and delivers rapid <5 ms response time. The IP20-rated, industrial-grade plastic housing and DIN rail mounting ensure adaptable deployment. Now available with a significant price cut in our current promotion, its removable terminal block enhances maintenance efficiency. Experience incomparable reliability, certified to CE, UL, and CSA standards, making it indispensable for robust PLC system applications across diverse industrial sectors.

Application Areas and Usage Suitability

The SCHNEIDER ELECTRIC TSXDEY32D2K Discrete Input Module excels in extensive industrial environments such as manufacturing plants, process automation, and control panels. Its 32-channel design, fast response time, and DIN rail mounting make it an optimal choice for PLC systems and automation architectures. This module is suitable for industries seeking robust, scalable, and reliable input solutions where precise monitoring and seamless integration are pivotal to operations.

Certifications, Domestic Market and Sample Policy

Certified for CE, UL, and CSA standards, the SCHNEIDER ELECTRIC TSXDEY32D2K is ideal for use across the main domestic markets in India. Each module is carefully packaged for safe dispatching, ensuring quality upon arrival. Upon request, we provide detailed quotations and can support sample policies to meet project evaluation needs. Expect prompt dispatching and professional service from order placement to delivery, ensuring efficiency and satisfaction.

FAQs of SCHNEIDER ELECTRIC TSXDEY32D2K DISCRETE INPUT MODULE:

Q: How does the TSXDEY32D2K module benefit industrial automation systems?

A: The TSXDEY32D2K provides rapid input scanning with less than 5 ms response time, ensuring timely data processing for industrial automation and offering LED status indicators for ease of monitoring.

Q: What input types and voltage ranges are supported by this module?

A: This module supports both sink and source (positive or negative logic) configurations with an input voltage range of 19.2 to 30 V DC, suitable for varied automation environments.

Q: Where can the TSXDEY32D2K Discrete Input Module be installed?

A: It is designed for direct DIN rail mounting in control panels, PLC cabinets, and automation systems within manufacturing, process industries, and other industrial automation setups.

Q: What is the process for obtaining a quotation and sample unit?

A: To receive a quotation or request a sample unit, contact our sales team or authorized trader in India. Our team will provide detailed pricing, packaging information, and dispatching timelines tailored to your requirements.

Q: Is the TSXDEY32D2K module compliant with industrial standards and suitable for the Indian market?

A: Yes, it is compliant with CE, UL, CSA, and the IEC 61131-2 standard, making it suitable and safe for diverse industrial applications throughout the Indian domestic market.
