SCHNEIDER ELECTRIC BMXART0814 ISOLATED INPUT MODULE

Send Inquiry

Request To Call Back

SCHNEIDER ELECTRIC BMXART0814 ISOLATED INPUT MODULE

Get a Price/Quote

SCHNEIDER ELECTRIC BMXART0814 ISOLATED INPUT MODULE Specification

Cabinet Material
Not applicable (for PLC rack mount)

Components
Input module with terminal blocks

Protection Level
Up to IP20

Rated Current
10 mA per channel

Rated Operation Voltage
24 V DC

Cover Material
Polycarbonate

Cooling System
Natural convection

Way
8 Channels

Thickness
Standard module thickness

Features
Isolated channels, diagnostic LEDs, compatible with Modicon X80

Protection Class
Class II

Rated Insulation Voltage
500 V AC/DC

Control System
Modicon X80 Automation Platform

Current Rating
10 mA per channel

Operating Voltage
24 V DC

Base Material
Polycarbonate

Panel Type
Modular PLC Mount

Connectivity Type
Backplane connection

Product Type
Isolated Analog Input Module

Material
Plastic and electronic components

Surface Finish
Matte

Standard
IEC 61131-2

Surface Color
Grey

Rated Voltage
24 V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
Not Applicable (Input Module)

Dimension (L*W*H)
32 x 100 x 110 mm (approx.)

Application
Industrial Automation, Process Control

IP Rating
IP20

Display Type
LED Indicators

Storage Temperature Range
-40°C to 85°C

Weight
210 g (approx.)

Number of Inputs
8 analog inputs, isolated

Isolation Voltage
500 V between channels and ground

Response Time
3 ms

Mounting Type
DIN rail or rack mount

Operating Temperature Range
0°C to 60°C

Power Dissipation
4.2 W

Relative Humidity
10% to 95% (non-condensing)

Input Type
Current and Voltage (0-20mA, 4-20mA, 0-10V, -10 to +10V)

Environmental Protection
RoHS compliant

Module Code
BMXART0814

About SCHNEIDER ELECTRIC BMXART0814 ISOLATED INPUT MODULE

Explore the dazzling performance of the SCHNEIDER ELECTRIC BMXART0814 ISOLATED INPUT MODULE, the sought-after solution for industrial automation and process control. Featuring 8 soaring analog inputs, each isolated for reliable current and voltage measurements (0-20mA, 4-20mA, 0-10V, -10 to +10V), this robust module boasts a 500V isolation voltage and fast 3ms response. Crafted with RoHS compliant polycarbonate, its modular, rack-mountable form seamlessly integrates with Modicon X80. Pick yours online today and experience supreme operational assurance in demanding industrial environments.

Key Advantages and Material Features

The SCHNEIDER ELECTRIC BMXART0814 ISOLATED INPUT MODULE stands out with isolated channels for exceptional noise immunity and safety. Built from durable, RoHS-compliant polycarbonate, it adapts seamlessly to industrial automation and process control media. Its robust design ensures reliable operation in challenging environments, meeting rigorous IEC 61131-2 standards. The units diagnostic LEDs and compatibility with the Modicon X80 platform make it a primary choice for engineers seeking efficiency, resilience, and advanced troubleshooting features.

Global Shipment and Order Fulfillment

Experience prompt shipment and streamlined order completion for the SCHNEIDER ELECTRIC BMXART0814 ISOLATED INPUT MODULE. Secure, export-compliant packaging ensures safe delivery to global markets. Whether youre inquiring about the asking price or tracking your order, our supplier and trader network across India and international markets guarantees timely dispatch. With robust logistics support, you can confidently place your order, knowing your automation investment will arrive in optimal condition and on schedule.

FAQs of SCHNEIDER ELECTRIC BMXART0814 ISOLATED INPUT MODULE:

Q: How does the SCHNEIDER ELECTRIC BMXART0814 ensure input isolation and safety?

A: The BMXART0814 features individual channel isolation up to 500 V, which minimizes interference and ensures safety by separating each analog input from ground and other channels.

Q: What types of signals can this module handle?

A: This module supports 8 analog inputs and is compatible with both current (020mA, 420mA) and voltage (-10 to +10V, 010V) signals, making it versatile for various industrial applications.

Q: Where is the SCHNEIDER ELECTRIC BMXART0814 typically used?

A: It is widely applied in industrial automation and process control environments, especially where reliable, high-speed data collection and isolation are invaluable.

Q: What are the material and environmental protection features?

A: The main structure uses RoHS-compliant polycarbonate, with a matte, grey finish and an IP20 protection level, ensuring durability and environmental safety in industrial settings.

Q: How can I place an order and what is the delivery process?

A: You can buy online or contact suppliers and traders in India and globally. Upon order completion, secure packaging and rapid shipment are arranged, ensuring prompt delivery.
