SCHNEIDER ELECTRIC ATV12H075M2 VARIBLE SPEED DRIVES

Send Inquiry

Request To Call Back

SCHNEIDER ELECTRIC ATV12H075M2 VARIBLE SPEED DRIVES

Get a Price/Quote

SCHNEIDER ELECTRIC ATV12H075M2 VARIBLE SPEED DRIVES Specification

Operating Temperature
-10C to +50C (with derating above 50C)

Power Supply
Single phase 200-240V AC, 50/60Hz

Connector Type
Screw terminal

Features
Compact size, integrated EMC filter, user-friendly keypad, energy saving, analog and digital input/output, Modbus communication

Output Type
3-phase AC

Current Range
0.7 A to 4.2 A

Power Factor
>=0.96

Working Temperature
-10C to +50C (without derating)

Rated Current
4.2 A

Cooling Method
Natural convection

Output Current
4.2 A

Phase
Single phase (input), Three phase (output)

Rated Power
0.75 kW

Noise Level
<60 dB

Application
Industrial motor control, conveyors, pumps, fans

Product Type
Variable Speed Drive (AC Drive)

Output Power
0.75 kW (1 HP)

Output Frequency
0.5 to 400 Hz

Input Voltage
200-240V AC

Voltage Protection
Integrated overvoltage/undervoltage protection

Efficiency
98% at full load

Material
Plastic enclosure with aluminum heat sink

Line Regulation
Typically <1%

Storage Temperature
-25C to +70C

Weight
1.1 kg

Relative Humidity
5% to 95% (non-condensing)

Mounting Type
Wall or panel mounting

Motor Compatibility
Asynchronous 3-phase motors

Degree of Protection
IP20

Braking Unit
Integrated (optional external resistor possible)

EMC Filter
Integrated according to IEC/EN 61800-3 C1

Control Method
V/F (Voltage/Frequency) and sensorless flux vector control

Display Type
LED display with keypad

Control Interface
Modbus RTU, logic inputs, analog/digital input/output

Altitude
Up to 1000m without derating (above 1000m derating applies)

About SCHNEIDER ELECTRIC ATV12H075M2 VARIBLE SPEED DRIVES

Experience top-tier motor control with the SCHNEIDER ELECTRIC ATV12H075M2 Variable Speed Drive. Designed with integrated EMC filter and user-friendly keypad, it provides efficient, affordable, and reliable performance for industrial motor control. This compact drive receives favorable reviews for its versatility, available in wall or panel mounting options. With lustrous LED display, majestic efficiency up to 98% at full load, and multiple protection features, it ensures personalized solutions for conveyors, pumps, and fans. Easy Modbus RTU integration and broad analog/digital IO compatibility make it a preferred choice for suppliers and traders across India.

Applications and Special Features

The SCHNEIDER ELECTRIC ATV12H075M2 Variable Speed Drive excels in diverse industrial plant applications such as conveyor systems, pumps, and fans. Its compact size, robust voltage/frequency and sensorless flux vector control, along with an integrated braking unit ensure optimal performance under demanding conditions. The drive boasts a majestic LED display with keypad and supports installation in both wall and panel mounting sites, adapting seamlessly to varied operational environments.

Payment Terms, Dispatch & Export Markets

Flexible payment terms are available with special attention to prompt packing and dispatch processes. Each SCHNEIDER ELECTRIC ATV12H075M2 Variable Speed Drive is securely packed and swiftly dispatched to fulfill domestic and international supply demands. The sample policy caters to the discerning requirements of clients, ensuring satisfaction before purchase. Major export markets include Asia, Middle East, Africa, and Europe, making it an internationally trusted solution for top-tier motor control.

FAQs of SCHNEIDER ELECTRIC ATV12H075M2 VARIBLE SPEED DRIVES:

Q: How is the SCHNEIDER ELECTRIC ATV12H075M2 Variable Speed Drive typically used in industrial applications?

A: The ATV12H075M2 is commonly used for controlling the speed and torque of asynchronous 3-phase motors in applications like conveyors, pumps, and fans, helping optimize energy usage and equipment lifespan.

Q: What are the main benefits of using this variable speed drive?

A: Users benefit from energy savings, improved process control, reduced machinery wear, and integrated features such as EMC filter, compact design, and a user-friendly LED display with keypad interface.

Q: Where can the ATV12H075M2 be installed?

A: It supports both wall and panel mounting, providing flexibility for different site requirements and ensuring adaptability across a variety of plant setups.

Q: What payment and supply options are offered for this product?

A: Flexible payment methods are available, and the drives are carefully packed and dispatched to ensure safe and timely delivery. Sample policies are also available for evaluation before committing to larger orders.

Q: How is the product protected during operation and under challenging environmental conditions?

A: It features integrated overvoltage and undervoltage protection, a robust plastic enclosure with an aluminum heat sink, and operates reliably across wide temperature and humidity ranges, with derating applied above certain thresholds.

Q: What special features enhance the personalization and user experience of this variable speed drive?

A: Personalization is enhanced with Modbus communication, a user-friendly keypad, various logic and analog inputs and outputs, and configuration options that can be tailored to specific process requirements.
