Schneider Analog Input Module Twdami8ht

Get a Price/Quote

Schneider Analog Input Module Twdami8ht Specification

Operating Temperature
0°C to 55°C

Humidity %
10% to 95% (non-condensing)

Feature
8-channel analog input, hot swap, diagnostics LED

Shape
Rectangular

IP Rating
IP20

Connector Type
Removable terminal blocks

Mounting Type
DIN Rail Mounting

Efficiency
High signal accuracy

Insulation Material
Plastic

Overheating Protection
NO

Surface Finish
Matte finish

Product Type
Analog Input Module

Application
PLC Automation Systems, Industrial Control

Protection Level
CE, UL, CSA certified

Frequency (MHz)
50/60 Hz

Rated Voltage
24 V DC

Energy Consumption
1.3 W max

Color
Grey

Dimension (L*W*H)
72 x 32 x 70 mm

Weight
0.11 kg

Size
Compact module

Input Voltage
24 V DC

Connection Type
Removable spring terminal block

Material
Plastic (housing), electronic components

Diagnostics
Channel status LED indication

Number of Analog Inputs
8 inputs

Response Time
< 15 ms

Resolution
12 bits

Storage Temperature
-20°C to +70°C

Compatible Series
Twido PLCs (Modicon Twido)

Input Type
Voltage (0 to 10 V) / Current (4 to 20 mA)

Relative Humidity
10% to 95% (operation/storage)

Isolation
Galvanic isolation between channels and bus

Schneider Analog Input Module Twdami8ht About

Discover the Schneider Analog Input Module Twdami8hta rare and highly sought-after addition for industrial control systems. With eight inputs supporting both voltage (010 V) and current (420 mA), this modular device delivers astonishing 12-bit signal resolution and classic reliability through galvanic isolation. Its compact, rectangular, matte-finished plastic housing ensures durability, while diagnostic LEDs provide instant channel status. Certified for CE, UL, and CSA standards, this module offers unprecedented efficiency and is effortlessly compatible with Twido PLCs. Enhance your automationadd this ephemeral but classic asset to your cart today!

Engineered for Versatility: Applications and Media

The Schneider Analog Input Module Twdami8ht is ideally suited for PLC automation systems in industrial environments. Its robust design and IP20 rating ensure protection during applications involving voltage or current signals, making it suitable across various industrial media. The matte-finished, compact surface effortlessly integrates with Twido PLCs, and DIN rail mounting allows installation on multiple surfaces within control cabinets. Experience seamless compatibility and reliable performance in automation and control projects.

Transparent Transactions: Payment, Supply, and Sample Policies

Acquiring the Schneider Analog Input Module Twdami8ht is straightforward. We offer a variety of payment terms and consistently strive for the lowest price for our clients. Efficient goods transport ensures the swift handover of your order, while strong supply ability guarantees product availability even for large-scale projects. For added confidence, samples are available upon request to experience the classic performance and quality before finalizing your purchase.

FAQs of Schneider Analog Input Module Twdami8ht:

Q: How does the Schneider Twdami8ht module ensure high signal accuracy during operation?

A: Thanks to 12-bit resolution and galvanic isolation between channels and the communication bus, the Twdami8ht module provides reliable, high-precision analog input readings essential for demanding industrial processes.

Q: What types of analog signals are supported by this input module?

A: The Schneider Twdami8ht accommodates both voltage (0 to 10 V) and current (4 to 20 mA) input signals, making it versatile for various automation and industrial applications.

Q: Where can the Schneider Analog Input Module Twdami8ht be installed?

A: This module is suitable for installation in control panels, typically mounted on a DIN rail within industrial automation systems. Its compact dimensions facilitate easy integration in limited spaces.

Q: What are the main benefits of using diagnostic LED indication?

A: Diagnostic LEDs allow for instant status monitoring of individual input channels, helping operators swiftly identify and troubleshoot issues for continuous operational efficiency.

Q: Is there a process to request a sample before making a bulk purchase?

A: Yes, samples are available upon request. You can contact the supplier or trader for further details on sample provision, ensuring confidence before committing to larger orders.
