RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX ETHERNET SWITCH

Send Inquiry

Request To Call Back

RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX ETHERNET SWITCH

Get a Price/Quote

MOQ : 1 Piece

RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX ETHERNET SWITCH Specification

Way
Unmanaged

Thickness
Compact Form Factor

Protection Class
Industrial Grade

Cooling System
Fanless

Cabinet Material
Metal

Protection Level
High Immunity to EMI/RFI

Features
Rugged fanless design, Extended temperature range, High EMI immunity, Wide operating voltage, DIN rail mounting

Base Material
Metal

Operating Voltage
24-48 VDC

Rated Operation Voltage
24-48 VDC

Panel Type
DIN Rail Mount

Rated Insulation Voltage
500 V

Cover Material
Metal

Connectivity Type
8x 10/100BaseTX Ethernet Ports

Components
Switch Unit, Terminal Block, Mounting Accessories

Control System
Unmanaged Ethernet Switching

Product Type
Industrial Ethernet Switch

Material
Industrial Grade Metal

Surface Finish
Powder Coated

Standard
IEEE 802.3, 802.3u, 802.3x

Surface Color
Black

Rated Voltage
24-48 VDC

Dimension (L*W*H)
66 x 164 x 120 mm

Application
Substations, Industrial Automation, Transportation Networks

IP Rating
IP30

Display Type
LED Status Indicators

Vibration/Shock Resistance
IEC 60068-2-6 / IEC 60068-2-27

Enclosure Type
Rugged metal, fanless

Number of Ports
8x 10/100BaseTX

Power Consumption
Maximum 7W

Weight
Approx. 1.2 kg

Warranty Type
Manufacturer Warranty

Operating Temperature Range
-40C to +85C

Mounting
DIN Rail

Compliance
IEEE 1613, IEC 61850-3

LED Indicators
Power, Link/Activity

Input Voltage Range
24-48 VDC dual input

Redundancy Support
No

Relative Humidity
5% to 95% (non-condensing)

Management
Unmanaged

About RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX ETHERNET SWITCH

Grab Yours today-the Top-rated RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX Ethernet Switch, the pivotal choice for industrial-grade networking. This fresh, unrivaled switch boasts eight 10/100BaseTX ports, high EMI/RFI immunity, and a rugged, fanless metal enclosure with IP30 protection. Valuable for extreme environments, its wide temperature range (-40C to +85C) and DIN rail mounting ensure easy installation. With minimal power consumption (max 7W), IEEE 1613/IEC 61850-3 compliance, and premium build, this switch is indispensable for substations, automation, and transportation networks.

Exceptional Performance in Industrial Applications

The RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX Ethernet Switch is engineered for plant applications requiring consistent uptime and resilience. With its compact form factor and robust metal housing, the switch seamlessly integrates into industrial automation systems. It is specifically designed for DIN rail mounting, delivering optimal space usage. The powder-coated black surface finish not only adds durability but also blends effortlessly into plant infrastructure. Its unmatched heat, vibration, and EMI protection support reliable operation in harsh environments.

Premium Logistics, Packaging, and Affordable Payment

Benefit from our premium sample policy and meticulous packaging details, ensuring your RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX Switch is safely delivered during transportation. Our packaging safeguards the product's integrity with every shipment. Take advantage of flexible payment terms, securing top-tier industrial equipment at the lowest price. Experience streamlined procurement with reliable supply, fast order processing, and comprehensive support. Each switch is crafted and handled to meet rigorous standards, providing excellent value for suppliers, traders, and end-users in India.

FAQ's of RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX ETHERNET SWITCH:

Q: How does the RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX withstand extreme environmental conditions?

A: The switch is built with a rugged, industrial-grade metal enclosure and operates efficiently in temperatures ranging from -40C to +85C. It also meets IEC 60068-2-6/27 standards for vibration and shock resistance, and complies with IP30 protection, making it highly reliable in harsh environments.

Q: What are the primary applications of this Ethernet switch?

A: This model is specifically designed for demanding sectors such as substations, industrial automation, and transportation networks, where robust networking and uninterrupted performance are pivotal.

Q: When should I consider using an unmanaged Ethernet switch like this one?

A: Use an unmanaged switch like the RUGGEDCOM RS900NC-HI-D-TX-TX-00-XX when simplicity, reliability, and plug-and-play installation are needed. It's ideal for settings where minimal configuration and management are required, ensuring efficient network connectivity.

Q: Where can this switch be installed for optimal performance?

A: Thanks to its compact, DIN rail-mountable design, the switch installs effortlessly in industrial cabinets, control panels, and onsite enclosures where space and durability are essential.

Q: What benefits does the fanless design provide?

A: The fanless design eliminates moving parts, reducing maintenance needs and enhancing longevity. This results in quieter operation and increased reliability, especially in environments prone to dust and temperature extremes.

Q: How is the product packaged for transportation and delivery?

A: Each switch is packed securely with protective materials to prevent transit damage. Our careful packaging ensures the unit arrives in premium condition, ready for immediate installation.
