PEPPERL FUCHS KFD2-SD-EX1.48-90A SWITCH AMPLIFIER

Get a Price/Quote

PEPPERL FUCHS KFD2-SD-EX1.48-90A SWITCH AMPLIFIER Specification

Features
Galvanic isolation, LED indication, SIL 2, compact design

Current
Up to 35 mA per channel

Switch Type
Switch Amplifier Interface Module

Sensor Type
Proximity sensor, switch contact

Connectivity Type
Screw terminals

IP Rating
IP20

Frequency
Signal frequency 0 to 2.5 kHz

Installation Type
DIN Rail Mounting

Display
LED indication (yellow for channel, green for power)

Usage & Applications
Signal interface between field device and control system in hazardous areas

Mounting Type
DIN Rail

Output
Relay (SPDT) or transistor output, passive

Protection Level
Intrinsic Safety (Ex ia)

Product Type
Switch Amplifier

Operating Temperature
-20C to +60C

Working Temperature
-20C to +60C

Input
NAMUR input, according to EN 60947-5-6

Application
For use with intrinsically safe applications in hazardous areas (zone 2, 22)

Supply Voltage
48 V DC (40 V ... 90 V DC, max. 100 mA)

Dimension (L*W*H)
115 mm x 12.5 mm x 128 mm

Weight
Approx. 120 g

About PEPPERL FUCHS KFD2-SD-EX1.48-90A SWITCH AMPLIFIER

Select the trending PEPPERL FUCHS KFD2-SD-EX1.48-90A Switch Amplifier for signal interfacing in hazardous zones. Redeem unbeaten reliability with its compact, polished polyamide housing, delivering a switch amplifier refined for safety and performance. This single-channel solution handles up to 1.5A load current, with a wondrous response time under 10 ms for precise signal operations. With LED indicators, galvanic isolation, and SIL 2 compliance, this interface module offers a seamless, safe, and trustworthy connection between field devices and control systemsmaking it a top choice for demanding industrial applications.

Outstanding Features and Application Guidance

The KFD2-SD-EX1.48-90A offers exceptional galvanic isolation and compact design, ideal for demanding environments. Simply mount on a DIN rail and connect using screw terminals. For optimal results, follow the clear LED indications and ensure installation within the ambient temperature range. This device suits various applications, especially signal interfacing between field instruments and control systems in hazardous areas. It supports fast response and reliable operation, making it a preferred solution for modern industrial facilities.

Certifications, Export Markets, and Shipping Details

PEPPERL FUCHS KFD2-SD-EX1.48-90A comes certified for intrinsic safety (Ex ia) and SIL 2, meeting international standards. Export markets span Europe, Asia, and the Middle East, strengthening its global presence. Estimate delivery timelines and request a quotation through authorized suppliers. Packaging is meticulously designed for maximum protection. FOB ports include major Indian sea and air terminals, ensuring efficient and reliable shipping to your facility or construction site.

FAQs of PEPPERL FUCHS KFD2-SD-EX1.48-90A SWITCH AMPLIFIER:

Q: How do I install the PEPPERL FUCHS KFD2-SD-EX1.48-90A Switch Amplifier?

A: Install the device onto a DIN rail using the designated mounting system and connect the wiring via the removable screw terminal blocks. Ensure the environment temperature remains within -20C to +60C for optimal performance.

Q: What are the main benefits of using this switch amplifier in hazardous areas?

A: The switch amplifier offers intrinsic safety, galvanic isolation, and quick response time, ensuring reliable and secure signal interfacing between field devices and control systems in hazardous zones (zone 2, 22).

Q: When should I use the relay output versus the transistor output?

A: Use the relay output when electrical isolation and higher load currents are required; choose the transistor output for faster switching and lower noise environments.

Q: Where can I check the device status during operation?

A: Device status can be monitored via LED indicationsyellow for channel activation and green for powerlocated on the front of the module.

Q: What is the certification level for this product?

A: The unit is certified for intrinsic safety (Ex ia) and conforming to SIL 2 safety standards, making it suitable for critical and hazardous industrial applications.

Q: How do I request an estimate or quotation for bulk orders?

A: You can obtain estimates and quotations by contacting official suppliers or authorized distributors, who provide tailored packaging and delivery solutions as per your requirements.
