OMRON ZEN-10C1DR-A-V1 CPU UNIT MODULE

Get a Price/Quote

OMRON ZEN-10C1DR-A-V1 CPU UNIT MODULE Specification

Rated Operation Voltage
24V DC

Rated Insulation Voltage
500V AC

Protection Class
Class II

Control System
Programmable Logic Controller (PLC)

Current Rating
0.5A

Rated Current
0.5A

Cabinet Material
Plastic

Cooling System
Natural Air Cooling

Protection Level
IP20

Panel Type
Modular

Thickness
Standard

Features
Compact design, Easy programming, Built-in LCD, Expandable

Operating Voltage
24V DC

Base Material
ABS Plastic

Cover Material
ABS Plastic

Connectivity Type
Screw Terminal

Way
10 I/O (Input/Output)

Components
CPU, Relay Outputs, Digital Inputs

Product Type
CPU Unit Module

Material
Plastic and electronic components

Surface Finish
Matte

Standard
IEC

Surface Color
Grey

Rated Voltage
24V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
0.5A per output

Dimension (L*W*H)
90mm x 70mm x 56mm

Application
Industrial Automation, PLC Control

IP Rating
IP20

Display Type
LCD Display

Mounting Type
DIN Rail or Surface Mount

Operating Temperature Range
0°C to 55°C

Storage Temperature Range
-20°C to 75°C

Programming Method
Front Panel Buttons or PC Software

Output Contacts Ratings
5A, 250V AC (Relay)

Humidity
10% to 90% (Non-condensing)

Power Supply
External 24V DC

Input Voltage Type
DC

Model Number
ZEN-10C1DR-A-V1

Weight
Approx. 200g

Number of Inputs
6 Digital Inputs

Series
ZEN V1

Output Type
Relay

Display Characters
Single line, 8 characters

Expandable
Up to 34 I/O with expansion modules

Response Time
10ms max (input/output)

Memory Capacity
Program capacity up to 150 steps

Number of Outputs
4 Relay Outputs

About OMRON ZEN-10C1DR-A-V1 CPU UNIT MODULE

The OMRON ZEN-10C1DR-A-V1 CPU UNIT MODULE stands out as a cost-effective solution for industrial automation, receiving favorable reviews for its top-drawer build and optimum functionality. Equipped with 6 digital inputs and 4 relay outputs, it features a versatile DIN rail or surface mount design. Its compact form, reliable response time, and easy programming make it the best choice for users seeking both performance and affordability. This PLC control module is expandable, enabling up to 34 I/Os for complex operations. Available on sale, it promises dependable operation and long-term durability, adhering to strict IEC standards.

Enhanced Features for Industrial Applications

The OMRON ZEN-10C1DR-A-V1 CPU UNIT MODULE offers extra features like an intuitive LCD display, expandable I/O capabilities, and easy front-panel or PC-based programming. Its compact, modular design is engineered for industrial automation tasks, including control systems and PLC applications across manufacturing plants, process industries, and machinery automation. The devices ability to reliably operate in varied environments and its IP20-rated build ensure secure use in different application places, making it a versatile tool for industrial control solutions.

Convenient Supply, Payment Options, and Packaging

OMRON ZEN-10C1DR-A-V1 CPU UNIT MODULE is readily available for supply across the main domestic market of India. Competitive asking prices, well-secured packaging, and reliable logistics ensure prompt and safe delivery. Payment terms are designed to suit a diverse client base, accommodating online transfers, bank payments, and more. With consistent supply capacity, customers can easily obtain units for large-scale industrial projects or small-scale upgrades, ensuring seamless procurement for varied operational needs.

FAQs of OMRON ZEN-10C1DR-A-V1 CPU UNIT MODULE:

Q: How can the OMRON ZEN-10C1DR-A-V1 CPU UNIT MODULE be programmed?

A: The unit can be programmed either through its front-panel buttons for quick setups or using specialized PC software for more advanced functions, offering flexibility to both novice and experienced users.

Q: What are the environments suitable for installing this module?

A: Its robust design and IP20 rating make it suitable for industrial automation environments including manufacturing plants, process control units, and machinery automation, operating reliably within 0C to 55C and 10% to 90% humidity.

Q: Where can I expand the I/O capacity of the ZEN-10C1DR-A-V1 module?

A: You can expand the modules I/O capacity up to 34 points using compatible expansion modules, making it ideal for projects that require growing control capabilities.

Q: What are the main benefits of using this CPU Unit Module?

A: Users benefit from cost-effective automation, compact design, reliable relay outputs, easy programming options, and a favorable track record of performance in diverse industrial settings.

Q: What is the process to order and receive the module in India?

A: Simply contact the supplier or trader in India, discuss supply requirements, finalize the asking price and payment terms, and the product will be shipped with secure packaging to your desired location.
