OMRON INPUT MODULE C200H-MD215

Get a Price/Quote

OMRON INPUT MODULE C200H-MD215 Specification

Shape
Rectangular

Humidity %
1090% RH (non-condensing)

Overheating Protection
NO

Feature
LED Status Indicators, Easy Mounting, Removable Terminal Block

Connector Type
Screw Terminal

Efficiency
High Signal Accuracy

Operating Temperature
0C to 55C

Surface Finish
Matte

Mounting Type
DIN Rail, PLC Rack Mount

Insulation Material
Plastic

IP Rating
IP20

Product Type
Input Module

Application
Industrial Automation, PLC Expansion

Protection Level
Basic Protection

Frequency (MHz)
50/60 Hz

Rated Voltage
24 VDC

Energy Consumption
Approx. 5.4 W

Output Type
N/A (Input Only)

Color
Grey

Dimension (L*W*H)
130 mm x 35 mm x 98 mm (Approx.)

Weight
Approx. 160g

Input Voltage
24 VDC

Size
Standard Omron C200H Module Size

Phase
Single

Connection Type
Terminal Block

No Of Poles
16 (Input Points)

Material
Plastic Housing, Electronic Components

Storage Temperature
-20C to 70C

Response Time
ON: 20 ms max; OFF: 20 ms max

Compliance
CE, RoHS

Status Indication
Individual LED input indication

Input Current
Approx. 7 mA per point at 24 VDC

Modules per System
Expandable, up to rack capacity

Compatible PLC Series
OMRON C200H Series

Input Format
NPN/PNP (Sink/Source) compatible

Series
C200H

Isolation Voltage
1500 VAC for 1 min (between input terminals and internal circuit)

OMRON INPUT MODULE C200H-MD215 About

The OMRON INPUT MODULE C200H-MD215 is an affordable, must-have solution for industrial automation, offering uncommon versatility and monumental reliability. With its venerable isolation voltage of 1500 VAC and compatibility with both NPN/PNP input formats, this module excels in precision and efficiency. Featuring 16 input points, high signal accuracy, individual LED indicators, and robust plastic housing, it stands out as a special-rate expansion for the OMRON C200H Series. Easily mountable and expandable up to rack capacity, it is crafted for professionals seeking reliable, compliant devices in India.

Used By, Features, and Special Highlights

OMRON INPUT MODULE C200H-MD215 is trusted by automation professionals for its resilient design and straightforward usability. Key features include 16 input points, LED status indicators, and a removable terminal block for easy maintenance. Special highlights involve high isolation voltage, rapid response times, and flexibility with both NPN/PNP signals. This module excels in PLC expansion, providing reliable basic protection suitable for varied industrial environments and rack capacities.

FOB Port, Sample Policy, and Packaging Details

This module is shipped via a secure FOB port, ensuring express shipping for minimized expenditure and time efficiency. Our sample policy accommodates industry requirements, offering samples based on eligibility and application. Packaging details feature robust, secure shipping materials for added protection, safeguarding the module against transit hazards. Carefully packed in standard Omron sizes, it arrives ready for installation and confident use in industrial settings.

FAQs of OMRON INPUT MODULE C200H-MD215:

Q: How is the OMRON C200H-MD215 input module typically used in industrial automation?

A: This input module is employed to expand input capabilities on OMRON C200H Series PLCs, allowing precise signal detection from sensors and switches in varied automation applications.

Q: What are the unique features of the C200H-MD215 module that distinguish it from others?

A: This module stands out for its dual compatibility with NPN/PNP input formats, 16 individual input LED indicators, high isolation voltage, and effortless mounting for modular PLC systems.

Q: When is the C200H-MD215 most beneficial for a PLC expansion project?

A: It is most beneficial when additional input points are necessary for complex automation tasks, especially in environments demanding robust signal accuracy and secure system integration.

Q: Where can you purchase the C200H-MD215 in India?

A: This module is readily available through authorized OMRON suppliers and traders across India, ensuring access to genuine products and reliable technical support.

Q: What is the process for installing and maintaining the C200H-MD215 module?

A: Installation involves DIN rail or rack mounting with a removable terminal block for effortless wiring. Maintenance is simplified by individual LED input indicators and easy access to terminal connections.

Q: How does the modules compliance and protection level benefit users?

A: Compliance with CE and RoHS ensures safe, environmentally responsible usage, while basic protection and high isolation voltage safeguard both devices and operators in demanding applications.
