OMRON CS1WCLK21 CONTROLLER LINK UNIT MODULE

Send Inquiry

Request To Call Back

OMRON CS1WCLK21 CONTROLLER LINK UNIT MODULE

Get a Price/Quote

OMRON CS1WCLK21 CONTROLLER LINK UNIT MODULE Specification

Shape
Rectangular

IP Rating
IP20

Humidity %
10%90% RH (non-condensing)

Surface Finish
Matte

Efficiency
High Network Efficiency

Operating Temperature
0C to 55C

Connector Type
Terminal Block, Communications Port

Overheating Protection
No direct overheating protection

Insulation Material
Thermoplastic

Mounting Type
DIN Rail Mounting

Feature
Multi-node PLC communications, Remote I/O networking

Product Type
Controller Link Unit Module

Application
Industrial Automation, PLC Networking

Protection Level
IP20

Frequency (MHz)
2 MHz (Internal Circuit)

Rated Voltage
5V DC (from PLC rack)

Energy Consumption
2.5 W max.

Output Type
Data Communication

Color
Gray

Dimension (L*W*H)
130 mm x 35 mm x 100 mm

Weight
Approx. 180g

Phase
Single Phase

Input Voltage
5V DC (supplied from PLC)

Size
Standard CS1W Series Size

Connection Type
Screw/Terminal blocks

Material
Plastic, Metal

Storage Temperature
-20°C to 70°C

Firmware Upgrade
Via PLC Programming Port

LED Indicators
Error, Transmission, Status

Baud Rate
1 to 5 Mbps

Number of Units per Network
Up to 32

Compatible Cable Types
VCTF (0.75mm2, 1.25mm2) twisted pair

Transmission Method
Token Bus

Cooling Method
Passive

Supported PLC Series
CS1, CJ1, C200HX/HG/HE, CVM1, CV Series

Data Link Capacity
16,384 words

Communications Distance
Max 500m (using specified cables)

About OMRON CS1WCLK21 CONTROLLER LINK UNIT MODULE

Experience superb savings and top-drawer network efficiency with the OMRON CS1WCLK21 Controller Link Unit Module ideal for industrial automation and PLC networking. This gilt-edged module offers affordable multi-node remote I/O communication, supporting up to 32 units per network and transmission distances reaching 500m. Engineered for accessibility, its compatible with CS1, CJ1, C200HX/HG/HE, CVM1, and CV Series PLCs and boasts a highly robust design with IP20 protection, passive cooling, and clear LED indicators. With its versatile connectivity, flexible installation via DIN rail, and high data handling, it delivers value-driven performance in every aspect.

Versatile Industrial Performance

The OMRON CS1WCLK21 Controller Link Unit Module is a superb choice for dynamic industrial automation environments. Designed for both extensive PLC networking and remote I/O communications, it affords users remarkable accessibility and competitive advantages through its high-speed baud rate and multi-node capability. Ideal for factories, control systems, and distributed networking, its robust construction and reliable operation ensure consistent performance, maximizing process uptime for manufacturers and integrators alike.

Secure Global Shipping & Export Policies

Shipped with premium secure packaging from India, the OMRON CS1WCLK21 module is ensured safe transit to requested destinations. FOB Port options offer flexible logistics for international buyers. Sample policy options grant prospective users hands-on experience before purchase. The module reaches major export markets, including Asia, the Middle East, and Europe, supporting global automation needs with reliable, premium solutions that enhance connectivity and industrial productivity.

FAQs of OMRON CS1WCLK21 CONTROLLER LINK UNIT MODULE:

Q: How is the OMRON CS1WCLK21 Module installed in industrial setups?

A: The OMRON CS1WCLK21 module is designed for simple DIN rail mounting and uses terminal blocks for secure connection. Its rectangular, compact shape and standard CS1W size make integration seamless in most PLC racks.

Q: What are the primary benefits of using this module for PLC networking?

A: This module delivers affordable, high-efficiency multi-node communications, long-distance wiring capability up to 500m, and compatibility across multiple OMRON PLC series, enabling superb data sharing and control adaptability for complex industrial networks.

Q: Where is the OMRON CS1WCLK21 Controller Link Unit typically used?

A: It is typically used within industrial automation setups, remote I/O networking, and distributed control systems where reliable and fast PLC interconnections are required.

Q: When should users consider a firmware upgrade for the module?

A: Firmware upgrades are recommended when new features or performance improvements are released. Upgrading is conveniently handled via the PLC programming port, ensuring the module remains up-to-date and secure.

Q: What is the process for ordering and shipping this module internationally?

A: Orders can be placed through authorized traders and suppliers in India, with secure shipping and FOB port facilities offered to ensure safe international delivery. Sample policies are available for prospective buyers.

Q: How does the modules design contribute to protection and durability?

A: With IP20 protection, passive cooling, and a matte thermoplastic surface, the OMRON CS1WCLK21 is engineered for robustness and reliability, making it capable of withstanding challenging industrial environments.
