OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULE

Send Inquiry

Request To Call Back

OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULE

Get a Price/Quote

MOQ : 1 Piece

OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULE Specification

Current Rating
150 mA

Rated Current
0.15A (approx. at 24V DC)

Rated Insulation Voltage
500V AC (1 min.)

Operating Voltage
24V DC

Way
Single communication port

Connectivity Type
PROFIBUS DP network

Components
PROFIBUS communication interface, terminal block

Protection Level
IP20

Cooling System
Natural air cooling

Cabinet Material
Plastic

Base Material
Plastic

Protection Class
Class I

Cover Material
Plastic

Rated Operation Voltage
24V DC

Thickness
Approx. 70 mm

Features
Easy integration with Omron PLCs, supports GSD file configuration, baud rate auto-detection, plug-in terminal block

Control System
CJ-series PLC platform

Panel Type
DIN Rail Mount

Product Type
PROFIBUS DP Slave Module

Material
Plastic, Metal (electronic components)

Surface Finish
Matte

Standard
CE, UL, cUL

Surface Color
Grey

Rated Voltage
24V DC

Frequency (MHz)
12

Maximum Output Current
N/A (Slave module not output specific)

Dimension (L*W*H)
90mm x 31mm x 80mm (approx.)

Application
PROFIBUS DP communication in CJ-series PLC systems

IP Rating
IP20

Display Type
LED indicators

Supported Baud Rates
9.6 kbps to 12 Mbps

Weight
Approx. 150 g

Module Type
Slave Device Module

Power Consumption
3.6W max.

Protocol Version
PROFIBUS DP V0

Mounting Method
DIN rail

Configuration Method
GSD file based, rotary switch for address setting

Operating Temperature
0°C to 55°C

Relative Humidity
10% to 90% (no condensation)

Signal Transmission
Twisted pair, RS-485

Interface Type
9-pin D-sub (male)

Storage Temperature
-20°C to 75°C

About OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULE

Experience a praiseworthy leap in industrial automation with the OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULEyour last chance to secure unmatchable connectivity and robust performance for CJ-series PLC systems. Advance purchase of this majestic DIN rail-mounted module provides reliable PROFIBUS DP communication at incredible speeds, supporting baud rates from 9.6 kbps to 12 Mbps. Access simplified configuration via GSD files and rotary address setting. Designed for rugged environments with IP20 protection and natural cooling, this CE, UL, cUL-compliant module integrates seamlessly, ensuring dependable operation and advanced diagnostics for your automation network.

Versatile Application & Usage Summary

The OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULE is engineered for seamless integration into industrial automation environments. Commonly used as a communication interface within CJ-series PLC platforms, it supports PROFIBUS DP networks over twisted pair cabling. Its primary application media includes manufacturing lines, process automation, and control cabinets requiring reliable, real-time data exchange. Designed for DIN rail mounting, it finds purpose in diverse industries such as automotive, pharmaceuticals, and packaging, where precision and connectivity are critical.

Order Fulfillment & Packaging Information

For the OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULE, all order processing is swift, ensuring timely delivery at the lowest price through major FOB ports in India. Exchange options are available to ensure customer satisfaction. Each module is carefully packaged to guarantee secure transit and arrives ready for immediate installation. Our streamlined delivery process focuses on efficiency, dependability, and excellent support, providing a smooth procurement experience from dispatch to destination.

FAQs of OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULE:

Q: How do I set the communication address for the OMRON CJW1-PRT21 module?

A: The communication address is set easily using the built-in rotary switch. This design feature simplifies the process, allowing for precise configuration right at the installation point.

Q: What environments are suitable for using the OMRON CJW1-PRT21 PROFIBUS DP SLAVE MODULE?

A: This module operates reliably in industrial settings with temperatures ranging from 0C to 55C and relative humidity up to 90% (non-condensing), making it ideal for manufacturing floors, control cabinets, and harsh environments.

Q: Where can I integrate this module within an automation system?

A: The OMRON CJW1-PRT21 is specifically designed for seamless integration into Omron CJ-series PLC systems, serving as a slave communication link in PROFIBUS DP networks.

Q: What are the benefits of using a GSD file-based configuration?

A: GSD file-based configuration offers streamlined integration, reduces setup time, and enhances compatibility with diverse PROFIBUS DP master devices, ensuring flexible and efficient deployment.

Q: What is the typical delivery timeline for this module in India?

A: Order processing and delivery times are optimized for quick shipment. Most orders are dispatched promptly via major Indian FOB ports, ensuring timely and reliable delivery to your location.

Q: How does the OMRON CJW1-PRT21 module facilitate system reliability?

A: With features like plug-in terminal blocks, natural air cooling, LED status indicators, and compliance with CE, UL, and cUL standards, this module ensures consistent, safe, and reliable communication in automation networks.
