OMRON C200H-OC225 OUTPUT UNIT MODULE

Get a Price/Quote

OMRON C200H-OC225 OUTPUT UNIT MODULE Specification

Features
High-speed Response, Easy Installation, Compact Design

Protection Class
Class II

Cover Material
ABS

Rated Operation Voltage
24V DC

Cooling System
Natural Air Cooling

Operating Voltage
DC 24V

Protection Level
IP20

Thickness
Standard Module

Panel Type
Plug-In Module

Components
Solid State Output

Base Material
Plastic

Current Rating
2A/channel

Rated Current
2A

Rated Insulation Voltage
250V AC

Control System
PLC-Based

Connectivity Type
Terminal Block

Way
16 points

Product Type
Output Unit Module

Material
Industrial-grade Plastic and Metal Components

Surface Finish
Matte

Standard
OMRON Industrial Automation

Surface Color
Grey

Rated Voltage
24V DC

Frequency (MHz)
50/60Hz

Maximum Output Current
2A per channel

Dimension (L*W*H)
130mm x 40mm x 100mm

Application
Industrial Control Panel Automation

IP Rating
IP20

Display Type
LED Status Indicators

Channels
16 Output Channels

Output Type
Relay Contact Output

Compatible Models
Omron C200H Series PLC

Operating Temperature
0C to 55C

Weight
Approx. 250g

Dielectric Strength
2000 VAC, 50/60 Hz for 1 min

Humidity Range
10 to 90% RH (non-condensing)

Response Time
Max. 10ms

Mounting Type
Rack Mountable (C200H-series main rack)

Insulation Resistance
100 M minimum (at 500 VDC)

Storage Temperature
-20C to 75C

Category
Output Relay Module

Terminal Type
Screw Terminal

About OMRON C200H-OC225 OUTPUT UNIT MODULE

Highlighted as a paragon among output relay modules, the OMRON C200H-OC225 OUTPUT UNIT MODULE stands out for delivering blue-ribbon reliability in industrial automation. This magnificent plug-in module features 16 output channels supported by robust relay contact output, sturdy insulation, and impressive dielectric strength. Engineered for seamless rack-mount integration with Omron C200H Series PLCs, it boasts an industrial-grade build and natural air cooling. Jump on efficiency, add to cart, and elevate your control systems with compact, high-speed response and easy installationtruly an industrial automation masterpiece.

Versatile Application & Robust Installation

The OMRON C200H-OC225 OUTPUT UNIT MODULE is tailored for diverse Application Media in demanding industrial control panel automation. Its designated Site Of Application is within main racks of Omron C200H-series PLCs, ensuring seamless system extension. Perfect for surfaces in electrical cabinets and control panels, this modules industrial-grade plastic body and IP20 protection are ideal for factory floors. Its compact matte finish provides both resilience and professional aesthetics, making it fit for modern automated workplaces.

Impeccable Packaging & Market Reach

Handed over to clients via reliable FOB Port options, the OMRON C200H-OC225 is meticulously packed for safe transit. It commands significant Market Value owing to its performance in Indias automation sector, yet is available at the lowest price for its class. Main Domestic Market reach extends across India, empowering traders and suppliers to deliver rapid solutions. Detailed packaging ensures the module arrives pristine and ready for panel integration straight from supplier to site.

FAQs of OMRON C200H-OC225 OUTPUT UNIT MODULE:

Q: How is the OMRON C200H-OC225 OUTPUT UNIT MODULE typically used in industrial automation?

A: The module is primarily installed within industrial control panels for Omron C200H PLC systems, providing 16 channels of relay-based output suitable for managing a range of automated processes.

Q: What are the main benefits of using this output unit module in a control system?

A: The key benefits include high-speed response, easy installation, compact design, and reliable relay contact output, which contribute to efficient operation and minimized downtime in automated environments.

Q: Where can this output unit module be installed?

A: It is designed to be rack mountable in the C200H-series main rack and is ideally suited for deployment in industrial electrical control panels and automation control cabinets.

Q: What types of environments is this module designed to operate in?

A: The OMRON C200H-OC225 is built for applications in environments with temperatures between 0C to 55C and humidity ranging from 10% to 90% non-condensing, making it suitable for a wide range of industrial sites.

Q: How is the module connected and monitored during operation?

A: Connection is established via screw terminals, and operation is monitored using onboard LED status indicators, enabling quick setup and effective real-time status tracking.
