NI IGBT

Get a Price/Quote

NI IGBT Specification

Output
High-Power Switching

Current
Up to 400A

Connectivity Type
Screw Terminal

Protection Level
Short Circuit Protection, Overheat Protection

Features
High Efficiency, Fast Switching, Low Saturation Voltage, Rugged Construction

Pole Type
Single, Dual, or Multi-Pole

Phase
Three Phase

Frequency
50 Hz / 60 Hz

Switch Type
Insulated Gate Bipolar Transistor (IGBT)

Mounting Type
Chassis Mount

IP Rating
IP20

Installation Type
Panel Mount

Usage & Applications
Frequency Inverters, AC Motor Controls, Industrial Automation

Product Type
NI IGBT Module

Operating Temperature
-40C to +150C

Working Temperature
-40C to +150C

Input
Standard Gate Drive Signal

Application
Industrial Motor Drives, Power Supplies, UPS Systems, Inverters, Traction, Welding Equipment

Supply Voltage
600V / 1200V / 1700V

Dimension (L*W*H)
135mm x 75mm x 30mm (approx.)

Weight
Approx. 350 g

Isolation Voltage
2500V (AC 1 min)

Power Dissipation
Up to 1200W

Thermal Resistance
< 0.25 K/W

Package Type
Module

Gate-Emitter Voltage (max)
±20V

Standards Compliance
RoHS, CE

Technology
Field Stop Trench IGBT

Response Time
Fast turn-on/turn-off (<2 µs)

Collector-Emitter Voltage (Vce max)
600V / 1200V / 1700V

About NI IGBT

Experience grand performance and praiseworthy reliability with the NI IGBT Field Stop Trench module. Engineered for cost-effective solutions, this spectacular device offers superior fast turn-on/turn-off response (<2 s) and robust power dissipation up to 1200W. Designed for critical industrial applicationssuch as motor drives, power supplies, and invertersthe module thrives in ephemeral environments, delivering enduring power with high efficiency, low thermal resistance, and rugged construction. Boasting RoHS and CE compliance, its short circuit and overheat protection ensure faultless safety, while its versatile three-phase configuration grabs every opportunity for reliable, high-capacity switching.

Material Feature & Wide Application Versatility

The NI IGBT module stands out with its grand rugged construction and superior efficiency, thanks to advanced Field Stop Trench technology. Crafted for both general and specific industrial use, it seamlessly integrates into frequency inverters, AC motor controls, UPS systems, and industrial automation setups. This praiseworthy device is designed for demanding high-power switching, making it a spectacular choice for applications requiring reliability and performance in versatile settings.

FOB Port & Swift DeliveryOptimizing Expenditure

NI IGBT modules are delivered efficiently with the option of shipment from a reputable FOB port. Upon receiving your Purchase Order, expect reliable delivery within the stated time frame, ensuring your project timelines are met. High supply ability and seamless order processing contribute to lower expenditure and uninterrupted operations, making your procurement process straightforward and stress-free. This guarantees that you get quality products exactly when you need them, without unnecessary delays.

FAQs of NI IGBT:

Q: How does the fast turn-on/turn-off response of NI IGBT modules benefit industrial applications?

A: The exceptionally rapid response time (<2 s) ensures efficient high-speed switching, reducing energy losses and enhancing overall system performance in industrial motor drives, inverters, and automation systems.

Q: What protection features are included in the NI IGBT module?

A: The module integrates short circuit and overheat protection mechanisms, safeguarding your equipment from potential faults and expanding the lifespan and reliability of your industrial systems.

Q: Where can NI IGBT modules be used?

A: They are ideal for use in frequency inverters, AC motor controls, UPS systems, industrial automation, power supplies, traction, and welding equipment, covering a wide spectrum of high-power applications.

Q: What makes the NI IGBT module a cost-effective choice?

A: Its combination of high efficiency, robust construction, compliance with international standards, and low maintenance requirements results in reduced operating costs over time, maximizing your investment.

Q: When can I expect delivery after placing a purchase order for NI IGBT modules?

A: Delivery schedules are prompt, with dispatch initiated upon receipt of your purchase order; specific timelines will depend on your location and order quantity, ensuring timely fulfillment for your needs.
