MITSUBISHI QJ71C24N SERIAL COMMUNICATION MODULE

Get a Price/Quote

MITSUBISHI QJ71C24N SERIAL COMMUNICATION MODULE Specification

Features
Dual-channel, Diagnostic LEDs, Switchable RS-232/422/485

Working Temperature
0C to +55C

Application
PLC Serial Communication

Cooling Method
Natural

Operating Temperature
0C to +55C

Output Type
RS-232, RS-422, RS-485 (Serial)

Power Supply
Supplied from base unit

Connector Type
D-Sub 9-pin

Product Type
Serial Communication Module

Input Voltage
5V DC (from base unit)

Material
Plastic/Metal

Storage Temperature
-25C to +75C

Weight
0.23 kg

Compatibility
Mitsubishi Q-Series PLCs

Model
QJ71C24N

Mounting Type
DIN Rail (Fits Q-series rack)

Parity
None, Even, Odd

Isolation
Photo-coupler and transformer isolation

Stop Bit
1 or 2

Communication Protocols
Mitsubishi MELSEC communication protocols, Dedicated protocol, Non-procedural (transparent) protocol

Max Cable Length (RS-422/485)
1200 m

Max Cable Length (RS-232)
15 m

Indicator
Channel status LEDs

Baud Rate
300 bps to 115.2 kbps

Number of Channels
2

Dimensions
98 x 27.4 x 90 mm

Data Bits
7 or 8

About MITSUBISHI QJ71C24N SERIAL COMMUNICATION MODULE

Seize this hot deal on the sterling MITSUBISHI QJ71C24N Serial Communication Moduletop-ranking, venerable technology for reliable PLC serial communication. Fresh from Mitsubishis distinguished Q-Series line, it features dual channels, switchable RS-232/422/485 output, and versatile communication protocols, including MELSEC and transparent protocol support. With robust photo-coupler and transformer isolation, intuitive channel status LEDs, and durable DIN rail mounting, it adapts effortlessly to demanding industrial settings. Try now for seamless integration, advanced diagnostics and proven Mitsubishi performancesupplied by a leading supplier and trader in India.

Features & Competitive Advantages of MITSUBISHI QJ71C24N

The MITSUBISHI QJ71C24N offers robust serial communication capabilities, supporting both dedicated and non-procedural protocols. With two independent channels and intuitive diagnostic LEDs, it ensures swift troubleshooting and monitoring. Its compatibility with the Mitsubishi Q-Series PLC system and flexible DIN rail mounting make it an ideal fit for automation needs. High isolation standards and flexible output options, paired with a wide temperature tolerance, set this sterling module apart as a top choice for industrial communication.

FOB Port, Certifications & Payment Terms for MITSUBISHI QJ71C24N

The MITSUBISHI QJ71C24N is available domestically with prompt transport services to your location. Delivered from notable FOB ports in India, this product meets rigorous industry certifications, guaranteeing quality and reliability. The list price is competitive, supporting businesses across the domestic market. Flexible payment terms are available, adapting to customer requirements for streamlined procurement and delivery. Enquire today to experience swift, trusted service and world-class industrial communication solutions.

FAQs of MITSUBISHI QJ71C24N SERIAL COMMUNICATION MODULE:

Q: How do I install the MITSUBISHI QJ71C24N Serial Communication Module onto my PLC system?

A: The module is designed for quick DIN rail mounting and fits seamlessly into Mitsubishi Q-Series racks. Ensure the base unit is powered down during installation, align the connectors properly, and secure it firmly for optimal performance.

Q: What protocols does the QJ71C24N support for communication?

A: This model supports Mitsubishi MELSEC native communication protocols, dedicated protocol, and a non-procedural (transparent) protocol, providing flexibility for diverse automation and monitoring needs.

Q: Where can I use the MITSUBISHI QJ71C24N in industrial settings?

A: This versatile module is ideal for use in factory automation, process control, and industrial equipment integration, where reliable PLC serial communication is required.

Q: What benefits do diagnostic LEDs provide on the QJ71C24N module?

A: The diagnostic channel status LEDs offer immediate visual feedback on operational states and communication status, enabling quick issue identification and reduced downtime.

Q: What are the maximum cable lengths supported by this module for RS-232 and RS-422/485 interfaces?

A: For RS-232 connections, the maximum cable length supported is 15 meters. For RS-422/485 connections, the maximum is 1200 meters, allowing for extensive communication range in various setups.
