MITSUBISHI QJ71C24N-R4 SERIAL COMMUNICATION MODULE

Get a Price/Quote

MITSUBISHI QJ71C24N-R4 SERIAL COMMUNICATION MODULE Specification

Application
Industrial automation, PLC communication

Operating Temperature
0C to +55C

Features
Supports RS-232, RS-422, RS-485 interfaces; programmable communication parameters; LED status indicators; DIN rail mountable

Working Temperature
0C to +55C

Cooling Method
Natural air cooling

Output Type
Serial (RS-232 / RS-422 / RS-485)

Power Supply
From base unit (internal)

Connector Type
9-pin D-sub female (RS-232C), 9-pin D-sub male (RS-422/485)

Product Type
Serial Communication Module

Input Voltage
24V DC

Voltage Protection
Built-in surge protection

Material
Plastic, Metal

Storage Temperature
-25C to +75C

Weight
Approximately 0.19 kg

Model
QJ71C24N-R4

Dimensions (W x H x D)
27.4 x 98 x 90 mm

Baud Rate Range
300 to 230,400 bps

Isolation
Optical isolation between channels and CPU

Protocol Support
Customizable and user-defined protocols

Communication Channels
2 channels

Compatible Series
Q Series PLC

Status Indications
Communication and error LEDs

Maximum Cable Length
RS-232C: 15 m, RS-422/485: 1,200 m

Mounting Type
Rack Mount (Q Series base unit)

About MITSUBISHI QJ71C24N-R4 SERIAL COMMUNICATION MODULE

On Clearance and acclaimed for its elite functionality, the MITSUBISHI QJ71C24N-R4 Serial Communication Module is the superb choice for advanced industrial automation. Compatible with Q Series PLCs, this polished module features two high-speed communication channels, supporting baud rates from 300 to 230,400 bps. With robust optical isolation, customizable protocols, and built-in surge protection, it ensures safe, reliable data exchanges. Grab this quality unitengineered for rack mounting, DIN rail support, and flexible communication through RS-232, RS-422, and RS-485 interfacesat an excellent value.

Versatile Usage and Industry Applications

The MITSUBISHI QJ71C24N-R4 SERIAL COMMUNICATION MODULE is expertly designed for professional use in demanding industrial automation and PLC communication settings. Its polished surface and robust materials allow seamless integration into control cabinets, factory floors, and panel installations. Ideal for process control, manufacturing systems, and real-time data exchange, this module ensures stable operation across a wide temperature range. Surface compatibility with rack-mounted Q Series bases elevates its deployment flexibility for both retrofit and new installations.

Domestic and International Shipping Price Advantage

Shipped Goods are carefully dispatched from Indias main FOB port, serving both the extensive domestic market and thriving export markets, including Asia and the Middle East. Buyers benefit from our offer to source this advanced serial communication module at the lowest price. Our supply network ensures competitive distribution and prompt fulfillment for traders and suppliers alike. As demand for elite automation grows, we maintain a commitment to affordability and reliability across global markets.

FAQs of MITSUBISHI QJ71C24N-R4 SERIAL COMMUNICATION MODULE:

Q: How does the optical isolation feature benefit the QJ71C24N-R4 Serial Communication Module?

A: Optical isolation separates the communication channels from the CPU and control signals, protecting both hardware and data integrity in harsh industrial environments.

Q: What industrial sectors commonly use the QJ71C24N-R4 Serial Communication Module?

A: This module is widely applied in manufacturing, processing plants, and automation facilities where precise PLC-to-device communication is vital for seamless process control.

Q: When should I consider using this module for my automation system?

A: You should use the QJ71C24N-R4 when your application requires reliable, high-speed serial communication between a Q Series PLC and external devices, with robust protection against electrical surges.

Q: Where can the QJ71C24N-R4 be installed within my facility?

A: The module is designed for rack mounting onto Q Series base units in control panels, making it suitable for integration inside industrial cabinets or equipment enclosures.

Q: What is the process for configuring communication parameters on this module?

A: Users can easily set programmable communication parameters, including baud rate and protocol, via specialized software tools compatible with Mitsubishi PLC systems.

Q: How does the module support diverse serial interfaces?

A: It accommodates RS-232, RS-422, and RS-485 serial output types, connecting effortlessly to a variety of industrial devices and ensuring interoperability across different protocols.
