MITSUBISHI OUTPUT MODULE AY60

Get a Price/Quote

MITSUBISHI OUTPUT MODULE AY60 Specification

Operating Temperature
0C to +55C

Surface Finish
Matte

Efficiency
High

Feature
High-speed output, Compact design

Humidity %
5 to 95% RH (non-condensing)

Shape
Rectangular

Connector Type
Screw Terminal Block

Mounting Type
DIN Rail Mounting

Overheating Protection
YES

IP Rating
IP20

Insulation Material
Plastic

Product Type
Output Module

Application
Programmable Logic Controller (PLC) systems

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
24 V DC

Energy Consumption
Max. 8 W

Output Type
Transistor (Sink Type)

Color
Grey

Dimension (L*W*H)
140 mm x 80 mm x 30 mm

Weight
300 g

Size
Standard

Phase
Single Phase

Material
Plastic, Metal

Connection Type
Screw Terminal

Storage Temperature
-25°C to +75°C

Status Indicator
Yes (LED per channel)

Output Current per Point
0.5A max/point

Vibration Resistance
5~8.4 Hz, double amplitude 3.5 mm, 8.4~150 Hz, 9.8 m/s²

Shock Resistance
147 m/s², 11 ms, 3 times in each X, Y, Z direction

Number of Output Points
16 points

Compatible PLC Series
Mitsubishi MELSEC-A Series

Switching Method
NPN (Sink)

RoHS Compliance
Yes

Fuse Protection
Provided

Response Time
Less than 0.5 ms

Isolation Type
Photocoupler

About MITSUBISHI OUTPUT MODULE AY60

The MITSUBISHI OUTPUT MODULE AY60 is a popular and sought-after component among elite automation professionals. Boasting 16 output points with a supreme output current of 0.5A per point, this module features an uncommon blend of compact size and high-speed NPN (sink) switching. RoHS compliant and protected by fuses, the AY60 ensures reliability under demanding conditions, with exceptional vibration and shock resistance. Its DIN rail mounting and screw terminal connectivity make integration seamless into Mitsubishi MELSEC-A Series PLCs. Order today to experience advanced control, unmatched efficiency, and robust protection in your industrial applications.

Versatile Usage and Standout Features of AY60

The MITSUBISHI OUTPUT MODULE AY60 is designed for versatile use within PLC-controlled automation systems, excelling in industrial control environments requiring high-speed output and precise switching. Application is straightforwardmount the module on a DIN rail using its robust screw terminal block, enabling secure connections. Noteworthy features include photocoupler isolation, individual LED status indicators, fast response times below 0.5 ms, and robust overheating and fuse protection, ensuring elite performance in demanding industrial settings.

Domestic Availability and Export Advantages

The AY60 output module is readily accessible within the main domestic market, with samples available to facilitate evaluation before placing a purchase order. Leading suppliers and traders across India make the shipment process efficient, ensuring timely delivery and competitive rates. The product is also exported globally, serving sought-after international markets that value Mitsubishis supreme reliability and high operational standards. Secure your order to benefit from swift fulfillment and responsive after-sales support.

FAQs of MITSUBISHI OUTPUT MODULE AY60:

Q: How do I install the MITSUBISHI OUTPUT MODULE AY60 into my PLC system?

A: The module is designed for easy DIN rail mounting. Simply use the screw terminal block connections to securely integrate it into Mitsubishi MELSEC-A Series PLC systems, following the provided wiring diagram and safety guidelines.

Q: What are the primary benefits of using the AY60 output module in industrial automation?

A: This sought-after module delivers high-speed and reliable transistor (sink type) output, with individual LED status indicators and protection features such as overheating and fuse protection. Its robust construction ensures resilience to shock, vibration, and harsh temperatures.

Q: When should I consider replacing or upgrading to the AY60 module?

A: Consider upgrading if you require faster response times (below 0.5 ms), higher output density (16 points), enhanced protection, and RoHS compliance in your automation setup, or when seeking improved longevity and performance compared to older modules.

Q: Where can I get technical support or samples for the AY60 module in India?

A: Leading automation suppliers and traders throughout India offer comprehensive technical support and can provide evaluation samples. Contact their sales representatives to discuss purchase orders, requirements, and post-shipment assistance.

Q: What process should I follow to ensure correct operation and safety of the AY60 module?

A: Ensure the module is operated within its rated voltage and environmental specifications. Use only compatible power supplies, maintain proper ventilation, follow precise wiring protocols, and use the onboard status LEDs to monitor operation and troubleshoot if necessary.
