MIDDEX ELECTRONICS K480216A-24 STEP MOTOR DRIVER

Get a Price/Quote

MOQ : 1 Piece

MIDDEX ELECTRONICS K480216A-24 STEP MOTOR DRIVER Specification

Features
Microstepping, Short circuit protection, LED status display

Current
2.0A/phase max

Frequency
Up to 200kHz

Protection Level
Over current and Over voltage protection

Connectivity Type
Terminal Block connections

Mounting Type
Screw Mount

Display
LED indicators

Installation Type
Panel Mount

IP Rating
IP20

Phase
2 phase

Switch Type
DIP Switch for settings

Output
24V DC output control

Usage & Applications
Stepper motor control in automation equipment, robotics, textile machinery

Product Type
Step Motor Driver

Operating Temperature
0C to 50C

Working Temperature
0C to 50C

Input
Pulse/Direction signals

Application
Industrial automation, CNC machinery

Supply Voltage
24V DC

Accuracy
Microstepping resolution up to 1/16

Dimension (L*W*H)
116mm x 76mm x 34mm

Weight
420g (approx)

Cooling
Natural air cooling

Control Signal Input
Opto-isolated, accepts TTL/CMOS

Signal Interface
External pulse 5V/24V selectable

Output Current Range
0.5A to 2.0A (adjustable via DIP switch)

Microstepping Resolution Options
Full, Half, 1/4, 1/8, 1/16 steps selectable

Motor Voltage
12-24V DC supported

Isolation
Optical isolation on control inputs

Logic Voltage
5V compatible inputs

About MIDDEX ELECTRONICS K480216A-24 STEP MOTOR DRIVER

Explore the glorious world of precision motion with the MIDDEX ELECTRONICS K480216A-24 STEP MOTOR DRIVER. Designed with unmatchable microstepping versatility, this driver offers selectable resolutions from full to 1/16 step, empowering towering accuracy in every application. Get a price cut on this premium stepper driver and benefit from instant checkout-delivering robust performance for CNC machinery, automation, and robotics. Its opto-isolated logic interface, adjustable output current, and integrated protection make it a reliable partner for demanding industrial environments.

Comprehensive Control for Industrial Automation

The MIDDEX ELECTRONICS K480216A-24 STEP MOTOR DRIVER is engineered for heavy-duty, industrial automation applications. Its unmatchable compatibility with CNC machines, textile machinery, and robotics makes it ideal for stepper motor control. With screw-mount installation and DIP switch configuration, it's easy to tailor to specific usage demands. Whether for automated assembly or precision fabric handling, this driver supplies robust and reliable motion solutions where accuracy matters most.

Flexible Supply, Shipping, and Export Policies

Sample policies for the MIDDEX ELECTRONICS K480216A-24 ensure businesses can assess quality before placing bulk orders. Shipments are primarily dispatched from India's main FOB ports, ensuring timely and secure delivery worldwide. We offer responsive customer support and cater to export markets across Asia, Europe, and the Middle East. Trust our efficient supply chain and competitive offers to streamline your procurement process.

FAQ's of MIDDEX ELECTRONICS K480216A-24 STEP MOTOR DRIVER:

Q: How does the microstepping resolution benefit stepper motor performance?

A: Microstepping resolution allows for smoother and more precise control of the stepper motor, reducing noise and vibration while enhancing positional accuracy. It is ideal for applications requiring fine movement adjustments.

Q: What applications are best suited for the K480216A-24 Step Motor Driver?

A: This step motor driver excels in industrial automation, CNC machines, robotics, and textile machinery where high accuracy and reliability are paramount.

Q: Where is the product typically supplied from and shipped to?

A: The K480216A-24 Driver is supplied from India, with shipments commonly dispatched to export markets across Asia, Europe, and the Middle East.

Q: What protections are included in the driver?

A: The driver features overcurrent and overvoltage protection, short circuit protection, and optical isolation for control inputs to ensure safe and reliable operation.
