MESSUNG RS-232-RS422/485 PLC MODULE

Get a Price/Quote

MOQ : 1 Piece

MESSUNG RS-232-RS422/485 PLC MODULE Specification

IP Rating
IP20

Surface Finish
Powder Coated

Humidity %
10% to 90% RH, non-condensing

Overheating Protection
YES

Mounting Type
DIN Rail Mounting

Feature
Isolated Communication Ports, Surge Protection

Connector Type
DB9 Female, Terminal Block

Efficiency
>95%

Operating Temperature
0C to 55C

Shape
Rectangular

Power Factor
0.98

Insulation Material
High Grade Polymer

Product Type
PLC Communication Module

Application
Industrial Automation, PLC Networking

Protection Level
Protected Circuit Board

Frequency (MHz)
50/60 Hz

Rated Voltage
24V DC

Energy Consumption
Low Power

Output Type
RS-422 & RS-485 Differential Output

Color
Blue & Grey

Dimension (L*W*H)
120 x 80 x 35 mm

Weight
180 g

Size
Standard Module Size

Input Voltage
24V DC

Phase
Single Phase

Connection Type
Screw Terminal Block

Material
Plastic & Metal

About MESSUNG RS-232-RS422/485 PLC MODULE

Experience a remarkable deal with our Reduced Price, Top-notch MESSUNG RS-232-RS422/485 PLC MODULE, now available at a superior Markdown. Engineered for heroic industrial automation, this module offers access to reliable communication standards: RS-232, RS-422, and RS-485 with baud rates up to 115.2 Kbps. Its 1500V RMS opto-isolation ensures robust protection, while LED status indicators and surge protection enhance operational clarity and safety. Compatible with Messung NX PLC Series and other standard PLCs, this hero module guarantees seamless networking, efficiency over 95%, and low energy consumption in a durable blue-grey chassis.

Competitive Advantages and Versatile Applications

The MESSUNG RS-232-RS422/485 PLC MODULE stands out for its superior isolation voltage and surge protection, providing a safe and stable interface. Ideal for industrial automation, PLC networking, and protected circuit operations, it integrates flawlessly in general or specific control environments. Its powder-coated finish and IP20 rating guarantee reliability in various production and process industries, ensuring advanced communication and top-level efficiency wherever deployed.

Supply Ability, Payment Efficiency, and Export Markets

Our supply capability ensures rapid order completion and prompt drop-off, enhancing delivery for domestic and global clients. Flexible payment terms facilitate seamless transactions, making procurement effortless. The MESSUNG PLC MODULE is in high demand across India and major export markets, with dedicated logistics ensuring safe and timely arrival, whether for repeat orders or initial installations. Experience streamlined service and reliable fulfillment with every module shipped.

FAQs of MESSUNG RS-232-RS422/485 PLC MODULE:

Q: How does the MESSUNG RS-232-RS422/485 PLC MODULE enhance industrial automation?

A: The module provides opto-isolated communication ports and surge protection, ensuring reliable, interference-free data transmission critical for industrial automation and PLC networking.

Q: What is the process to connect compatible devices to this PLC module?

A: Devices connect using the screw terminal block or DB9 female connector, making integration with Messung NX PLC Series and standard PLCs straightforward and secure.

Q: When should I use RS-422/RS-485 over RS-232 with this module?

A: RS-422/RS-485 should be used for longer cable runs up to 1200 meters or when differential output is required for networked PLC environments, while RS-232 suits shorter connections.

Q: Where can this PLC module be mounted for optimum performance?

A: It is designed for DIN rail mounting in industrial control panels, maximizing organization, safety, and accessibility within controlled environments.

Q: What are the top benefits of LED status indicators on the module?

A: LED indicators provide instant feedback for transmission and reception (TX/RX) status, allowing operators to quickly diagnose communication and resolve issues efficiently.

Q: How does the module ensure protection against overheating and surges?

A: Featuring protected circuit board design, opto-isolation, and overheating protection, the module maintains safe operation and shields sensitive equipment from electrical hazards.
