Infineon IGBT

Get a Price/Quote

Infineon IGBT Specification

Protection Level
Short circuit and over-temperature protection

Pole Type
Single pole

Current
75A

Connectivity Type
Screw terminals

Usage & Applications
Industrial drives, renewable energy systems, electric vehicles

Mounting Type
Screw Mount

Phase
Three-phase compatible

Switch Type
Semiconductor electronic switch

Features
Low saturation voltage, fast switching speed, robust module design

Installation Type
Panel mount

Frequency
High-frequency switching

Output
High power switching output

Product Type
IGBT (Insulated Gate Bipolar Transistor)

Operating Temperature
-40C to 150C

Working Temperature
-40C to 150C

Input
Low voltage drive signal

Application
Power electronics, inverter, UPS, motor drives

Supply Voltage
Up to 1200V

Dimension (L*W*H)
134mm x 44mm x 21mm

Weight
350g

Package Type
Standard Infineon IGBT module

RoHS Compliant
Yes

Module Technology
Trench/Field Stop IGBT

Insulation Voltage
2500V (AC 1 min)

Maximum Power Dissipation (Ptot)
312W

Gate Threshold Voltage (Vge(th))
5V - 6.5V

Collector Current (Ic)
75A continuous

Collector-Emitter Voltage (Vces)
1200V

Short Circuit Withstand Time
10s

Switching Frequency
up to 20kHz

Storage Temperature
-40C to 125C

About Infineon IGBT

Experience distinguished value with this meritorious Infineon IGBT module, engineered for superlative industrial and high-power applications. Featuring a robust 1200V collector-emitter voltage and 75A continuous current, it delivers exceptional efficiency and reliability. Built with advanced Trench/Field Stop IGBT technology, it ensures low saturation voltage, fast switching speed up to 20kHz, and reliable protection mechanisms. RoHS compliant and designed for panel mount installation, this module is suitable for three-phase systems. For a limited time, secure this IGBT module at the lowest priceexclusively from our trusted supply channel.

Versatile Applications & Operating Methods

The Infineon IGBT is ideal for diverse sectors including industrial drives, renewable energy systems, electric vehicles, inverters, and UPS systems. Its design allows for flexible integrationfeaturing screw terminals for secure connectivity, panel mount installation, and three-phase compatibility. The application method is straightforward: simply connect to low-voltage drive signals for high power switching outputs, making it well suited for both continuous and demanding intermittent operations in professional power electronics environments.

Domestic Market Reach & Service Commitment

Our Infineon IGBT module is readily available for prompt handover across the main domestic market. We maintain a transparent sample policy to facilitate your evaluation prior to bulk orders, with competitive asking prices and efficient handling of shipping freight. With high supply ability and rigorous service standards, we ensure seamless procurement and reliable supportfrom inquiry through deliveryhelping you accelerate your project timelines with minimal disruption.
