INFINEON FS75R12KE3-B9 IGBT MODULE

Get a Price/Quote

MOQ : 1 Piece

INFINEON FS75R12KE3-B9 IGBT MODULE Specification

Components
IGBT with Free Wheeling Diode

Control System
External Gating

Features
High Efficiency, Low Losses, Fast Switching

Rated Operation Voltage
1200 V

Thickness
Standard Module Thickness

Operating Voltage
1200 V

Rated Insulation Voltage
2500 V

Way
Three-phase

Rated Current
75 A

Protection Class
Class I

Cover Material
Molded Plastic

Cooling System
Baseplate for External Heat Sink

Current Rating
75 A

Panel Type
Module

Connectivity Type
Screw Terminal

Protection Level
IP20

Base Material
Copper Baseplate

Product Type
IGBT Module

Material
Plastic and Metal

Surface Finish
Smooth

Standard
IEC Standard

Surface Color
Black and White

Rated Voltage
1200 V

Frequency (MHz)
50/60 Hz

Maximum Output Current
75 A

Dimension (L*W*H)
106 mm 62 mm 30 mm

Application
Industrial Inverters, Motor Drives, Power Supplies

IP Rating
IP20

Power Dissipation
400 W

Operating Temperature Range
-40C to +150C

Mounting Type
Screw Mount

Collector Current (Ic)
75 A

Collector Emitter Voltage (Vces)
1200 V

Isolation Voltage
2500 V (AC)

Module Configuration
6-Pack (Three Phase Bridge)

Package
B9 Standard

Series
EconoPACK

Gate Emitter Voltage (Vge)
20 V

Weight
Approx. 350 g

Storage Temperature
-40C to +125C

About INFINEON FS75R12KE3-B9 IGBT MODULE

Redeem the opportunity to own the INFINEON FS75R12KE3-B9 IGBT MODULE, now available for a limited time. This first-class 6-Pack module is engineered for commanding industrial performance, offering a robust collector-emitter voltage of 1200 V and a collector current of 75 A. Its exquisite design features low losses, high efficiency, and rapid switching within a scarce supply, making it a coveted choice for sophisticated motor drives, power supplies, and industrial inverters. Secure this IEC-standard modulecrafted from premium materialsbefore it becomes even more elusive.

Versatile Usage and Elite Application Areas

The INFINEON FS75R12KE3-B9 IGBT MODULE excels in demanding industrial environments. It is uniquely suited for motor drives, industrial inverters, and advanced power supplies, operating proficiently with three-phase bridge configuration. This module commands performance across varied media, including high-frequency circuits and robust power control systems. Whether deployed in manufacturing or automated facilities, its versatility and resilience ensure consistent, reliable output under strenuous operational demands.

Export Markets, Packaging, and Transaction Excellence

Our INFINEON FS75R12KE3-B9 IGBT MODULE reaches main export markets in Asia, the Middle East, and Europe. It is securely packaged to industry standards for quick dispatch, preserving its integrity during transit. We offer the lowest price accompanied by convenient payment terms, including purchase orders and swift remittances. Commitment to prompt delivery and quality assurance sets us apart, ensuring that global clients receive their critical components with unparalleled speed and confidence.

FAQs of INFINEON FS75R12KE3-B9 IGBT MODULE:

Q: How does the INFINEON FS75R12KE3-B9 IGBT MODULE enhance industrial performance?

A: This module delivers high efficiency, fast switching, and low losses, ensuring reliable operation in industrial inverters, motor drives, and power supply systems.

Q: What is the recommended usage process for installing the module?

A: Begin by verifying compatibility, then mount using the screw terminals and baseplate. Ensure external gating and adequate heat sinking are provided for optimal thermal management.

Q: Where can this IGBT module be effectively utilized?

A: It is ideally suited for use in factory automation, manufacturing, and energy management systems where robust three-phase bridge configurations are required.

Q: What are the benefits of redeeming this scarce module during the limited time offer?

A: By acting now, customers can benefit from exclusive pricing and secure a scarce, high-performance component before stock becomes unavailable.

Q: When can buyers expect dispatch after a purchase order?

A: Quick dispatch is guaranteed upon confirmation of a purchase order, ensuring timely delivery to meet urgent project requirements.

Q: How is the module packaged to ensure safety during transportation?

A: The INFINEON FS75R12KE3-B9 is packaged with protective materials and sealed in accordance with industry standards to safeguard against transit damage.
