HEIDENHAIN ENCODER ROD 320.005

Get a Price/Quote

HEIDENHAIN ENCODER ROD 320.005 Specification

Components
Encoder Body, Mounting Hardware, Connector/Cable

Features
High accuracy, Robust design, Easy installation

Operating Voltage
5 V DC

Protection Class
Class II

Current Rating
Max 100 mA

Connectivity Type
Cable/Connector

Rated Operation Voltage
5 V DC

Rated Current
< 100 mA

Way
Single-turn/Incremental

Cover Material
Aluminum

Cooling System
Self-cooled

Thickness
Approx. 28 mm (body)

Protection Level
IP64

Control System
Compatible with Numeric Controls & DROs

Base Material
Aluminum

Product Type
Rotary/Linear Encoder

Material
Aluminum Alloy, Steel components

Surface Finish
Anodized/Polished

Standard
HEIDENHAIN Standard

Surface Color
Silver/Grey

Rated Voltage
5 V DC 5%

Frequency (MHz)
up to 100 kHz output signal

Maximum Output Current
20 mA

Dimension (L*W*H)
Approx. 235 mm x 35 mm x 28 mm

Application
Industrial Automation, CNC Machines

IP Rating
IP64

Display Type
Not Applicable (Electronics Interface)

Reference Marks
One or multiple, selectable

Mounting Method
Clamp fixtures on mounting surface

Grating Period
20 m

Storage Temperature Range
-20C to +70C

Signal Cable Length
Standard 3 m, max up to 30 m

Output Signal
TTL square-wave signals or 1Vpp (selectable)

Vibration Resistance
Up to 100 m/s2 (10 - 2000 Hz)

Measuring Length
Up to 1040 mm (configurable)

Shock Resistance
Up to 300 m/s2 (6 ms)

Weight
Approx. 0.5 kg per meter

Operating Temperature Range
0C to +50C

About HEIDENHAIN ENCODER ROD 320.005

The HEIDENHAIN ENCODER ROD 320.005 offers meritorious value and affordable, trending solutions for industrial automation and CNC machines. This splendiferous incremental encoder features a configurable measuring length up to 1040 mm and a durable aluminum alloy build. With selectable TTL or 1Vpp output signals, multiple reference marks, and robust resistance to vibrations and shocks, it delivers first-class performance. The anodized surface finish, exceptional accuracy, and easy installation make it the preferred choice for industries seeking reliability, compatibility, and high-precision results within a value-driven framework.

Versatile Performance and Application Highlights

HEIDENHAIN ENCODER ROD 320.005 is tailored for single-turn, incremental usage in demanding environments. Ideal for industrial automation and CNC machinery, it excels in precise position measurement and feedback applications. Its robust build and accurate signal output make it perfect for integration in numeric controls and digital readouts. With protection class IP64, this encoder suits challenging conditions, providing long-lasting, reliable service in a wide range of manufacturing and control system scenarios.

Flexible Payment Terms and Hassle-Free Sampling

Order processing for HEIDENHAIN ENCODER ROD 320.005 begins promptly upon enquiry, ensuring you receive your quotation without delay. A sample is available, subject to a fair sample policyplease consult before placing your request. Payment terms can be tailored to customer needs, offering flexibility and peace of mind. Once your order is confirmed and payment is processed, the product is efficiently dispatched to minimize your downtime and support operational continuity.

FAQs of HEIDENHAIN ENCODER ROD 320.005:

Q: How is the measuring length of the HEIDENHAIN ENCODER ROD 320.005 configured?

A: The measuring length can be customized up to 1040 mm to suit specific application requirements, ensuring flexibility for various installation scenarios.

Q: What industrial applications best suit this encoder?

A: The encoder is ideal for use in industrial automation, CNC machines, and any setting requiring precise linear position measurement and robust reliability.

Q: Where should I install the encoder for optimal performance?

A: Install the encoder on a stable surface using clamp fixtures, ensuring alignment and securing the mounting for accurate measurement results and protection from operational vibrations.

Q: What process do I follow to request a sample?

A: Requesting a sample is straightforward: contact the supplier for a quotation and review their sample policy. Upon agreement, your sample order will be processed and promptly dispatched.

Q: How does the HEIDENHAIN ENCODER ROD 320.005 benefit industrial automation?

A: Its high accuracy, robust design, and reliable output signals contribute to precise control and efficiency in automation systems, minimizing errors and optimizing production output.

Q: When will I receive my order after placing it?

A: Once your order is processed and payment confirmed, the encoder is dispatched quickly, with lead times depending on availability and locationplease refer to your supplier for specific timelines.
