HEIDENHAIN ENCODER EQN 1325.020

Get a Price/Quote

HEIDENHAIN ENCODER EQN 1325.020 Specification

Connectivity Type
12-pin Connectors, Cable output

Thickness
Standard Series

Rated Current
Max. 100 mA

Protection Level
IP64 (Shaft output), IP67 (Housing)

Protection Class
Class III

Operating Voltage
5 V DC 5%

Current Rating
100 mA

Components
Optical Scanning Disk, Encoder PCB, Shaft, Cover

Base Material
Aluminum

Cover Material
Aluminum

Rated Operation Voltage
5 V DC

Control System
Used with Digital Motion Controls

Features
High precision, Compact size, Robust construction, Maintenance free

Way
Single-Turn, Absolute

Cooling System
None (Passive)

Rated Insulation Voltage
500 V AC (test)

Product Type
Rotary Encoder

Material
Aluminum Housing, Stainless Steel Shaft

Surface Finish
Anodized

Standard
HEIDENHAIN Factory Standard

Surface Color
Silver / Metallic

Rated Voltage
5 V DC 5%

Frequency (MHz)
Up to 25 MHz

Maximum Output Current
20 mA per Channel

Dimension (L*W*H)
Approx. 58 mm diameter

Application
CNC Machines, Automation, Robotics, Textile Machines

IP Rating
IP64 / IP67

Display Type
None (Encoder)

Permissible Shaft Speed
Up to 12,000 rpm

Measuring Step
Smallest step < 0.00005°

Shaft Type
Hollow through shaft, 12 mm

Permissible Axial/Radial Play
±0.15 mm axial, ±0.2 mm radial

Operating Temperature Range
-20°C to +70°C

Output Signal
EnDat 2.2, Absolute/Serial Data Interface

Resolution
25 Bits (13 bit singleturn, 12 bit multiturn)

Weight
Approx. 0.22 kg

Mounting
Clamping ring, stator coupling

About HEIDENHAIN ENCODER EQN 1325.020

The HEIDENHAIN ENCODER EQN 1325.020 stands as a first-class solution for demanding automation environments, earning favorable reviews for unparalleled precision and robust design. With a resolution of 25 bits and a miniature measuring step, it delivers unrivaled accuracy in position and speed feedback, making it ideal for CNC machines, robotics, and textile automation. Procure this compact device to enjoy reliable performance, maintenance-free operation, and superior protection levels. Realize significant savings by choosing a proven, high-grade encoder recognized for its excellence and durability in industrial applications.

Primary Competitive Advantages and Applications

The HEIDENHAIN ENCODER EQN 1325.020 offers primary competitive advantages like high measurement precision and maintenance-free operation, giving users a distinct edge in diverse applications. Its durable, anodized aluminum construction ensures longevity, even in challenging conditions. This encoder is extensively used for precision motion feedback in CNC machines, high-performance robots, and advanced textile equipmentdelivering unmatched consistency and reliability wherever integrated.

Sample Availability, Delivery, and Packaging Information

Sample units of the HEIDENHAIN ENCODER EQN 1325.020 are available for evaluation upon request. Once procured, the goods are carefully packaged in protective, industry-standard materials to ensure safe transport. Delivery time is prompt and goods are delivered efficiently via secure freight channels. Our logistics process is designed for swift, damage-free arrival, providing peace of mind from procurement right through to on-site installation.

FAQs of HEIDENHAIN ENCODER EQN 1325.020:

Q: How does the HEIDENHAIN ENCODER EQN 1325.020 benefit CNC and automation systems?

A: This encoder provides ultra-high precision with a 25-bit resolution and reliable absolute feedback, ensuring accurate control and enhanced performance in CNC machinery, robotics, and textile machines.

Q: What protection levels and materials make it suitable for tough industrial environments?

A: The encoder features an IP64/IP67 protection rating, an anodized aluminum housing, and a stainless steel shaft, offering excellent resistance to dust, water, and mechanical stress, making it ideal for demanding environments.

Q: Where can the EQN 1325.020 be typically used?

A: It is commonly deployed in CNC machines, robotic systems, textile machinery, and other automation platforms requiring precise motion control and robust, long-lasting components.

Q: What is the process to procure a sample or place a bulk order?

A: You can request a sample or initiate bulk procurement by contacting accredited suppliers or traders in India; samples are delivered with secure packaging for evaluation before full-scale purchase.

Q: When can I expect delivery after ordering the HEIDENHAIN ENCODER?

A: Delivery times are prompt, with goods transported via reliable freight services. Packaging ensures safe arrival, and customers receive detailed tracking for every shipment.

Q: How easy is the installation and maintenance of this encoder?

A: Mounting is straightforward with a clamping ring and stator coupling; the encoder is designed to be maintenance-free, offering long-term, hassle-free operation.
